Motorola ASTRO Digital Spectra User Manual

7-86 Schematics, Component Location Diagrams and Parts Lists: ASTRO Spectra Plus VOCON Section
September 5, 2008 6881076C25-E
C502 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C503 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C504 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C505 2311049G01 CAP,FXD,150UF,+10%,-10%,
4V-DC,
C506 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C507 2113743L41 CAP,CHIP,.01UF,+10%,-10%,
16V-DC
C508 2185802B01 CAP,CHIP,4.7UF,+10%,-10%,
10V-DC
C509 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C510 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C511 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C514 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C515 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C516 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C600 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C601 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
C602 2113743M24 CAP,CHIP,.1UF,+80%,-20%,
16V-DC
D300 4805129M90 DIODE,SHTK,BAT54,SM,
SOT-23,2UA
D304 4805129M90 DIODE,SHTK,BAT54,SM,
SOT-23,2UA
J501 0905516W02 CONN RECT,BTB,2 ROW,RCPT,
50CON
L200 2462587N58 IDCTR,FXD,270NH,5%,500MA,
.91OH
L300 2480067M02 FIXED INDUCTOR,FXD,200MA,
.4OHM
L301 2480067M02 FIXED INDUCTOR,FXD,200MA,
.4OHM
L302 2480067M02 FIXED INDUCTOR,FXD,200MA,
.4OHM
L400 2462587N68 IDCTR,FXD,1UH,5%,460MA,
1.75OHM
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
P1 0913915A18 RECTANGULAR/SQUARE
CONNECTOR,R
P3 – NOT PLACED
PCB 8485146D04 PCB,RGD,NEW VOCON BRD
Q200 4813824A10 XSTR,GEN PURPOSE SMALL
SIG,NP
Q201 4805128M12 XSTR,GEN PURPOSE SMALL
SIG,NPN
Q202 4805128M12 XSTR,GEN PURPOSE SMALL
SIG,NPN
Q203 4805128M12 XSTR,GEN PURPOSE SMALL
SIG,NPN
Q204 4805128M12 XSTR,GEN PURPOSE SMALL
SIG,NPN
Q300 4880048M01 XSTR,BIP GP SS,SLCN,NPN,
SM,SOT
Q301 4880048M01 XSTR,BIP GP SS,SLCN,NPN,
SM,SOT
Q302 4880048M01 XSTR,BIP GP SS,SLCN,NPN,
SM,SOT
Q303 4880048M01 XSTR,BIP GP SS,SLCN,NPN,
SM,SOT
Q600 4885844C02 XSTR,FET GP PWR,MOSFET,P,
SM,12
Q601 4880048M01 XSTR,BIP GP SS,SLCN,NPN,
SM,SOT
R200 0662057N23 RES,MF,100KOHM,5%,.032W,
SM,040
R201 0662057N23 RES,MF,100KOHM,5%,.032W,
SM,040
R202 0662057M81 RES,MF,2KOHM,5%,.032W,SM,
0402,
R207 0662057N05 RES,MF,18KOHM,5%,.032W,SM,
0402
R208 0662057N10 RES,MF,30KOHM,5%,.032W,SM,
0402
R209 0662057N10 RES,MF,30KOHM,5%,.032W,SM,
0402
R213 0662057A35 RES,MF,270OHM,5%,.0625W,
SM,060
R214 0662057A35 RES,MF,270OHM,5%,.0625W,
SM,060
R215 0662057A13 RES,CF,33OHM,5%,.1W,SM,
0603,20
R216 0662057A13 RES,CF,33OHM,5%,.1W,SM,
0603,20
R219 0662057A37 RES,MF,330OHM,5%,.063W,
SM,0603
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
R220 0662057A37 RES,MF,330OHM,5%,.063W,
SM,0603
R221 0662057N05 RES,MF,18KOHM,5%,.032W,
SM,0402
R222 0662057N23 RES,MF,100KOHM,5%,.032W,
SM,040
R223 0662057M98 RES,MF,10KOHM,5%,.032W,
SM,0402
R224 0662057N23 RES,MF,100KOHM,5%,.032W,
SM,040
R225 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R226 0662057N10 RES,MF,30KOHM,5%,.032W,
SM,0402
R229 0662057N23 RES,MF,100KOHM,5%,.032W,
SM,040
R230 0662057N23 RES,MF,100KOHM,5%,.032W,
SM,040
R231 0662057N10 RES,MF,30KOHM,5%,.032W,
SM,0402
R232 0662057M98 RES,MF,10KOHM,5%,.032W,
SM,0402
R234 0662057M50 RES,MF,100OHM,5%,.032W,
SM,0402
R235 0662057M34 RES,MF,22OHM,5%,.032W,
SM,0402,
R236 0662057M34 RES,MF,22OHM,5%,.032W,
SM,0402,
R240 0662057M86 RES,MF,3.3KOHM,5%,.032W,
SM,040
R241 – NOT PLACED
R242 0662057M64 RES,MF,390OHM,5%,.032W,
SM,0402
R243 – NOT PLACED
R245 – NOT PLACED
R246 0662057M92 RES,MF,5.6KOHM,5%,.032W,
SM,040
R247 – NOT PLACED
R248 0662057M92 RES,MF,5.6KOHM,5%,.032W,
SM,040
R249 – NOT PLACED
R250 0662057M90 RES,MF,4.7KOHM,5%,.032W,
SM,040
R301 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R303 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R304 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R306 – NOT PLACED
R307 0662057M98 RES,MF,10KOHM,5%,.032W,
SM,0402
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
R308 0662057N15 RES,MF,47KOHM,5%,.032W,
SM,0402
R309 – NOT PLACED
R310 0662057N15 RES,MF,47KOHM,5%,.032W,
SM,0402
R311 0662057M98 RES,MF,10KOHM,5%,.032W,
SM,0402
R313 – NOT PLACED
R314 – NOT PLACED
R315 0662057N15 RES,MF,47KOHM,5%,.032W,
SM,0402
R316 – NOT PLACED
R317 – NOT PLACED
R318 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R320 – NOT PLACED
R321 – NOT PLACED
R322 0662057N23 RES,MF,100KOHM,5%,.032W,
SM,040
R323 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R324 – NOT PLACED
R325 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R326 – NOT PLACED
R329 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R331 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R332 0662057M98 RES,MF,10KOHM,5%,.032W,
SM,0402
R333 0662057N15 RES,MF,47KOHM,5%,.032W,
SM,0402
R340 – NOT PLACED
R341 0662057M98 RES,MF,10KOHM,5%,.032W,
SM,0402
R342 0662057M98 RES,MF,10KOHM,5%,.032W,
SM,0402
R343 0662057M98 RES,MF,10KOHM,5%,.032W,
SM,0402
R344 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R345 0662057M74 RES,MF,1KOHM,5%,.032W,SM,
0402,
R346 0662057M98 RES,MF,10KOHM,5%,.032W,
SM,0402
R347 0662057N15 RES,MF,47KOHM,5%,.032W,
SM,0402
R348 – NOT PLACED
R349 0662057M98 RES,MF,10KOHM,5%,.032W,
SM,0402
R350 0662057M98 RES,MF,10KOHM,5%,.032W,
SM,0402
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
