ASTRO Digital Spectra Plus VHF 25–50 and 50–110 Watt Model Chart
Model Number Description
D04KKH9SW3AN Model W3 (146-174 MHz), 25-50 Watt, 512 Channels
D04KKF9SW4AN Model W4 (146-174 MHz), 25-50 Watt, 512 Channels
D04KKF9SW5AN Model W5 (146-174 MHz); 25-50 Watt, 512 Channels
D04KKH9SW7AN Model W7 (146-174 MHz),25-50 Watt, 512 Channels
T04KKH9SW9AN Model W9 (146-174 MHz), 25-50 Watt, 512 Channels
T04KLH9SW3AN Model W3 (146-174 MHz), 50-110 Watt, 512 Channels
T04KLF9SW4AN Model W4 (146-174 MHz), 50-110 Watt, 512 Channels
T04KLF9SW5AN Model W5 (146-174 MHz), 50-110 Watt, 512 Channels
T04KLH9SW7AN Model W7 (146-174 MHz), 50-110 Watt, 512 Channels
T04KLH9SW9AN Model W9 (146-174 MHz), 50-110 Watt, 512 Channels
Item No. Description
X XXXXXXXXX HRD6002_ Front-End Rcvr Board Kit (Range 2, 146-174 MHz)
X XXXXXXXXX HRN6014_ RF Board Kit
X
XXXXXXXXX HLD4342_ VCO Board Kit
X
XXXXXXXXX HLD6062_ VCO Hybrid Kit (Range 2, 146-174 MHz)
X
XXXXXXXXX HLN5558_ Command Board Kit
X
XXXXXXXXX HLN6837_ VOCON Board Kit
X
XXXX HLD6022_ Power Amplifier Board
(25-50W, Range 2, 146-174 MHz)
XXXXX HLD6063_ Power Amplifier Board
(50-110W, Range 2, 146-174 MHz)
X HLN6344_ Interconnect Board, Remote, Mid-Power (W4–W9)
XXX HLN6401_ Interconnect Board, Dash-Mount (W4–W9)
X
HLN6459_ W3 Interconnect Board Kit (Mid-Power)
X HLN6574_ W3 Interconnect Board Kit (High-Power)
X XXX HLN6486_ High-Power Interconnect Board (W4–W9)
X XX HLN6432_ Control Head Back Housing
X
X HMN4044_ W3 ASTRO Handheld Control Head
X X AAHN4045_ W4 Control Head
X X XX HLN6396_ W5,W7 Control Head Board
X X HCN1078_ W9 Control Head
O
OOOOOOOOO NTN9801_ ASTRO Spectra Plus UCM
XXX X XX HMN1080_ Microphone
X X HMN1061_ Microphone
X
XXXX HSN4018_ Speaker
XXXXX HSN6001_ Speaker
X X HLN4921_ Control Head (W9) Trunnion
X X HLN5488_ Radio Microphone Installation Hardware (W9 Trunnion)
X
X HLN6185_* Rem-Mount, SECURENET Control-Head Hardware
X XX HLN6231_ Remote W4, W5, W7 Control-Head Trunnion
XXXXX HLN6233_* Option Connector Hardware
XXXXX HLN6132_* High-Power Installation Hardware
X HLN6291_ Installation Hardware Kit
X XXX HLN6015_ Trunnion/Hardware (Dash Mount)
X
XXX HLN6060_ Dash-Mount Hardware
XXXXX HLN6121_* High-Power Radio Hardware
X XXXX HLN6866_* Transceiver Hardware
X X HLN6440_* Control Head without Keypad Hardware
X X HLN6441_* Control Head with Keypad Hardware
X = Item Included
O = Optional item
_ = the latest version kit. When ordering a kit, refer to your specific kit for the suffix number.
* = kit not available. Order piece parts from the Customer Care and Services Division.
