Motorola ASTRO Digital Spectra - Page 354

7-96 Schematics, Component Location Diagrams and Parts Lists: VCO Section
September 5, 2008 6881076C25-E
Notes:
1. Valid in HLD4342D only.
2. Valid in HLD4343D only.
C674 –
2113740B65
NOT PLACED
1
CAP CHIP REEL CL1 +/-30
470
2
C675 2113741N45 CAP CHIP CL2 X7R 10%
10000
C676 2113740B65
–
CAP CHIP REEL CL1 +/-30
470
1
NOT PLACED
2
C677 & C679 2113740B65 CAP CHIP REEL CL1 +/-30
470
C685 2113740B21 CAP CHIP REEL CL1 +/-30
6.8
C686 2311049J07 CAP TANT CHIP 3.3 10 20
C687 2113740B21 CAP CHIP REEL CL1 +/-30
6.8
C688 2113741N45 CAP CHIP CL2 X7R 10%
10000
C689 2113740B44 CAP CHIP REEL CL1 +/-30
62
C690 2113741N45 CAP CHIP CL2 X7R 10%
10000
C691 2113740B11 CAP CHIP REEL CL1 +/-30
2.7
C692 2113740B65 CAP CHIP REEL CL1 +/-30
470
C700 – NOT PLACED
2
C701 2113741N69 CAP CHIP CL2 X7R 10%
100000
C702 & C703 2113740B76 CAP CHIP REEL CL1 +/-30
1500
C704 2113740B30 CAP CHIP REEL CL1 +/-30
16
C705 2113740B29 CAP CHIP REEL CL1 +/-30
15
CR601 &
CR602
4880154K03 DIODE DUAL SCHOTTKY
MIXER
J3641 0980110M01 RECP COAX PCBMOUNT
J642 0980212N03 RECP COAX PCB MOUNT
JU670 &
JU671
– NOT PLACED
L3663 2480140E01 INDUCTOR CHIP 1.2 UH
L3664 &
L3665
2480140E04 INDUCTOR CHIP 65 NH
L660 2480140E01 INDUCTOR CHIP 1.2 UH
L661 & L662 2480140E03 INDUCTOR CHIP 50 NH
L666 thru
L674
2480067M01 CHK RF CHIP BEAD
INDUCTOR 28MZ
L675 2480140E01 000INDUCTOR CHIP 1.2
UH
L676 2405452C87 COIL CHIP INDUCTOR 39
5
L677 2480140E01 INDUCTOR CHIP 1.2 UH
L678 2480140E03 INDUCTOR CHIP 50 NH
ITEM
MOTOROLA PART
NUMBER
DESCRIPTION
L679 2405452C87 COIL CHIP INDUCTOR 39
5
L681 2480140E03 INDUCTOR CHIP 50 NH
L682 thru
L685
2480067M01 CHK RF CHIP BEAD
INDUCTOR 28MZ
L686 2405452C87 COIL CHIP INDUCTOR 39
5
1
P0601 2880099M02 PLUG VERTICAL
P0602 –
4280088P01
NOT PLACED
1
CLIP COAX
2
Q3683 4813827A03 TSTR NPN SML SIG
MMBR901LT1 7X
Q642 &
Q643
4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
Q644 4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
1
Q675 4802000P02 NEC SILICON TR
2SC3357 RE
Q677 &
Q678
4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
Q681 &
Q682
4813827A03 TSTR NPN SML SIG
MMBR901LT1 7X
R3663 0611077A62 RES CHIP 330 5 1/8W
R3664 0611077A82 RES CHIP 2200 5 1/8
R3665 – NOT PLACED
R3666 0611077A30 RES CHIP 15 5 1/8W
R3667 0611077A66 RES CHIP 470 5 1/8W
R3668 0611077A90 RES CHIP 4700 5 1/8
R3669 – NOT PLACED
R636 0611077A94 RES CHIP 6800 5 1/8
R637 0611077B07 RES CHIP 22K 5 1/8W
R639 0611077B15 RES CHIP 47K 5 1/8W
R641 0611077A58 RES CHIP 220 5 1/8W
R642 0611077A90 RES CHIP 4700 5 1/8
R643 0611077A74 RES CHIP 1000 5 1/8
R644 0611077A98 RES CHIP 10K 5 1/8W
R645 0611077A58 RES CHIP 220 5 1/8W
R646 & R647 0611077A98 RES CHIP 10K 5 1/8W
R648 & R649 0611077A70 RES CHIP 680 5 1/8W
R650 0611077A98 RES CHIP 10K 5 1/8W
R651 0611077A54 RES CHIP 150 5 1/8W
R652 0611077A86
–
RES CHIP 3300 5 1/8
1
NOT PLACED
2
R653 0611077A62 RES CHIP 330 5 1/8W
R654 0611077A98 RES CHIP 10K 5 1/8W
R655 0611077A32 RES CHIP 18 5 1/8W
R656 0611077A50 RES CHIP 100 5 1/8W
R657 0611077A30 RES CHIP 15 5 1/8W
R658 – NOT PLACED
R659 0611077A78 RES CHIP 1500 5 1/8
R660 0611077A90 RES CHIP 4700 5 1/8
R661 0611077A30 RES CHIP 15 5 1/8W
ITEM
MOTOROLA PART
NUMBER
DESCRIPTION
R662 – NOT PLACED
R670 0611077A50 RES CHIP 100 5 1/8W
R671 – NOT PLACED
R672 & R673 0611077A58 RES CHIP 220 5 1/8W
2
R674 0611077A48 RES CHIP 82 5 1/8W
R675 0611077A50 RES CHIP 100 5 1/8W
R677 0611077A26 RES CHIP 10 5 1/8W
R678 & R679 0611077A62 RES CHIP 330 5 1/8W
R680 0611077A26 RES CHIP 10 5 1/8W
R681 0611077A74 RES CHIP 1000 5 1/8
R682 0611077A74 RES CHIP 1000 5 1/8
R683 0611077A48 RES CHIP 82 5 1/8W
R684 0611077A86 RES CHIP 3300 5 1/8
R685 0611077A98 RES CHIP 10K 5 1/8W
R699 0611077A43 RES CHIP 10 5 1/8W
R700 0611077A62 RES CHIP 330 5 1/8W
R701 0611077A26 RES CHIP 10 5 1/8W
R702 0611077A98 RES CHIP 10K 5 1/8W
1
T601 2405548Q06 TRANSFORMER, RF
T602 2405548Q06 TRANSFORMER, RF
1280954T43 SPECTRA VHF VCO
ASSEMBLY
ITEM
MOTOROLA PART
NUMBER
DESCRIPTION
