Motorola ASTRO XTS 3000 User Manual

1-3
XTS 3000 R Radios
Only
1. If the radio has been submersed in water, shake the radio well to
remove any water that may be trapped inside the speaker grille
and microphone port. Otherwise, the water will decrease the audio
quality of the radio. Dry the radio and battery.
2. If the radio’s battery contact area has been exposed to water, dry
the battery contacts (both on the radio and the battery) before
attaching the battery to the radio. Otherwise, the water could
short-circuit the radio.
3. If the radio has been submersed in corrosive medium (such as salt
water), rinse the radio and battery in fresh water, and dry the radio
and battery.
4. If cleaning is desired, use a diluted solution of mild dishwashing
detergent and fresh water (one teaspoon of detergent to one gallon
of water).
5. Do not disassemble the radio. This could damage radio seals and
result in leak paths into the radio. Any radio maintenance should
be performed by only a qualified service person.
• The XTS 3000 R radio casting has a vent hole
that allows for pressure equalization in the
radio. Never poke this vent with any objects,
such as needles, tweezers, or screwdrivers. This
will create a leak path into the radio and the
radio’s submersibility will be lost.
• This pressure equalization vent is located on the
chassis, just below the battery contact. Never
obstruct or cover the two slots with any object,
including a label. Ensure that no oily substances
come in contact with this vent.
• The XTS 3000 R radio is designed to be
submersed to a maximum depth of 6 feet and a
maximum submersion time of 4 hours.
Exceeding either maximum limit may result in
damage to the radio.
!
C a u t i o n

Motorola ASTRO XTS 3000 Specifications

General

Brand	Motorola
Model	ASTRO XTS 3000
Category	Radio
Language	English
