Motorola ASTRO Digital Spectra Service Manual

7-88 Schematics, Component Location Diagrams and Parts Lists: VCO Section
October 28, 2002 6881076C25-D
HLE6103B UHF VCO Range 3 Hybrid and HLE6104B
UHF VCO Range 4 Hybrid Parts List
Notes:
1. Valid in HLE6103B only.
2. Valid in HLE6104B only.
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C9610 2111059B11 CAP CHIP 21D84547A11 A/I
C9611 2111078B22 CAP CHIP RF 22 5 NPO 100V
C9612 &
C9613
2111078B15 CAP CHIP RF 12 5 NPO 100V
C9614 2111078B59 CAP CHIP RF 470 5 NPO 100V
C9615 2113740B65 CAP CHIP REEL CL1 +/-30 470
2
C9616 2111078B18
2111078B14
CAP CHIP RF 15 5 NPO 100V
1
CAP CHIP RF 11 5 NPO 100V
2
C9617 2111078B59 CAP CHIP RF 470 5 NPO 100V
C9618 2111059B11 CAP CHIP 21D84547A11 A/I
C9619 2113740B65 CAP CHIP REEL CL1 +/-30 470
C9621 2113740B11 CAP CHIP REEL CL1 +/-30 2.7
C9622 2113740B15
2113740B31
CAP CHIP REEL CL1 +/-30 3.9
1
CAP CHIP REEL CL1 +/-30 18
2
C9623 2113740B05 CAP CHIP REEL CL1 +/-30 1.5
C9624 2113740B76 CAP CHIP REEL CL1 +/-30 1500
C9625 2111059B11 CAP CHIP 21D84547A11 A/I
C9626 2111078B59 CAP CHIP RF 470 5 NPO 100V
C9628 2113740B65 CAP CHIP REEL CL1 +/-30 470
C9630 &
C9631
2111078B59 CAP CHIP RF 470 5 NPO 100V
C9632 2113740B65 CAP CHIP REEL CL1 +/-30 470
C9633 2113740B65 CAP CHIP REEL CL1 +/-30 470
C9635 2113740B11 CAP CHIP REEL CL1 +/-30 2.7
C9636 &
C9638
2111059B11 CAP CHIP 21D84547A11 A/I
CR9610 4813825A05 DIODE 30V HOT CARRIER
MMBD301L
CR9616 4880006E13 DIODE VAR SI SMBV1050
350MW
CR9617
&
CR9621
4880006E13 DIODE VAR SI SMBV1050
350MW
CR9626
&
CR9630
4880154K05 DIODE CMN CATH DUAL PIN
SOT23
L9610 &
L9611
2480140E01 INDUCTOR CHIP 1.2 UH
L9616 2480140E06
2480140E04
INDUCTOR CHIP 130 NH
1
INDUCTOR CHIP 65 NH
2
L9618 &
L8619
2480140E01 INDUCTOR CHIP 1.2 UH
L9628 2480140E01 INDUCTOR CHIP 1.2 UH
L9632 &
L9633
2480140E01 INDUCTOR CHIP 1.2 UH
MP9611
thru
MP9614
0780299L01 FRAME LEAD J STRAP
MP9618
&
MP9619
0780299L01 FRAME LEAD J STRAP
MP9624
&
MP9625
0780299L01 FRAME LEAD J STRAP
MP9628 0780299L01 FRAME LEAD J STRAP
MP9632
&
MP9633
0780299L01 FRAME LEAD J STRAP
MP9636
thru
MP9639
0780299L01 FRAME LEAD J STRAP
Q9610 4880141L06 TSTR NC MOS FET SOT23 TGR
MMBF
Q9635 4813827A03 TSTR NPN SML SIG
MMBR901LT1 7X
R9611 0611077A32
0611077A43
RES CHIP 18 5 1/8W
1
RES CHIP 51 5 1/8W
2
R9612 0611077A46
0611077A43
RES CHIP 68 5 1/8W
1
RES CHIP 51 5 1/8W
2
R9613 0611077B07 RES CHIP 22K 5 1/8W
R9624 &
R9625
0611077B07 RES CHIP 22K 5 1/8W
R9635 0611077A01 RES CHIP JUMPER
R9636 0611077A82 RES CHIP 2200 5 1/8
R9637 0611077A74 RES CHIP 1000 5 1/8
R9638 0611077A50 RES CHIP 100 5 1/8W
R9639 0611077A50 RES CHIP 100 5 1/8W
RT9611 0680149M01 THERMISTOR CHIP 470 OHMS
8480036P02 BD CKT HYBRID
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
