Motorola ASTRO Digital Spectra Service Manual

7-144 Schematics, Component Location Diagrams and Parts Lists: Power Amplifier Section
October 28, 2002 6881076C25-D
HLF6078C 800MHz 15-Watt PA Parts List
ITEM
MOTOROLA
PARTS NUMBER
DESCRIPTION
C9500 2311049A37 CAP TANT CHIP 1 20 20
C9800 &
C9801
2113740B13 CAP CHIP REEL CL1 +/-30 3.3
C9802 2113740B25 CAP CHIP REEL CL1 +/-30 10
C9803 2113740B39 CAP CHIP REEL CL1 +/-30 39
C9804 2113740B11 CAP CHIP REEL CL1 +/-30 2.7
C9805 2113741N45 CAP CHIP CL2 X7R 10% 10000
C9806
thru
C9808
2113740B39 CAP CHIP REEL CL1 +/-30 39
C9851 2113740B39 CAP CHIP REEL CL1 +/-30 39
C9852 2113741N69 CAP CHIP CL2 X7R 10%
100000
C9854 2113741N69 CAP CHIP CL2 X7R 10%
100000
C9855 2113740B39 CAP CHIP REEL CL1 +/-30 39
C9857 2380090M24 CAP ALU 10 20 50V SURF MT
C9858 2111078B29 CAP CHIP RF 33 5 NPO 100V
C9859 2113741N69 CAP CHIP CL2 X7R 10%
100000
C9879 2111078B32 CAP CHIP RF 39 5 NPO 100V
C9900 2113740B39 CAP CHIP REEL CL1 +/-30 39
C9902 2113740B25 CAP CHIP REEL CL1 +/-30 10
C9920 2113740B39 CAP CHIP REEL CL1 +/-30 39
C9921 2111078B32 CAP CHIP RF 39 5 NPO 100V
C9922 2113740B01 CAP CHIP REEL CL1 +/-30 1.0
C9923 2113740B07 CAP CHIP REEL CL1 +/-30 1.8
C9924
thru
C9928
2113740B39 CAP CHIP REEL CL1 +/-30 39
C9932 2311049A37 CAP TANT CHIP 1 20 20
C9933 &
C9934
2113740B39 CAP CHIP REEL CL1 +/-30 39
C9940
thru
C9944
2113740B39 CAP CHIP REEL CL1 +/-30 39
CR9800 4811058B11 DIODE 48S11058A11 A/P
CR9850 4880236E07 DIODE TRANSIENT SUP
CR9900 4813825A05 DIODE 30V HOT CARRIER
MMBD301L
CR9920
thru
CR9922
4880236E24 DIODE PIN
CR9923 4811058B11 DIODE 48S11058A11 A/P
J9860 2980014A03 CLIP COAX TERMINAL
L9800 2480091G23 COIL AIRWOUND
L9801 2480091G24 COIL AIRWOUND
L9803 2480091G23 COIL AIRWOUND
L9804 2480091G06 COIL AIRWOUND
L9805 2480091G23 COIL AIRWOUND
L9900 &
L9920
2480091G32 COIL AIRWOUND
L9921 2480091G40 COIL AIRWOUND
L9922 2480091G32 COIL AIRWOUND
L9923 2480091G23 COIL AIRWOUND
L9924 2480091G01 COIL AIRWOUND
L9925 &
L9926
2480091G24 COIL AIRWOUND
L9927 2480091G06 COIL AIRWOUND
P9853 6480262N01 PLATE LP FEEDTHRU
ASSEMBLY
P9950 &
P9951
2980014A03 CLIP COAX TERMINAL
Q9800 4880182D50 TSTR SI SORF 4V 750MW
960MHZ
Q9500 4813822D56 TSTR NPN 100V 6A
Q9920 4880048M01 TSTR NPN DIG 47K/47K
R9500 0611077A74 RES CHIP 1000 5 1/8
R9501 0611077A28 RES CHIP 12 5 1/8W
R9560 0611077B23 RES CHIP 100K 5 1/8W
R9561 0611077A94 RES CHIP 6800 5 1/8
R9562 0611077A86 RES CHIP 3300 5 1/8
R9563 0611077A98 RES CHIP 10K 5 1/8W
R9800 0611077A54 RES CHIP 150 5 1/8W
R9801 0611077A74 RES CHIP 1000 5 1/8
R9802 &
R9805
0611077A50 RES CHIP 100 5 1/8W
R9806 0611077A50 RES CHIP 100 5 1/8W
R9807 0611077A26 RES CHIP 10 5 1/8W
R9875 1780228N03 RESISTOR SHUNT
R9900 0611077A43 RES CHIP 51 5 1/8W
R9901 &
R9902
0680194M18 RES 51 OHMS 5% 1W
R9905 0611077B23 RES CHIP 100K 5 1/8W
R9920 &
R9921
0680194M18 RES 51 OHMS 5% 1W
R9922
thru
R9927
0611077A74 RES CHIP 1000 5 1/8
R9990
thru
R9995
0611077A01 RES CHIP JUMPER
RT9560 0680149M02 THERMISTOR CHIP 100K OHM
U9850 5180110E01 MODE RF PWR 800MH 20W
2280128P01 PIN POLARIZING
8480130P05 BD CKT 1.5/15W PA
ITEM
MOTOROLA
PARTS NUMBER
DESCRIPTION
