Motorola ASTRO Digital Spectra User Manual

Schematics, Component Location Diagrams and Parts Lists: ASTRO Spectra Plus VOCON Section 7-87
6881076C25-E September 5, 2008
R351 0662057M98 RES,MF,10KOHM,5%,.032W,
SM,0402
R352 0662057M98 RES,MF,10KOHM,5%,.032W,
SM,0402
R353 – NOT PLACED
R354 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R355 – NOT PLACED
R356 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R357 – NOT PLACED
R358 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R400 0662057M86 RES,MF,3.3KOHM,5%,.032W,
SM,040
R401 0662057M86 RES,MF,3.3KOHM,5%,.032W,
SM,040
R402 0662057N23 RES,MF,100KOHM,5%,.032W,
SM,040
R403 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R404 0662057M91 RES,MF,5.1KOHM,5%,.032W,
SM,040
R405 0662057M82 RES,MF,2.2KOHM,5%,.032W,
SM,040
R406 0662057N23 RES,MF,100KOHM,5%,.032W,
SM,040
R407 0662057M98 RES,MF,10KOHM,5%,.032W,
SM,0402
R408 0662057N05 RES,MF,18KOHM,5%,.032W,
SM,0402
R409 0662057N23 RES,MF,100KOHM,5%,.032W,
SM,040
R410 0662057M98 RES,MF,10KOHM,5%,.032W,
SM,0402
R416 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R419 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R420 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R421 – NOT PLACED
R425 0662057B46 RES,CF,10MOHM,5%,.1W,SM,
0603
R426 0662057N39 RES,MF,470KOHM,5%,.032W,
SM,040
R427 0662057B46 RES,CF,10MOHM,5%,.1W,SM,
0603
R428 0662057M50 RES,MF,100OHM,5%,.032W,
SM,0402
R429 – NOT PLACED
R430 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R434 0662057M81 RES,MF,2KOHM,5%,.032W,SM,
0402,
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
R435 0662057M74 RES,MF,1KOHM,5%,.032W,SM,0
402,
R436 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R437 0662057N07 RES,MF,22KOHM,5%,.032W,
SM,0402
R438 0662057N07 RES,MF,22KOHM,5%,.032W,
SM,0402
R441 0662057N39 RES,MF,470KOHM,5%,.032W,
SM,040
R442 0662057N39 RES,MF,470KOHM,5%,.032W,
SM,040
R443 0662057B46 RES,CF,10MOHM,5%,.1W,SM,
0603
R451 0662057N13 RES,MF,39KOHM,5%,.032W,
SM,0402
R452 0662057N06 RES,MF,20KOHM,5%,.032W,
SM,0402
R454 0662057N11 RES,MF,33KOHM,5%,.032W,
SM,0402
R455 0662057N15 RES,MF,47KOHM,5%,.032W,
SM,0402
R456 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R457 0662057V15 RES,CF,33000OHM,1%,.063W,
SM,04
R458 0662057V18 RES,CF,43KOHM,1%,.063W,
SM,0402
R459 0662057V17 RES,CF,39000OHM,1%,.063W,
SM,04
R460 0662057V02 RES,CF,10KOHM,1%,.0625W,
SM,040
R461 0662057M50 RES,MF,100OHM,5%,.032W,
SM,0402
R462 0662057M01 RES,MF,0OHM,5%,.032W,SM,
0402
R500 0662057M81 RES,MF,2KOHM,5%,.032W,SM,0
402,
R600 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R603 0662057B47 RES,CF,0OHM,5%,.1W,SM,0603
R606 0662057N23 RES,MF,100KOHM,5%,.032W,
SM,040
R607 – NOT PLACED
R608 0662057M98 RES,MF,10KOHM,5%,.032W,
SM,0402
R609 – NOT PLACED
SC400 – NOT PLACED
U200 5185963A50 IC,ASIC GATE ARRAY,SM,
BGA144,C
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
U201 5166554A01 IC,A/D-D/A,BGA,ADDAG IC
(CMOS)
U202 5113818A14 IC,OP AMP,2PER PKG,SO-8,13
U300 5188017U01 IC,UCNTLR,SM,DSP56XXX,
16BITS,I
U301 5185956E69 IC,FLSH,64MB,60NS,SM,DRAM
1.8V
U302 5185941F03 IC,SRAM,8M,512KX16,70NS,
SM,FBG
U303 5105109Z31 IC,MUX/DEMUX,SM,TSSOP16
,MAX SP
U304 – NOT PLACED
U305 5109522E53 IC,BFR,1PER
PKG,NC7SZ125P5X,3
U306 5113837A15 IC,BFR,4PER
PKG,MC74LCX125,3ST
U307 5113837A02 IC,NOR,MC74LCX02,4PER
PKG,TSSO
U400 5185368C55 IC,POT,DIG,LOW POWER,
LINEAR T
U401 5185368C55 IC,POT,DIG,LOW POWER,
LINEAR T
U402 5185941F33 IC,PCM CODEC,IC,PCM
CODEC,IC,3
U404 5113818A14 IC,OP AMP,2PER PKG,SO-8,13
U408 5185623B01 HI SPEED CMOS INVTR
U409 5185353D93 IC,BFR,1PER
PKG,74AHC1G04,INVE
U410 5185353D55 IC VOLTAGE REGULATOR
100MZ ADJ
U411 5185353D55 IC VOLTAGE REGULATOR
100MZ ADJ
U412 5185353D46 IC,VDET,SM,SOT-23/5,1PER
PKG,V
U413 5185353D55 IC VOLTAGE REGULATOR
100MZ ADJ
U414 5185353D55 IC VOLTAGE REGULATOR
100MZ ADJ
U417 5113837A11 IC,BUS DRIVER,8PER PKG,
3ST,
U419 5113837A11 IC,BUS DRIVER,8PER PKG,
3ST,
U420 5113837A11 IC,BUS DRIVER,8PER PKG,
3ST,
U421 5113837A11 IC,BUS DRIVER,8PER PKG,
3ST,
U422 5113837A11 IC,BUS DRIVER,8PER PKG,
3ST,
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
U423 5114000C09 IC,SW,3157,TSSOP,PB-FREE
U500 5113805C01 IC,BFR,8PER PKG,3ST,
TSSOP20,5.
U501 5113805C01 IC,BFR,8PER PKG,3ST,
TSSOP20,5.
U502 5113805C01 IC,BFR,8PER PKG,3ST,
TSSOP20,5.
U503 5113837A07 IC,LINE DRIVER,8PER PKG,
3ST,TS
U504 5113837A07 IC,LINE DRIVER,8PER PKG,
3ST,TS
U600 5113805B16 IC,CNTR BIN,4BITS,2PER PKG,
SOI
U601 5113806A05 IC,F-F/D,2PER PKG,SOIC14,18
U602 5113805B44 IC,OR,74HC32,4PER PKG,
TSSOP14,
VR301 4813830A11 DIODE,ZEN,MMBZ5228BLT1,
TO-236A
VR302 4813830A28 DIODE,ZEN,MMBZ5245BLT1,
TO-236A
VR303 4813830A15 DIODE,ZEN,MMBZ5232BLT1,
TO-236A
VR304 4813830A22 DIODE,ZEN,MMBZ5239BLT1,
TO-236A
VR305 4813830A15 DIODE,ZEN,MMBZ5232BLT1,
TO-236A
Y400 4885071E01 OSC,FXD,16.8MHZ,SM,SM4,
M5LX3.2
Y401 4809995L05 RESON,QRTZ,.032768MHZ,SM,
F
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
