Schematics, Component Location Diagrams and Parts Lists: VOCON Section 7-43
6881076C25-E September 5, 2008
Notes:
1. Valid in HLN6458F only.
2. Valid in HLN6458G only.
R257 thru
R260
0662057A97 CHIP RES 100K OHMS 5%
R261 0662057A73 CHIP RES 10K OHMS 5%
R262 0662057A89 CHIP RES 47K OHMS 5%
R263 0662057A73
–
CHIP RES 10K OHMS 5%
1
NOT PLACED
2
R264 0662057A82 CHIP RES 24K OHMS 5%
R265 &
R266
0662057A97 CHIP RES 100K OHMS 5%
R267 0662057A73 CHIP RES 10K OHMS 5%
R268 0662057A97 CHIP RES 100K OHMS 5%
R269 0662057A85 CHIP RES 33K OHMS 5%
R270 0662057A97 CHIP RES 100K OHMS 5%
R271 0662057A97 CHIP RES 100K OHMS 5%
R272 0662057A73 CHIP RES 10K OHMS 5%
R273 0662057A97 CHIP RES 100K OHMS 5%
R274 0662057A85
–
CHIP RES 33K OHMS 5%
1
NOT PLACED
2
R275 0662057A85 CHIP RES 33K OHMS 5%
R276 0662057A85 CHIP RES 33K OHMS 5%
R277 0662057A85 CHIP RES 33K OHMS 5%
R278 0662057A85 CHIP RES 33K OHMS 5%
R279 0662057A85 CHIP RES 33K OHMS 5%
R280 0662057A85 CHIP RES 33K OHMS 5%
R281 0662057A85 CHIP RES 33K OHMS 5%
R282 0662057A85 CHIP RES 33K OHMS 5%
R283 NOT PLACED 64AM DUMMY PART
NUMBER
R284 0662057A97 CHIP RES 100K OHMS 5%
R285 NOT PLACED 64AM DUMMY PART
NUMBER
R286 NOT PLACED 64AM DUMMY PART
NUMBER
R287 NOT PLACED 64AM DUMMY PART
NUMBER
R288 0662057A97 CHIP RES 100K OHMS 5%
R289 NOT PLACED 64AM DUMMY PART
NUMBER
R290 NOT PLACED 64AM DUMMY PART
NUMBER
R291 NOT PLACED 64AM DUMMY PART
NUMBER
R292 NOT PLACED 64AM DUMMY PART
NUMBER
R293 NOT PLACED 64AM DUMMY PART
NUMBER
R294 NOT PLACED 64AM DUMMY PART
NUMBER
R295 NOT PLACED 64AM DUMMY PART
NUMBER
R296 thru
R307
– NOT PLACED
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
R308 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R402 0662057B12 CHIP RES 390K OHMS 5%
R403 – NOT PLACED
R404 0662057A73 CHIP RES 10K OHMS 5%
R405 0662057B22 CHIP RES 1.0 MEG OHMS
5%
R406 – NOT PLACED
R407 0662057A97 CHIP RES 100K OHMS 5%
R408 – NOT PLACED
R409 thru
R411
0662057A73 CHIP RES 10K OHMS 5%
R412 0662057A65 CHIP RES 4700 OHMS 5%
R413 &
R414
0662057A73 CHIP RES 10K OHMS 5%
R415 0662057A97 CHIP RES 100K OHMS 5%
R416 – NOT PLACED
R417 0662057A97 CHIP RES 100K OHMS 5%
R418 0662057A49 CHIP RES 1000 OHMS 5%
R419 0662057A73 CHIP RES 10K OHMS 5%
R420 0662057A97 CHIP RES 100K OHMS 5%
R421 thru
R423
– NOT PLACED
R424 0662057A63 CHIP RES 3900 OHMS 5%
R425 0662057A69 CHIP RES 6800 OHMS 5%
R426 thru
R431
– NOT PLACED
R432 0662057A73 CHIP RES 10K OHMS 5%
R433 0662057A57 CHIP RES 2200 OHMS 5%
R434 – NOT PLACED
R435 0662057A73 CHIP RES 10K OHMS 5%
R436 thru
R438
– NOT PLACED
R450 0662057A89 CHIP RES 47K OHMS 5%
R459 &
R460
0662057A73 CHIP RES 10K OHMS 5%
R477 thru
R480
– NOT PLACED
R481 0662057A97 CHIP RES 100K OHMS 5%
R482 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R483 thru
R485
0662057A97 CHIP RES 100K OHMS 5%
R490 thru
R492
– NOT PLACED
U201 5105109Z72 IC 32X8 EEPROM 28 PIN
TSOP
U202 5185963A21
5185748L01
IC, 32K X 8 SRAM
1
32K X 8 SRAM 28 PIN TSOP
2
U204 5113802A75 HC11F1
MICROPROCESSOR (TAPE/
REEL)
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
U205 5185963A84 IC 512K X 16/1M X 8 SMART
VLTG
U206 5105835U80 CC SLIC5 GLOBTOP DIE
91W30 86P
U208 – NOT PLACED
U211 &
U214
5105279V65 IC
U215 &
U216
– NOT PLACED
U401 – NOT PLACED
U402 5105462G87
5185963A18
IC 32K X 8 LW PWR SRAM
TSOP
1
IC 32K X 8 LW PWR SRAM
TSOP
2
U403 5105462G87
5185963A18
IC 32K X 8 LW PWR SRAM
TSOP
1
IC 32K X 8 LW PWR SRAM
TSOP
2
U404 5105625U73 IC 256K X8 FLS ROM NIN
TSOP SD
U405 5105457W70 CC OMPAC DSP56001A
U406 5105457W19 CC ADSIC ABACUS/DSP
SUP/OMPAC
U407 5105492X73 IC 4.2V VOLTAGE
DETECTOR
U408 thru
U412
– NOT PLACED
U414 5105462G87
518963A18
IC 32K X 8 LW PWR SRAM
TSOP
1
IC 32K X 8 LW PWR SRAM
TSOP
2
U417 – NOT PLACED
VR201 thru
VR203
4813830A15 DIODE 5.6V 5% 225MW
MMBZ5232B_
VR204 &
VR205
– NOT PLACED
VR206 4813830A31 DIODE 18V 5% 225MW
MMBZ5248B_
VR207 4813830A22 DIODE 9.1V 5% 225MW
MMBZ5239B_
VR208 4813830A24 DIODE 11V 5% 225MW
MMBZ5241B_
VR209 4813830A15 DIODE 5.6V 5% 225MW
MMBZ5232B_
VR210 – NOT PLACED
VR211 4813830A15 DIODE 5.6V 5% 225MW
MMBZ5232B_
VR212 thru
VR214
4813830A15 DIODE 5.6V 5% 225MW
MMBZ5232B_
VR215 thru
VR223
– NOT PLACED
Y201 4805574W01 XTAL PRL RESONANCE
7.3728 MHZ
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
Y401 4805573W01 CRYSTAL SERIAL
RESONANCE
8405160Y03 BD CKT VOCON CTRL
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
