Motorola ASTRO Digital Spectra User Manual

Schematics, Component Location Diagrams and Parts Lists: VOCON Section 7-47
6881076C25-E September 5, 2008
HLN6458H VOCON Board Electrical Parts List
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
CAPACITOR, Fixed:
unless otherwise stated
C201, 202 – Not Placed
C203, 204 2113930F39 33pF
C205 thru 213 – Not Placed
C214 2113931F17 470pF
C215 2113930F39 33pF
C216 – Not Placed
C217 2113932K15 0.1µF
C218 – Not Placed
C219 2113931F17 470pF
C220, 221 – Not Placed
C222, 223 2113931F17 470pF
C224 thru 226 2113932K15 0.1µF
C227 2113930F36 24pF
C228 – Not Placed
C229 2113930F36 24pF
C230, 231 2113932K15 0.1µF
C236 2113932K15 0.1µF
C237 2113931F17 470pF
C238 2113932K15 0.1µF
C241 2113931F17 470pF
C245 thru 247 2113932K15 0.1µF
C248 2113931F17 470pF
C249 thru 257 – Not Placed
C258 2113930F39 33pF
C261 2113932K15 0.1µF
C262 thru 269 – Not Placed
C270 2113931F17 470pF
C271 thru 279 – Not Placed
C281, 282 2113930F39 33pF
C284 thru 287 – Not Placed
C400 2113932K15 0.1µF
C401 2113931F17 470pF
C402 thru 406 – Not Placed
C407 thru 414 2113932K15 0.1µF
C415 2113743A23 0.22µF
C416 thru 420 2113932K15 0.1µF
C421 2113931F17 470pF
C422 thru 434 – Not Placed
C435 2113932K15 0.1µF
C436, 437 – Not Placed
C438 2113930F34 20pF
C439 – Not Placed
C440 2113732K15 0.1µF
C441 – Not Placed
C442, 443 2113930F09 1.8pF
C444 thru 456 2113932K15 0.1µF
C457 2113931F13 330pF
C458 2113932K15 0.1µF
C459 2113930F03 1pF
C460 – Not Placed
C461, 462 2113932K15 0.1µF
C463 thru 465 – Not Placed
C466 2113932K15 0.1µF
C467 2113930F21 5.6pF
C468 2113743A23 0.22µF
C469 – Not Placed
C470 2311049C07 100µF
C471 thru 475 – Not Placed
C476, 477 2113932K15 0.1µF
C478, 479 – Not Placed
C480 2113930F46 62pF
C481 – Not Placed
C482 2311049A05 0.47µF
C483 2113930F39 33pF
C484 thru 489 – Not Placed
C490, 491 2113931F17 470pF
C492 – Not Placed
C493 2113932K15 0.1µF
DIODE: See Note 1.
CR201 – Not Placed
CR202 4884939C35 Hot Carrier, 4V
CR203, 204 – Not Placed
ITEM
MOTOROLA
PART NUMBE R
DESCRIPTION
CR205 4805212N57 Dual Diode
CR402 4813825A06 PIN, 35V
CR403 – Not Placed
JACK:
J201 – Not Placed
J401 – Not Placed
J501 0905516W02 Connector, Receptacle
J601 – Not Placed
J701 – Not Placed
J801 0913915A11 Connector, 25-Position
J901 – Not Placed
JUMPER:
JU201 – Not Placed
JU210, 211 – Not Placed
JU401 – Not Placed
JU402 thru
404
0662057B47 0 Ohm
JU405 – Not Placed
JU407 0662057B47 0 Ohm
COIL, RF:
unless otherwise stated
L201 2460578C43 33µH
L203 thru 206 – Not Placed
L208 thru 223 – Not Placed
L401, 402 – Not Placed
L403 2462587E71 1.8µH
TRANSISTOR: See Note 1.
Q201 thru 203 – Not Placed
Q204 thru 206 4805128M12 NPN
Q207 4805718V01 PNP
Q208 4805128M12 NPN
Q210 – Not Placed
Q211 4805128M40 PNP
Q401, 402 – Not Placed
Q403 4805128M12 NPN
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
RESISTOR: W±5%; 1/8W
unless otherwise stated
R199 – Not Placed
R200 0662057A65 4.7k
R201, 202 0662057A97 100k
R203 – Not Placed
R204 0662057A97 100k
R205, 206 – Not Placed
R207 0662057A73 10k
R208 thru 210 – Not Placed
R211 0662057A97 100k
R212 0662057A73 10k
R213 thru 217 – Not Placed
R218 0662057A65 4.7k
R219 0662057A97 100k
R220 – Not Placed
R221 0662057A73 10k
R222 0662057G08 82.5k
R223 0662057R92 47.5k
R224 0662057A85 33k
R225 0662057B47 0
R226, 227 0662057A97 100k
R228 – Not Placed
R229 0662057A97 100k
R230 0662057A65 4.7k
R231 0662057B22 1M
R232 0662057A65 4.7k
R233 0662057A85 33k
R234, 235 0662057A73 10k
R236 0662057A97 100k
R237 0662057A73 10k
R238 0662057A97 100k
R239 0662057A65 4.7k
R240 thru 242 – Not Placed
R243 thru 248 0662057A97 100k
R249 – Not Placed
R250 0662057A73 10k
ITEM
MOTOROLA
PART NUMBE R
DESCRIPTION
