Motorola ASTRO Digital Spectra User Manual

Schematics, Component Location Diagrams and Parts Lists: VCO Section 7-95
6881076C25-E September 5, 2008
HLD4342B and HLD4343B VHF VCO Parts List
Notes:
1. Valid in HLD4342B
2. Valid in HLD4343B
HLD4342D and HLD4343D VHF VCO Parts List
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C3645 2113741N45 CAP CHIP CL2 X7R 10%
10000
C3655 2113740B65 CAP CHIP REEL CL1 +/-30 470
C3656 2113741N45 CAP CHIP CL2 X7R 10%
10000
C3657 2113740B28 CAP CHIP REEL CL1 +/-30 13
C3658 2113740B36 CAP CHIP REEL CL1 +/-30 30
C3659 2113740B39 CAP CHIP REEL CL1 +/-30 39
C3660 2113740B65 CAP CHIP REEL CL1 +/-30 470
C636 2113741N21 CAP CHIP CL2 X7R 10% 1000
C637 &
C638
2113740B76 CAP CHIP REEL CL1 +/-30
1500
C639 2311049A37 CAP TANT CHIP 1 20 20
C646 &
C647
2113741N45 CAP CHIP CL2 X7R 10%
10000
C648 2113741N69 CAP CHIP CL2 X7R 10%
100000
C649 2113741N45 CAP CHIP CL2 X7R 10%
10000
C650 2113740B65 CAP CHIP REEL CL1 +/-30 470
C651 2113740B21 CAP CHIP REEL CL1 +/-30 6.8
C652 – NOT PLACED
C653 2113740B65 CAP CHIP REEL CL1 +/-30 470
C654 2160521H41 CAP CHIP 220K 80 20 25V Y5V
C661 2113741N45 CAP CHIP CL2 X7R 10%
10000
C662 2113741N69 CAP CHIP CL2 X7R 10%
100000
C663 &
C664
– NOT PLACED
C665 2113741N69 CAP CHIP CL2 X7R 10%
100000
C666 2160521H41 CAP CHIP 220K 80 20 25V Y5V
C668 thru
C672
2113740B76 CAP CHIP REEL CL1 +/-30
1500
C673 2113741N69 CAP CHIP CL2 X7R 10%
100000
C674 –
2113740B65
NOT PLACED
1
CAP CHIP REEL CL1 +/-30 470
2
C675 2113741N45 CAP CHIP CL2 X7R 10%
10000
C676 2113740B65
–
CAP CHIP REEL CL1 +/-30 470
1
NOT PLACED
2
C677 &
C679
2113740B65 CAP CHIP REEL CL1 +/-30 470
C685 2113740B21 CAP CHIP REEL CL1 +/-30 6.8
C686 2311049J07 CAP TANT CHIP 3.3 10 20
C687 2113740B21 CAP CHIP REEL CL1 +/-30 6.8
C688 2113741N45 CAP CHIP CL2 X7R 10%
10000
C689 2113740B44 CAP CHIP REEL CL1 +/-30 62
C690 2113741N45 CAP CHIP CL2 X7R 10%
10000
C691 2113740B11 CAP CHIP REEL CL1 +/-30 2.7
C692 2113740B65 CAP CHIP REEL CL1 +/-30 470
C700 – NOT PLACED
C701 2113741N69 CAP CHIP CL2 X7R 10%
100000
C702 &
C703
2113740B76 CAP CHIP REEL CL1 +/-30
1500
CR601 &
CR602
4880154K03 DIODE DUAL SCHOTTKY
MIXER
J3641 0980110M01 RECP COAX PCBMOUNT
J642 0980212N03 RECP COAX PCB MOUNT
JU670 &
JU671
– NOT PLACED
L3663 2480140E01 INDUCTOR CHIP 1.2 UH
L3664 &
L3665
2480140E04 INDUCTOR CHIP 65 NH
L660 2480140E01 INDUCTOR CHIP 1.2 UH
L661 &
L662
2480140E03 INDUCTOR CHIP 50 NH
L666 thru
L674
2480067M01 CHK RF CHIP BEAD
INDUCTOR 28MZ
L675 2480140E01 INDUCTOR CHIP 1.2 UH
L676 2405452C87 COIL CHIP INDUCTOR 39 5
L677 2480140E01 INDUCTOR CHIP 1.2 UH
L678 2480140E03 INDUCTOR CHIP 50 NH
L679 2405452C87 COIL CHIP INDUCTOR 39 5
L681 2480140E03 INDUCTOR CHIP 50 NH
L682 thru
L685
2480067M01 CHK RF CHIP BEAD
INDUCTOR 28MZ
P0601 2880099M02 PLUG VERTICAL
P0602 –
4280088P01
NOT PLACED
1
CLIP COAX
2
Q3683 4813827A03 TSTR NPN SML SIG
MMBR901LT1 7X
Q642 &
Q643
4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
Q675 4802000P02 NEC SILICON TR 2SC3357 RE
Q677 &
Q678
4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
Q681 4813827A03 TSTR NPN SML SIG
MMBR901LT1 7X
Q682 4813827A03 TSTR NPN SML SIG
MMBR901LT1 7X
R3663 0611077A62 RES CHIP 330 5 1/8W
R3664 0611077A82 RES CHIP 2200 5 1/8
R3665 – NOT PLACED
R3666 0611077A30 RES CHIP 15 5 1/8W
R3667 0611077A66 RES CHIP 470 5 1/8W
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
R3668 0611077A90 RES CHIP 4700 5 1/8
R3669 – NOT PLACED
R636 0611077A94 RES CHIP 6800 5 1/8
R637 0611077B07 RES CHIP 22K 5 1/8W
R639 0611077B15 RES CHIP 47K 5 1/8W
R641 0611077A58 RES CHIP 220 5 1/8W
R642 0611077A90 RES CHIP 4700 5 1/8
R643 0611077A74 RES CHIP 1000 5 1/8
R644 0611077A98 RES CHIP 10K 5 1/8W
R645 0611077A58 RES CHIP 220 5 1/8W
R646 &
R647
0611077A98 RES CHIP 10K 5 1/8W
R648 &
R649
0611077A70 RES CHIP 680 5 1/8W
R650 0611077A98 RES CHIP 10K 5 1/8W
R651 0611077A54 RES CHIP 150 5 1/8W
R652 0611077A86 RES CHIP 3300 5 1/8
R652 – NOT PLACED
R653 0611077A62 RES CHIP 330 5 1/8W
R654 0611077A98 RES CHIP 10K 5 1/8W
R655 0611077A32 RES CHIP 18 5 1/8W
R656 0611077A50 RES CHIP 100 5 1/8W
R657 0611077A30 RES CHIP 15 5 1/8W
R658 – NOT PLACED
R659 0611077A78 RES CHIP 1500 5 1/8
R660 0611077A90 RES CHIP 4700 5 1/8
R661 0611077A30 RES CHIP 15 5 1/8W
R662 – NOT PLACED
R670 0611077A50 RES CHIP 100 5 1/8W
R671 – NOT PLACED
R672 –
0611077A58
NOT PLACED
1
RES CHIP 220 5 1/8W
2
R673 –
0611077A58
NOT PLACED
1
RES CHIP 220 5 1/8W
2
R674 &
R675
0611077A50 RES CHIP 100 5 1/8W
R677 0611077A36 RES CHIP 27 5 1/8W
R678 &
R679
0611077A62 RES CHIP 330 5 1/8W
R680 0611077A26 RES CHIP 10 5 1/8W
R681 &
R682
0611077A74 RES CHIP 1000 5 1/8
R683 0611077A50 RES CHIP 100 5 1/8W
R684 0611077A86 RES CHIP 3300 5 1/8
R685 0611077A98 RES CHIP 10K 5 1/8W
R699 0611077A38 RES CHIP 33 5 1/8W
R700 0611077A62 RES CHIP 330 5 1/8W
T601 &
T602
2405548Q06 TRANSFORMER, RF
1280954T43 SPECTRA VHF VCO
ASSEMBLY
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
ITEM
MOTOROLA PART
NUMBER
DESCRIPTION
C3645 2113741N45 CAP CHIP CL2 X7R 10%
10000
C3655 2113740B65 CAP CHIP REEL CL1 +/-30
470
C3656 2113741N45 CAP CHIP CL2 X7R 10%
10000
C3657 2113740B28 CAP CHIP REEL CL1 +/-30
13
C3658 2113740B36 CAP CHIP REEL CL1 +/-30
30
C3659 2113740B39 CAP CHIP REEL CL1 +/-30
39
C3660 2113740B65 CAP CHIP REEL CL1 +/-30
470
C636 2113740B76 CAP CHIP REEL CL1 +/-30
1500
1
C637 & C638 2113740B76 CAP CHIP REEL CL1 +/-30
1500
C639 2311049A37 CAP TANT CHIP 1 20 20
C646 & C647 2113741N45 CAP CHIP CL2 X7R 10%
10000
C648 2113741N69 CAP CHIP CL2 X7R 10%
100000
C649 2113741N45 CAP CHIP CL2 X7R 10%
10000
C650 2113740B65 CAP CHIP REEL CL1 +/-30
470
C651 2113740B21 CAP CHIP REEL CL1 +/-30
6.8
C652 – NOT PLACED
C653 2113740B65 CAP CHIP REEL CL1 +/-30
470
C654 2113741N69 CAP CHIP CL2 X7R 10%
100000
1
C661 2113741N45 CAP CHIP CL2 X7R 10%
10000
C662 2113741N69 CAP CHIP CL2 X7R 10%
100000
C663 – NOT PLACED
2
C664 – NOT PLACED
C665 & C666 2113741N69 CAP CHIP CL2 X7R 10%
100000
C668 & C669 2113740B76 000CAP CHIP REEL CL1
+/-30 1500
C670 thru
C672
2113740B76 CAP CHIP REEL CL1 +/-30
1500
C673 2113741N69 CAP CHIP CL2 X7R 10%
100000
