12-2
J401
Controller Board to Vocoder Board
J401 Pin # Description
To/
From
1 R/W* U701-35
2 HEN* U702-J7
3 A0 U701-17
4 A2 U701-15
5 VPP Q110
6 DSP_RST* U701-58
7 EMC_RXD J601-5
8+5V U709-9
9 +5V U709-9
10 +5VA U710-3
11 MICEN U718-14
12 INTMICEN U718-16
13 GROUND N/C
14 HREQ* U701-75
15 GROUND N/C
16 A1 U701-16
17 VPP Q110
18 BOOT_MODE U701-76
19 EMC_TXD J601-3
20 MOSI U701-66
21 SPI_SCK U701-67
22 SBI P201-4
23 +5VA U710-3
24 EXT_INT_SPKR* U718-20
25 SPKEN U718-19
26 D7 U701-49
27 D5 U701-47
28 D3 U701-45
29 D1 U701-43
30 +5V U709-9
31 GROUND N/C
32 GROUND N/C
33 DOUT* P201-1
34 SDO U718-6
35 MODIN P201-14
36 MAI U718-15
37 ADSIC_RST* 701-56
38 GROUND N/C
39 D6 U701-48
40 D4 U701-46
41 D2 U701-44
42 D0 U701-40
43 ODC-2.4MHZ P201-11
44 GROUND N/C
45 DOUT P201-2
46-49 GROUND N/C
50 ADSIC_SEL* U701-57
J601
Controller Board to Encryption Module
J601 Pin # Description To/From
1 SW_B+ Q106-5
2 SW_B+ Q106-5
3 EMC_TXD J401-19
4N/C
5 EMC_RXD J401-7
6N/C
7 MISO U701-65
8N/C
9 SPI_SCK U701-67
10 N/C
11 EMC_REQ U702-H3
12 N/C
13 TAMPER GROUND
14 UNSW_B+ P201-15, 20
15 KEYFAIL U717-2
16 N/C
17 MOSI U701-66
18 N/C
19 EMC_EN U702-D6
20 N/C
21 TAMPER GROUND
22 N/C
23 N/C
24 TAMPER GROUND
25 EMC_WAKEUP U702-K7
P107
Controller Board to Keypad Module
P107 Pin # Description To/From
1 COL1 U702-A7
2 COL2 U702-D5
3 COL3 U702-B4
4 BL_EN U702-E7
5 ROW1 U702-J3
6 ROW2 U702-G4
7 ROW3 U702-K8
8 ROW4 U702-G9
9 ROW5 U702-F8
10 ROW6 U702-G7
11 +5V U709-9
12 GROUND N/C
