11-1
Troubleshooting
Waveforms 11
Introduction to
This Section
This section contains images of waveforms which may be useful in
verifying operation of certain parts of the circuitry. These waveforms
are for reference only; the actual data depicted will vary depending
upon operating conditions.
Waveforms
103 Acquisitions
Tek stopped:
T
1
Ch1
T
M 200us Ch1 -680mV
W1: Switched Regulator Clock Out
Trace 1 - (U709)LX measured with radio in
standby mode with UNSW_B+ at 7.5VDC.
2.00V
MAEPF-26008-O
Waveform W1
To Next Page
