Motorola ASTRO Digital Spectra Service Manual

7-106 Schematics, Component Location Diagrams and Parts Lists: RX Front-End Section
October 28, 2002 6881076C25-D
HRE6011B UHF RXFE Pre-Amp Parts List
HRE6012B UHF RXFE Pre-Amp Parts List
HRE6014B UHF RXFE Pre-Amp Parts List
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C100 2113740B76 CAP CHIP REEL CL1 +/-30
1500
C101 2113740B19 CAP CHIP REEL CL1 +/-30
5.6
C102 2113740B76 CAP CHIP REEL CL1 +/-30
1500
C103 2113740B48 CAP CHIP REEL CL1 +/-30 91
C126 2113740B11 CAP CHIP REEL CL1 +/-30
2.7
C127
thru
C129
2113741N45 CAP CHIP CL2 X7R 10%
10000
C130 2113740B34 CAP CHIP REEL CL1 +/-30 24
C131 2113740B76 CAP CHIP REEL CL1 +/-30
1500
C132 2113740B34 CAP CHIP REEL CL1 +/-30 24
C133
thru
C135
2113740B17 CAP CHIP REEL CL1 +/-30
4.7
C136 2113740B46 CAP CHIP REEL CL1 +/-30 75
C137 2113741N45 CAP CHIP CL2 X7R 10%
10000
C138 2113740B17 CAP CHIP REEL CL1 +/-30
4.7
CR100 4882958R78 DIODE 48R82958R01 A/P
5.6V
E125 2680015P02 SHLD RXFE UHF TIN
PLATED
E126 2680002M02 SHLD INJ FLTR TIN PLATED
HY126 9180209N01 FLTR BANDPASS CERAMIC
417 MHZ
JU5125 - - - - - - - - - - PART NOT USED
L125 2480140E10 INDUCTOR CHIP 100NH
L126 &
L127
2480140E01 INDUCTOR CHIP 1.2 UH
L128 2480091G21 COIL AIRWOUND
L129 2480091G33 COIL AIRWOUND
MP126 0780091P01 BRACKET RX FE UHF
MP127 0780214N01 FRAME PRESELECTOR
LEAD
MP128 4280191N01 CLIP RECEIVER
GROUNDING
MP129 4280013P01 RETAINER WIRE
MP130 4380025P01 SPACER WIRE
Q100 &
Q125
4802000P02 NEC SILICON TR 2SC3357
RE
Q126 4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
R100 &
R101
0611077A26 RES CHIP 10 5 1/8W
R102 0611077A70 RES CHIP 680 5 1/8W
R103 0611077A62 RES CHIP 330 5 1/8W
R104 0611077A43 RES CHIP 51 5 1/8W
R126 0611077A74 RES CHIP 1000 5 1/8
R127 0611077A36 RES CHIP 27 5 1/8W
R128 0611077A52 RES CHIP 120 5 1/8W
R129 0611077A80 RES CHIP 1800 5 1/8
R130 0611077A94 RES CHIP 6800 5 1/8
R131 0611077A50 RES CHIP 100 5 1/8W
R132 0611077A43 RES CHIP 51 5 1/8W
W128 3080152M07 CBL COAX ASSEMBLY
W642 3080037R05 CABLE ASSEMBLY
8480241N02 HYBRID CKT BD UHF F/E
0980212N02 RECP COAX PCB MOUNT
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C100 2113740B76 CAP CHIP REEL CL1 +/-30
1500
C101 2113740B19 CAP CHIP REEL CL1 +/-30
5.6
C102 2113740B76 CAP CHIP REEL CL1 +/-30
1500
C103 2113740B48 CAP CHIP REEL CL1 +/-30 91
C126 2113740B09 CAP CHIP REEL CL1 +/-30
2.2
C127 thru
C129
2113741N45 CAP CHIP CL2 X7R 10%
10000
C130 2113740B34 CAP CHIP REEL CL1 +/-30 24
C131 2113740B76 CAP CHIP REEL CL1 +/-30
1500
C132 2113740B34 CAP CHIP REEL CL1 +/-30 24
C132 2113740B76 CAP CHIP REEL CL1 +/-30
1500
C133 &
C134
2113740B13 CAP CHIP REEL CL1 +/-30
3.3
C135 2113740B13 CAP CHIP REEL CL1 +/-30
3.3
C136 2113740B46 CAP CHIP REEL CL1 +/-30 75
C137 2113741N45 CAP CHIP CL2 X7R 10%
10000
C138 2113740B09 CAP CHIP REEL CL1 +/-30
2.2
CR100 4882958R78 DIODE 48R82958R01 A/P
5.6V
E125 2680015P02 SHLD RXFE UHF TIN
PLATED
E126 2680002M02 SHLD INJ FLTR TIN PLATED
HY126 9180209N02 FLTR BANDPASS CERAMIC
455 MHZ
L125 2480140E10 INDUCTOR CHIP 100NH
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
L126 &
L127
2480140E01 INDUCTOR CHIP 1.2 UH
L128 2480091G21 COIL AIRWOUND
L129 2480091G33 COIL AIRWOUND
MP126 0780091P01 BRACKET RX FE UHF
MP127 0780214N01 FRAME PRESELECTOR
LEAD
MP128 4280191N01 CLIP RECEIVER
GROUNDING
MP129 4280013P01 RETAINER WIRE
MP130 4380025P01 SPACER WIRE
Q100 &
Q125
4802000P02 NEC SILICON TR 2SC3357
RE
Q126 4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
R100 &
R101
0611077A26 RES CHIP 10 5 1/8W
R102 0611077A70 RES CHIP 680 5 1/8W
R103 0611077A62 RES CHIP 330 5 1/8W
R104 0611077A43 RES CHIP 51 5 1/8W
R126 0611077A74 RES CHIP 1000 5 1/8
R127 0611077A36 RES CHIP 27 5 1/8W
R128 0611077A52 RES CHIP 120 5 1/8W
R129 0611077A80 RES CHIP 1800 5 1/8
R130 0611077A94 RES CHIP 6800 5 1/8
R131 0611077A50 RES CHIP 100 5 1/8W
R132 0611077A43 RES CHIP 51 5 1/8W
W128 3080152M07 CBL COAX ASSEMBLY
0980212N02 RECP COAX PCB MOUNT
3080037R05 CABLE ASSEMBLY
0180757T43 SHLD W/CONTACT
8480241N02 HYBRID CKT BD UHF F/E
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C100 2113740B76 CAP CHIP REEL CL1 +/-30
1500
C101 2113740B19 CAP CHIP REEL CL1 +/-30
5.6
C102 2113740B76 CAP CHIP REEL CL1 +/-30
1500
C103 2113740B48 CAP CHIP REEL CL1 +/-30 91
C126 2113740B09 CAP CHIP REEL CL1 +/-30
2.2
C127 thru
C129
2113741N45 CAP CHIP CL2 X7R 10%
10000
C130 2113740B34 CAP CHIP REEL CL1 +/-30 24
C131 2113740B76 CAP CHIP REEL CL1 +/-30
1500
C132 2113740B34 CAP CHIP REEL CL1 +/-30 24
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C133 thru
C135
2113740B13 CAP CHIP REEL CL1 +/-30
3.3
C136 2113740B46 CAP CHIP REEL CL1 +/-30 75
C137 2113741N45 CAP CHIP CL2 X7R 10%
10000
C138 2113740B09 CAP CHIP REEL CL1 +/-30
2.2
CR100 4882958R78 DIODE 48R82958R01 A/P
5.6V
E125 2680015P02 SHLD RXFE UHF TIN
PLATED
E126 2680002M02 SHLD INJ FLTR TIN PLATED
HY126 9180209N04 FLTR BANDPASS CERAMIC
497 MHZ
L125 2480140E10 INDUCTOR CHIP 100NH
L126 &
L127
2480140E01 INDUCTOR CHIP 1.2 UH
L128 2480091G21 COIL AIRWOUND
L129 2480091G33 COIL AIRWOUND
MP126 0780091P01 BRACKET RX FE UHF
MP127 0780214N01 FRAME PRESELECTOR
LEAD
MP128 4280191N01 CLIP RECEIVER
GROUNDING
MP129 4280013P01 RETAINER WIRE
MP130 4380025P01 SPACER WIRE
Q100 &
Q125
4802000P02 NEC SILICON TR 2SC3357
RE
Q126 4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
R100 0611077A26 RES CHIP 10 5 1/8W
R101 0611077A26 RES CHIP 10 5 1/8W
R102 0611077A70 RES CHIP 680 5 1/8W
R103 0611077A62 RES CHIP 330 5 1/8W
R104 0611077A43 RES CHIP 51 5 1/8W
R126 0611077A74 RES CHIP 1000 5 1/8
R127 0611077A36 RES CHIP 27 5 1/8W
R128 0611077A52 RES CHIP 120 5 1/8W
R129 0611077A80 RES CHIP 1800 5 1/8
R130 0611077A94 RES CHIP 6800 5 1/8
R131 0611077A50 RES CHIP 100 5 1/8W
R132 0611077A43 RES CHIP 51 5 1/8W
W128 3080152M07 CBL COAX ASSEMBLY
W642 3080037R05 CABLE ASSEMBLY
0980212N02 RECP COAX PCB MOUNT
8480241N02 HYBRID CKT BD UHF F/E
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
