Motorola ASTRO Digital Spectra User Manual

7-42 Schematics, Component Location Diagrams and Parts Lists: VOCON Section
September 5, 2008 6881076C25-E
HLN6458F/G VOCON Board Parts List
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C201 &
C202
– NOT PLACED
C203 &
C204
2113930F39 CAP CER CHP 33 PF 50V 5%
C205 thru
C213
– NOT PLACED
C214 2113931F17 CAP CER CHP 470 PF 5%
50V
C215 2113930F39 CAP CER CHP 33 PF 50V 5%
C216 – NOT PLACED
C217 2113932K15 CAP CER .100 UF +80/-20%
16V
C218 – NOT PLACED
C219 2113931F17 CAP CER CHP 470 PF 5%
50V
C220 &
C222
– NOT PLACED
C222 &
C223
2113931F17 CAP CER CHP 470 PF 5%
50V
C224 thru
C226
2113932K15 CAP CER .100 UF +80/-20%
16V
C227 2113930F36 CAP CER CHP 24 PF 50V 5%
C228 – NOT PLACED
C229 2113930F36 CAP CER CHP 24 PF 50V 5%
C230 &
C231
2113932K15 CAP CER .100 UF +80/-20%
16V
C236 2113932K15 CAP CER .100 UF +80/-20%
16V
C237 2113931F17 CAP CER CHP 470 PF 5%
50V
C238 2113932K15 CAP CER .100 UF +80/-20%
16V
C241 2113931F17 CAP CER CHP 470 PF 5%
50V
C245 thru
C247
2113932K15 CAP CER .100 UF +80/-20%
16V
C248 2113931F17 CAP CER CHP 470 PF 5%
50V
C249 thru
C257
– NOT PLACED
C258 2113930F39 CAP CER CHP 33 PF 50V 5%
C261 2113932K15 CAP CER .100 UF +80/-20%
16V
C262 thru
C264
– NOT PLACED
C264 2113931F17 CAP CER CHP 470 PF 5%
50V
C265 thru
C268
– NOT PLACED
C268 2113931F17 CAP CER CHP 470 PF 5%
50V
C269 – NOT PLACED
C269 &
C270
2113931F17 CAP CER CHP 470 PF 5%
50V
C271 thru
C273
– NOT PLACED
C273 2113931F17 CAP CER CHP 470 PF 5%
50V
C274 thru
C279
– NOT PLACED
C281 &
C282
2113930F39 CAP CER CHP 33 PF 50V 5%
C284 thru
C287
– NOT PLACED
C402 thru
C406
– NOT PLACED
C407 thru
C414
2113932K15 CAP CER .100 UF +80/-20%
16V
C415 2113743A23 CAP CHIP .220 UF 10% X7R
C416 thru
C420
2113932K15 CAP CER .100 UF +80/-20%
16V
C422 thru
C434
– NOT PLACED
C435 2113932K15 CAP CER .100 UF +80/-20%
16V
C436 &
C437
– NOT PLACED
C438 2113930F34 CAP CER CHP 20 PF 50V 5%
C439 – NOT PLACED
C440 2113932K15 CAP CER .100 UF +80/-20%
16V
C441 – NOT PLACED
C442 &
C443
2113930F09 CAP 1.8 PF 50V +/-0.1 PF
50V
C444 thru
C448
2113932K15 CAP CER .100 UF +80/-20%
16V
C457 2113931F13 CAP CER CHP 330 PF 5%
50V
C458 2113932K15 CAP CER .100 UF +80/-20%
16V
C459 2113930F03 CAP 1.0 PF 50V +/-0.1 PF
50V
C460 – NOT PLACED
C461 &
C462
2113932K15 CAP CER .100 UF +80/-20%
16V
C463 thru
C465
– NOT PLACED
C467 2113930F24 C~P 7.5 PF 50V +/-.25 PF
50V
C468 2113743A23 CAP CHIP .220 UF 10% X7R
C469 – NOT PLACED
C470 2311049C07 CAP TANT CHIP 100UF 10V
10%
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C471 thru
C475
– NOT PLACED
C476 2113932K15 CAP CER .100 UF +80/-20%
16V
C478 &
C479
– NOT PLACED
C480 2113930F46 CAP CER CHP 62 PF 50V 5%
C481 – NOT PLACED
C482 2311049A05 CAP TANT CHIP A/P .47 10
25
C483 2113930F39 CAP CER CHP 33 PF 50V 5%
C484 thru
C489
– NOT PLACED
C490 &
C491
2113931F17 CAP CER CHP 470 PF 5%
50V
CR201 – NOT PLACED
CR202 4884939C35 DIODE HOT CAR 39C35 4V
CR203 &
CR204
– NOT PLACED
CR205 4805218N57 DIODE DUAL
CR402 4813825A06 PIN DIODE 35V
CR403 – NOT PLACED
J201 & J401 – NOT PLACED
J501 0905516W02 CONN RECEPTACLE
J601 & J701 – NOT PLACED
J801 0913915A11 RECP SMT LOPRO 25 POS
J901 – NOT PLACED
JU201 – NOT PLACED
JU202 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
JU203 – NOT PLACED
JU204 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
JU401 – NOT PLACED
JU402 thru
JU404
0662057B47 CHIP RES 0 OHMS +-.050
OHMS
JU405 – NOT PLACED
JU407 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
L201 2460578C43 INDUCTOR CHIP 33.0UH
10%
L203 thru
L206
–- - - - NOT PLACED
L208 thru
L223
– NOT PLACED
L401 & L402 – NOT PLACED
L403 2462587E71 CHIPINDUCTOR 1800 NH
5%
Q201 thru
Q203
– NOT PLACED
Q204 thru
Q206
4805128M12 TSTR SOT BCW 60B (RH)
Q207 4805718V01 XSTR IC PKG
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
Q208 4805128M12 TSTR SOT BCW 60B (RH)
Q210 – NOT PLACED
Q211 4805128M40 TSTR BCW61BB LH 48G26
Q401 &
Q402
– NOT PLACED
R199 – NOT PLACED
R200 0662057A65 CHIP RES 4700 OHMS 5%
R201 thru
R205
0662057A97 CHIP RES 100K OHMS 5%
R206 – NOT PLACED
R207 0662057A73 CHIP RES 10K OHMS 5%
R208 thru
R210
– NOT PLACED
R211 0662057A97 CHIP RES 100K OHMS 5%
R212 0662057A73 CHIP RES 10K OHMS 5%
R213 thru
R217
– NOT PLACED
R218 0662057A65 CHIP RES 4700 OHMS 5%
R219 0662057A97 CHIP RES 100K OHMS 5%
R220 – NOT PLACED
R221 0662057A73 CHIP RES 10K OHMS 5%
R222 0662057G08 CHIP RES 82.5 K OHMS 1%
R223 0662057R92 RES CHIP 47.5K .1W 1%
R224 0662057A85 CHIP RES 33K OHMS 5%
R225 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R226 0662057A97 CHIP RES 100K OHMS 5%
R227 0662057A97 CHIP RES 100K OHMS 5%
R228 – NOT PLACED
R229 0662057A97 CHIP RES 100K OHMS 5%
R230 0662057A65 CHIP RES 4700 OHMS 5%
R231 0662057B22 CHIP RES 1.0 MEG OHMS
5%
R232 0662057A65 CHIP RES 4700 OHMS 5%
R233 0662057A85 CHIP RES 33K OHMS 5%
R234 &
R235
0662057A73 CHIP RES 10K OHMS 5%
R236 0662057A97 CHIP RES 100K OHMS 5%
R237 0662057A73 CHIP RES 10K OHMS 5%
R238 0662057A97 CHIP RES 100K OHMS 5%
R239 0662057A65 CHIP RES 4700 OHMS 5%
R240 thru
R242
– NOT PLACED
R243 thru
R248
0662057A97 CHIP RES 100K OHMS 5%
R249 – NOT PLACED
R250 0662057A73 CHIP RES 10K OHMS 5%
R251 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R252 0662057A97 CHIP RES 100K OHMS 5%
R253 thru
R256
– NOT PLACED
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
