Schematics, Component Location Diagrams and Parts Lists: RX Front-End Section 7-111
6881076C25-E September 5, 2008
HRD6001E VHF RXFE Parts List HRD6002E Parts List
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C3100 &
C3101
2113740B34 CAP CHIP REEL CL1 +/-30 24
C3102 2113740B30 CAP CHIP REEL CL1 +/-30 16
C3103 2113740B34 CAP CHIP REEL CL1 +/-30 24
C3104 2113740B11 CAP CHIP REEL CL1 +/-30
2.7
C3105 &
C3106
2113740B09 CAP CHIP REEL CL1 +/-30
2.2
C3107 2113740B11 CAP CHIP REEL CL1 +/-30
2.7
C3108 thru
C3110
2111078B15 CAP CHIP RF 12 5 NPO 100V
C3125 2113740B29 CAP CHIP REEL CL1 +/-30 15
C3126 2113740B35 CAP CHIP REEL CL1 +/-30 27
C3150 thru
C3153
2113740B27 CAP CHIP REEL CL1 +/-30 12
C3154 2111078B25 CAP CHIP RF 27 5 NPO 100V
C3200 2113740B30 CAP CHIP REEL CL1 +/-30 16
C3201 2113740B24 CAP CHIP REEL CL1 +/-30
9.1
C3202 &
C3203
2113740B49 CAP CHIP REEL CL1 +/-30
100
C3205 thru
C3208
2113741N45 CAP CHIP CL2 X7R 10%
10000
C3209 &
C3210
0611077A01 RES CHIP JUMPER
CR3125 4880236E17 DIODE QUAD RING
CR3200 &
CR3201
4880154K03 DIODE DUAL SCHOTTKY
MIXER
E3103 &
E3104
2980014A03 CLIP COAX TERMINAL
E3105 &
E3106
2680003M03 SHLD HI IF TIN PLATED
E3107 2680004M03 SHLD OUTPUT MATCH TIN
PLATED
J3102 0980110M01 RECP COAX PCBMOUNT
JU3175 &
JU3178
0611077A01 RES CHIP JUMPER
JU3180 &
JU3181
0611077A01 RES CHIP JUMPER
L3100 thru
L3104
2480148M07 IND 4 1/2 TURNS FER CORE
82NH
L3125 &
L3126
2480140E06 INDUCTOR CHIP 130 NH
L3150 &
L3151
2480091G23 COIL AIRWOUND
L3200 2480140E04 INDUCTOR CHIP 65 NH
L3201 2480140E03 INDUCTOR CHIP 50 NH
L3202 2480140E04 INDUCTOR CHIP 65 NH
L3203 2480140E07 INDUCTOR CHIP 680 NH
L3204 2480140E01 INDUCTOR CHIP 1.2 UH
Q3200 &
Q3201
4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
Q3202 4802000P02 NEC SILICON TR 2SC3357
RE
R3100 0611077A26 RES CHIP 10 5 1/8W
R3101 &
R3125
0611077A70 RES CHIP 680 5 1/8W
R3126 0611077A26 RES CHIP 10 5 1/8W
R3127 0611077A70 RES CHIP 680 5 1/8W
R3128 0611077A43 RES CHIP 51 5 1/8W
R3130 0611077A01 RES CHIP JUMPER
R3200 0611077A43 RES CHIP 51 5 1/8W
R3201 0611077A98 RES CHIP 10K 5 1/8W
R3202 0611077B15 RES CHIP 47K 5 1/8W
R3203 0611077A43 RES CHIP 51 5 1/8W
R3204 0611077A01 RES CHIP JUMPER
R3205 0611077A98 RES CHIP 10K 5 1/8W
R3206 0611077A46 RES CHIP 68 5 1/8W
R3208 0611077A26 RES CHIP 10 5 1/8W
R3209 0611077A72 RES CHIP 820 5 1/8W
T3125 2405548Q06 TRANSFORMER, RF
T3126 2405548Q06 TRANSFORMER, RF
W3101 3080037R05 CABLE ASSEMBLY
W3103 3080152M07 CBL COAX ASSEMBLY
1280954T42 SPECTRA VHF FRONT END
ASSEM
MXW7635 HRD6001B/6011B PL
8480067S32 PCB VHF RX PNL
5480072G01 LABEL BD CKT PRTD
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C3100 2113740B31 CAP CHIP REEL CL1 +/-30 18
C3101 2113740B35 CAP CHIP REEL CL1 +/-30 27
C3102 2113740B31 CAP CHIP REEL CL1 +/-30 18
C3103 2113740B35 CAP CHIP REEL CL1 +/-30 27
C3104 211374B009
2113740B11
CAP CHIP REEL CL1 +/-30
2.2
3
CAP CHIP REEL CL1 +/-30
2.7
C3105 thru
C3106
2113740B11 CAP CHIP REEL CL1 +/-30
2.7
C3107 2113740B13 CAP CHIP REEL CL1 +/-30
3.3
C3108 2111078B16
2111078B19
CAP CHIP RF 13 5 NPO 100V
3
CAP CHIP RF 16 5 NPO 100V
C3109 &
C3110
2111078B16 CAP CHIP RF 13 5 NPO 100V
C3125 2113740B29 CAP CHIP REEL CL1 +/-30 15
C3126 2113740B35 CAP CHIP REEL CL1 +/-30 27
C3150 thru
C3153
2113740B27 CAP CHIP REEL CL1 +/-30 12
C3154 2111078B25 CAP CHIP RF 27 5 NPO 100V
C3200 2113740B25
2113740B30
CAP CHIP REEL CL1 +/-30 10
3
CAP CHIP REEL CL1 +/-30 16
C3201 2113740B23
2113740B24
CAP CHIP REEL CL1 +/-30
8.2
3
CAP CHIP REEL CL1 +/-30
9.1
C3202 2113740B49
2113740B65
CAP CHIP REEL CL1 +/-30
100
CAP CHIP REEL CL1 +/-30
470
3
C3203 2113740B49 CAP CHIP REEL CL1 +/-30
100
C3205 thru
C3208
2113741N45 CAP CHIP CL2 X7R 10%
10000
C3209 2113740B31 CAP CHIP REEL CL1 +/-30
18
3
C3210 2113740B32 CAP CHIP REEL CL1 +/-30 20
3
CR3125 4880236E17 DIODE QUAD RING
1
CR3126 &
C3127
4880154K03 DIODE DUAL SCHOTTKY
MIXER
4
CR3200 &
CR3201
4880154K03 DIODE DUAL SCHOTTKY
MIXER
4
E3103 &
E3104
2980014A03 CLIP COAX TERMINAL
6
E3105 &
E3106
2680003M03 SHLD HI IF TIN PLATED
6
E3107 2680004M03 SHLD OUTPUT MATCH TIN
PLATED
6
J3102 0980110M01 RECP COAX PCBMOUNT
JU3175 0611077A01 RES CHIP JUMPER
3
JU3177 &
JU3178
– NOT PLACED
JU3176,
JU3179, &
JU3181
3
0611077A01 RES CHIP JUMPER
JU3180 &
JU3181
– NOT PLACED
3
JU3182 0611077A01 RES CHIP JUMPER
3
JU3209 &
JU3210
0611077A01 RES CHIP JUMPER
2
L3100 thru
L3104
2480148M04 IND 3 1/2 TURNS FER CORE
62NH
L3125 &
L3126
2480140E06 INDUCTOR CHIP 130 NH
L3150 &
L3151
2480091G23 COIL AIRWOUND
L3200 2480140E04
2480140E06
INDUCTOR CHIP 65 NH
INDUCTOR CHIP 130 NH
3
L3201 2480140E03 INDUCTOR CHIP 50 NH
L3202 2480140E04
2480140E06
INDUCTOR CHIP 65 NH
INDUCTOR CHIP 130 NH
3
L3203 2480140E07
2480140E06
INDUCTOR CHIP 680 NH
INDUCTOR CHIP 130 NH
3
L3204 2480140E01 INDUCTOR CHIP 1.2 UH
M3000 &
M3001
2980014A03 CLIP COAX TERMINAL
3
Q3200 4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
Q3201 4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
Q3202 4882971R01
4802000P02
TSTR NPN 71R01 RF
NEC SILICON TR 2SC3357
RE
7
R3100 0611077A26 RES CHIP 10 5 1/8W
R3101 0611077A70 RES CHIP 680 5 1/8W
R3125 0611077A70
0611077A68
RES CHIP 680 5 1/8W
RES CHIP 560 5 1/8W
3
R3126 0611077A26 RES CHIP 10 5 1/8W
R3127 0611077A70
0611077A68
RES CHIP 680 5 1/8W
RES CHIP 560 5 1/8W
3
R3128 0611077A43 RES CHIP 51 5 1/8W
R3130 0611077A01 RES CHIP JUMPER
R3131 &
R3132
– NOT PLACED
3
R3200 0611077A43 RES CHIP 51 5 1/8W
R3201 0611077A98 RES CHIP 10K 5 1/8W
R3202 0611077B15 RES CHIP 47K 5 1/8W
R3203 0611077A43 RES CHIP 51 5 1/8W
R3204 0611077A01 RES CHIP JUMPER
R3205 0611077A98 RES CHIP 10K 5 1/8W
R3206 0611077A36 RES CHIP 27 5 1/8W
5
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
