Motorola ASTRO Digital Spectra Service Manual

7-86 Schematics, Component Location Diagrams and Parts Lists: VCO Section
October 28, 2002 6881076C25-D
HLE6101A UHF VCO Range 1 Hybrid and HLE6102A
UHF VCO Range 2 Hybrid Parts List
Notes:
1. Valid in HLE6101A only.
2. Valid in HLE6102A only.
ITEM
MOTOROLA PART
NUMBER
DESCRIPTION
C9610 2111059B11 CAP CHIP 21D84547A11 A/I
C9611 2111078B29
2111078B27
CAP CHIP RF 33 5 NPO
100V
1
CAP CHIP RF 30 5 NPO
100V
2
C9612 2111078B14 CAP CHIP RF 11 5 NPO
100V
C9613 2111078B20 CAP CHIP RF 18 5 NPO
100V
C9614 2111078B59 CAP CHIP RF 470 5 NPO
100V
C9615 2113740B65 CAP CHIP REEL CL1 +/-30
470
C9616 2111078B14
2111078B15
CAP CHIP RF 11 5 NPO
100V
1
CAP CHIP RF 12 5 NPO
100V
2
C9617 2111078B59 CAP CHIP RF 470 5 NPO
100V
C9618 2111059B11 CAP CHIP 21D84547A11 A/I
C9619 2113740B65 CAP CHIP REEL CL1 +/-30
470
C9621 2113740B07
2113740B11
CAP CHIP REEL CL1 +/-30
1.8
1
CAP CHIP REEL CL1 +/-30
2.7
2
C9622 2113740B29
2113740B27
CAP CHIP REEL CL1 +/-30
15
1
CAP CHIP REEL CL1 +/-30
12
2
C9623 2113740B05 CAP CHIP REEL CL1 +/-30
1.5
C9624 2113740B76 CAP CHIP REEL CL1 +/-30
1500
C9625 2111059B11 CAP CHIP 21D84547A11 A/I
C9626 2111078B59 CAP CHIP RF 470 5 NPO
100V
C9628 2113740B65 CAP CHIP REEL CL1 +/-30
470
C9630 &
C9631
2111078B59 CAP CHIP RF 470 5 NPO
100V
C9632 &
C9633
2113740B65 CAP CHIP REEL CL1 +/-30
470
C9635 2113740B11 CAP CHIP REEL CL1 +/-30
2.7
C9636 &
C9638
2111059B11 CAP CHIP 21D84547A11 A/I
CR9610 4813825A05 DIODE 30V HOT CARRIER
MMBD301L
CR9616 &
CR9617
4880006E13 DIODE VAR SI SMBV1050
350MW
CR9621 4880006E13 DIODE VAR SI SMBV1050
350MW
CR9626 &
CR9630
4880142L01 DIODE PIN SOT 23 MMBV
3401
L9610 &
L9611
2480140E01 INDUCTOR CHIP 1.2 UH
L9616 2480140E04 INDUCTOR CHIP 65 NH
L9618 &
L9619
2480140E01 INDUCTOR CHIP 1.2 UH
L9621 2480140E03 INDUCTOR CHIP 50 NH
1
L9628,
L9632, &
L9633
2480140E01 INDUCTOR CHIP 1.2 UH
MP9611
thru
MP9614,
0780299L01 FRAME LEAD J STRAP
MP9618 &
M9619
0780299L01 FRAME LEAD J STRAP
MP9624 &
M9625
0780299L01 FRAME LEAD J STRAP
MP9628 0780299L01 FRAME LEAD J STRAP
MP9632 &
M9633
0780299L01 FRAME LEAD J STRAP
MP9636
thru M9639
0780299L01 FRAME LEAD J STRAP
Q9610 4880141L06 TSTR NC MOS FET SOT23
TGR MMBF
Q9635 4813827A03 TSTR NPN SML SIG
MMBR901LT1 7X
R9611 0611077A46 RES CHIP 68 5 1/8W
R9612 0611077A32 RES CHIP 18 5 1/8W
R9613 0611077B07 RES CHIP 22K 5 1/8W
R9624 &
R9625
0611077B07 RES CHIP 22K 5 1/8W
R9635 0611077A01 RES CHIP JUMPER
R9636 0611077A82 RES CHIP 2200 5 1/8
R9637 0611077A74 RES CHIP 1000 5 1/8
R9638 &
R9639
0611077A50 RES CHIP 100 5 1/8W
RT9611 0680149M01 THERMISTOR CHIP 470
OHMS
8480034P02 HYBRID CKT BD UHF VCO
R1
ITEM
MOTOROLA PART
NUMBER
DESCRIPTION
