Motorola Astro XTL 5000 User Manual

ASTRO
®
XTL™ 5000 Digital
Mobile Radio with W4 Control Head
Quick Reference Card Product Safety and RF Exposure Compliance
ATTENTION!
This radio is restricted to occupational use only to satisfy FCC RF energy exposure requirements. Before using this product, read the RF energy awareness information and operating instructions in the Product Safety and RF Exposure booklet enclosed with your radio (Motorola Publication part number 6881095C99) to ensure compliance with RF energy exposure limits.
BASIC OPERATION Turning the Radio On and Off Setting the Volume and Squelch Changing Modes Transmitting Transmitting (Conventional Modes)
Activating Scan Programming a Scan List Selecting Scan Mode Priority
Before using this product, read the operating instructions for safe usage contained in the Product Safety and RF Exposure booklet enclosed with your radio.
!
C
a u t i o
n
PHONE
PAGE
or
SECURE
or
EMERGENCY
Page
Emer
CALL DIRECT
XMIT
BUSY
Mode
Volume
Pwr
Phon
Call SelScan
Mic
Home
Dim
H/L
Dir Mon
SCAN SELECT MONITOR
MODE
KNOB
POWER ON/OFF/
VOLUME KNOB
H
OME
H
ORN/
LI
GHTS
PRIORITY/
NON-PRIORITY
INDICATORS
DIRECT
INDICATOR
Rotate the Vol (Volume) knob clockwise.
1 Turn the Vol knob clockwise to increase volume or
counterclockwise to decrease volume as desired.
2 On conventional modes with Private-Line or Digital
Private-Line, press Mon or remove the microphone from the hang-up clip to defeat the coded squelch.
3 Press Mon again, or replace the microphone on the
hang-up clip to return to coded-squelch operation.
4 To adjust squelch level, hold Mon until a tone sounds.
5 Turn Mode knob to select squelch level.
6 Press Home.
Turn the Mode knob to select the desired mode
OR Press Home to access the preprogrammed Home mode.
1 Press and hold the microphone PTT button. 2 When the transmit light comes on solid and no alert
tones sound (or a talk-permit tone or ID sidetone sounds), speak into the microphone in a normal voice.
3 State your FCC call sign at the beginning of each
transmission.
1 Press Dir (Direct). The Dir indicator lights. 2 Press Dir again to return to repeater operation.
1 Press Scan to start a scan. If no activity exists, the
display shows your selected mode. When a scanned channel or talkgroup becomes active, the display shows the active mode name. The PRI and NPRI indicators show priority.
2 Press Scan again to stop scanning. 1 Hold Scan until a tone sounds and the scan indicator
blinks.
2 Turn the Mode knob to select the mode you want to
program.
3 Press the Sel button as indicated in the table below to
add or remove the displayed mode from the scan list.
4 Repeat the previous steps to continue editing the list. 5 Press Home or Scan to exit. Press Sel Mode Indicator
One time Non-Priority NPRI lit Two times Second Priority PRI lit Three times First Priority PRI blinks Four times Delete from List No indicator
1 Press the Sel button as indicated in the table above
to designate up to two modes as priorities.
2 Press Home or Scan to end scan list selection.
