Motorola ASTRO Digital Spectra User Manual

7-112 Schematics, Component Location Diagrams and Parts Lists: RX Front-End Section
September 5, 2008 6881076C25-E
Notes:
1. Valid in HRD6002C only.
2. Valid in HRD6002E only.
3. Valid in HRD6002G only.
4. Not valid in HRD6002C.
5. Not valid in HRD6002E
6. Not valid in HRD6002G
7. Valid in HRD6002E and HRD6002G only.
HRD6011E Parts List
Notes:
1. Valid in HRD6011D only.
2. Valid in HRD6011C only.
HRD6012E Parts List
R3208 0611077A26
0611077A32
RES CHIP 10 5 1/8W
RES CHIP 18 5 1/8W
1
R3209 0611077A68
0611077A72
RES CHIP 560 5 1/8W
RES CHIP 820 5 1/8W
4
R3210 0611077A68
0611077A72
RES CHIP 560 5 1/8W
4
RES CHIP 820 5 1/8W
3
SH1 2680003M03 SHLD HI IF TIN PLATED
3
SH2 2680004M03 SHLD OUTPUT MATCH TIN
PLATED
3
SH3 2680003M03 SHLD HI IF TIN PLATED
3
T3125 2405548Q06 TRANSFORMER, RF
6
T3126 2405548Q06 TRANSFORMER, RF
T3127 2405548Q06 TRANSFORMER, RF
3
W3101 3080037R05 CABLE ASSEMBLY
6
W3103 3080152M07 CBL COAX ASSEMBLY
6
1280954T42 SPECTRA VHF FRONT END
ASSEM
ITEM
MOTOROLA
PART NUBER
DESCRIPTION
C3100 &
C3101
2113740B34 CAP CHIP REEL CL1 +/-30 24
C3102 2113740B30 CAP CHIP REEL CL1 +/-30 16
C3103 2113740B34 CAP CHIP REEL CL1 +/-30 24
C3104 2113740B11 CAP CHIP REEL CL1 +/-30
2.7
C3105 &
C3106
2113740B09 CAP CHIP REEL CL1 +/-30
2.2
C3107 2113740B11 CAP CHIP REEL CL1 +/-30
2.7
C3108 2111078B16 CAP CHIP RF 13 5 NPO 100V
C3109 2111078B15 CAP CHIP RF 12 5 NPO 100V
C3110 2111078B16 CAP CHIP RF 13 5 NPO 100V
C3125 2113740B29 CAP CHIP REEL CL1 +/-30 15
C3126 2113740B35 CAP CHIP REEL CL1 +/-30 27
C3150
thru
C3153
2113740B27 CAP CHIP REEL CL1 +/-30 12
C3154 2111078B25 CAP CHIP RF 27 5 NPO 100V
C3200 2113740B30 CAP CHIP REEL CL1 +/-30 16
C3201 2113740B24 CAP CHIP REEL CL1 +/-30
9.1
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C3202 &
C3203
2113740B49 CAP CHIP REEL CL1 +/-30
100
C3205
thru
C3208
2113741N45 CAP CHIP CL2 X7R 10%
10000
C3209 &
C3210
0611077A01 RES CHIP JUMPER
1
CR3125 4880236E17 DIODE QUAD RING
CR3200 4880154K03 DIODE DUAL SCHOTTKY
MIXER
1
CR3201 4880154K03 DIODE DUAL SCHOTTKY
MIXER
1
E3103 &
E3104
2980014A03 CLIP COAX TERMINAL
E3105 &
E3106
2680003M03 SHLD HI IF TIN PLATED
E3107 2680004M03 SHLD OUTPUT MATCH TIN
PLATED
J3102 0980110M01 RECP COAX PCBMOUNT
JU3177 &
JU3178
0611077A01 RES CHIP JUMPER
JU3180 &
JU3182
0611077A01 RES CHIP JUMPER
L3100 thru
L3104
2480148M07 IND 4 1/2 TURNS FER CORE
82NH
L3125 &
L3126
2480140E06 INDUCTOR CHIP 130 NH
L3150 &
L3151
2480091G23 COIL AIRWOUND
L3200 2480140E04 INDUCTOR CHIP 65 NH
L3201 2480140E03 INDUCTOR CHIP 50 NH
L3202 2480140E04 INDUCTOR CHIP 65 NH
L3203 2480140E07 INDUCTOR CHIP 680 NH
L3204 2480140E01 INDUCTOR CHIP 1.2 UH
Q3200 &
Q3201
4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
Q3202 4882971R01 TSTR NPN 71R01 RF
R3100 &
R3126
0611077A01 RES CHIP JUMPER
R3128 0611077A43 RES CHIP 51 5 1/8W
R3130 0611077A01 RES CHIP JUMPER
R3201 0611077A98 RES CHIP 10K 5 1/8W
R3202 0611077B15 RES CHIP 47K 5 1/8W
R3203 0611077A43 RES CHIP 51 5 1/8W
R3204 0611077A01 RES CHIP JUMPER
R3205 0611077A98 RES CHIP 10K 5 1/8W
R3206 &
R3208
0611077A26 RES CHIP 10 5 1/8W
R3209 0611077A72 RES CHIP 820 5 1/8W
R3210 0611077A72 RES CHIP 820 5 1/8W
2
T3125 2405548Q06 TRANSFORMER, RF
T3126 2405548Q06 TRANSFORMER, RF
W3101 3080037R05 CABLE ASSEMBLY
ITEM
MOTOROLA
PART NUBER
DESCRIPTION
W3103 3080152M07 CBL COAX ASSEMBLY
1280954T42 SPECTRA VHF FRONT END
ASSEM
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C3100 2113740B31 CAP CHIP REEL CL1 +/-30 18
C3101 2113740B35 CAP CHIP REEL CL1 +/-30 27
C3102 2113740B31 CAP CHIP REEL CL1 +/-30 18
C3103 2113740B35 CAP CHIP REEL CL1 +/-30 27
C3104 2113740B09
2113740B11
CAP CHIP REEL CL1 +/-30
2.2
3
CAP CHIP REEL CL1 +/-30
2.7
C3105 thru
C3106
2113740B11 CAP CHIP REEL CL1 +/-30
2.7
C3107 2113740B13 CAP CHIP REEL CL1 +/-30
3.3
C3108 2111078B16
2111078B19
CAP CHIP RF 13 5 NPO 100V
3
CAP CHIP RF 16 5 NPO 100V
C3109 &
C3110
2111078B16 CAP CHIP RF 13 5 NPO 100V
C3125 2113740B29 CAP CHIP REEL CL1 +/-30 15
C3126 2113740B35 CAP CHIP REEL CL1 +/-30 27
C3150 thru
C3153
2113740B27 CAP CHIP REEL CL1 +/-30 12
C3154 2111078B25 CAP CHIP RF 27 5 NPO 100V
C3200 2113740B25
2113740B30
CAP CHIP REEL CL1 +/-30 10
3
CAP CHIP REEL CL1 +/-30 16
C3201 2113740B24
2113740B25
CAP CHIP REEL CL1 +/-30
9.1
CAP CHIP REEL CL1 +/-30 10
3
C3202 2113740B49
2113740B65
CAP CHIP REEL CL1 +/-30
100
CAP CHIP REEL CL1 +/-30
470
3
C3203 2113740B49 CAP CHIP REEL CL1 +/-30
100
C3205 thru
C3208
2113741N45 CAP CHIP CL2 X7R 10%
10000
C3209 0611077A01
2113740B31
RES CHIP JUMPER
CAP CHIP REEL CL1 +/-30 18
3
ITEM
MOTOROLA
PART NUBER
DESCRIPTION
C3210 0611077A01
2113740B32
RES CHIP JUMPER
CAP CHIP REEL CL1 +/-30 20
3
CR3125 4880236E17 DIODE QUAD RING
1
CR3126 &
CR3127
4880154K03 DIODE DUAL SCHOTTKY
MIXER
4
CR3200 &
CR3201
4880154K03 DIODE DUAL SCHOTTKY
MIXER
E3103 &
E3104
2980014A03 CLIP COAX TERMINAL
5
E3105 &
E3106
2680003M03 SHLD HI IF TIN PLATED
5
E3107 2680004M03 SHLD OUTPUT MATCH TIN
PLATED
5
J3102 0980110M01 RECP COAX PCBMOUNT
JU3175 – NOT PLACED
3
JU3176 &
JU3177
0611077A01 RES CHIP JUMPER
JU3178 – NOT PLACED
3
JU3179 0611077A01 RES CHIP JUMPER
JU3180 – NOT PLACED
3
JU3181 0611077A01 RES CHIP JUMPER
3
JU3182 0611077A01
–
RES CHIP JUMPER
NOT PLACED
3
L3100 thru
L3104
2480148M04 IND 3 1/2 TURNS FER CORE
62NH
L3125 &
L3126
2480140E06 INDUCTOR CHIP 130 NH
L3150 &
L3151
2480091G23 COIL AIRWOUND
L3200 2480140E04
2480140E06
INDUCTOR CHIP 65 NH
INDUCTOR CHIP 130 NH
3
L3201 2480140E03 INDUCTOR CHIP 50 NH
L3202 2480140E04
2480140E06
INDUCTOR CHIP 65 NH
INDUCTOR CHIP 130 NH
3
L3203 2480140E06
2480140E07
INDUCTOR CHIP 130 NH
3
INDUCTOR CHIP 680 NH
L3204 2480140E01 INDUCTOR CHIP 1.2 UH
M3000 &
M3001
2980014A03 CLIP COAX TERMINAL
3
Q3200 &
Q3201
4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
Q3202 4880141L01
4802000P02
4882971R01
TSTR PNP SOT23 LO
PROFILE TAPE
2
NEC SILICON TR 2SC3357
RE
3
TSTR NPN 71R01 RF
1
R3101,
R31127 &
R3125
– NOT PLACED
3
R3100 &
R3126
0611077A01 RES CHIP JUMPER
R3128 0611077A43 RES CHIP 51 5 1/8W
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
