13-23
Notes:
1. For optimum performance, order replacement diodes, transistors, and circuit
modules by Motorola part number only.
2. When ordering crystals, specify carrier frequency, crystal frequency, crystal
type number, and Motorola part number.
3. Part value notations:
p=10
-12
n=10
-9
µ=10
-6
m=10
-3
k=10
3
M=10
6
4. ITEM refers to the component reference designator. SIDE refers to the location
of the component on the board; S1=Side 1, S2=Side 2.
5. The NLE4249 UHF RF Board uses a 6-layer printed circuit board.
R130 0662057B47 0
R131 0662057B22 1 M
R203 (R1) 0662057A09 22
R203 (R2) 0662057A01 10
R204 0662057A73 10k
R205 0662057A77 15k
R206 0662057A73 10k
R207 0662057A93 68k
R208 0662057A58 2.4k
R209 0662057A41 470
R210 0662057A37 330
R211 0662057A27 120
R212, R213 0662057A46 750
R214 0662057A89 47k
R215 0662057A88 43k
R217 0662057A77 15k
R218 0662057A97 100k
R219 (R1) 0662057A01 10
R219 (R2) 0662057A09 22
R220 0662057A56 2k
R221 0662057A51 1.2k
R222 0662057A56 2k
R223 0662057A89 47k
R301 0662057B47 0
R401 0660079U18 5.1
R402 0662057B08 270k
R403 0662057A83 27k
R404 0662057A73 10k
R405 0662057A13 33
R406 0662057A69 6.8k
R407 0662057A17 47
R410, R411 0662057A21 68
R412 0662057A13 33
R413 0662057A35 270
R414 0662057A56 2k
R416 0662057A80 20k
R417 0662057A01 10
R418 0662057A53 1.5k
R419 0662057A89 47k
R420 0662057A80 20K
R421 0662057A56 2k
R510 0662057B47 0
R601 0662057A25 100
R602 0662057A56 2k
R603 0662057A85 33k
R604 0662057A75 12k
R605 0662057A61 3.3k
R606 0662057B22 1 M
THERMISTOR:
RT101 0605621T02 50k
SHIELD:
S201 2602657J02 VCO
S202 (R1) 2602674J03 VCO Back
S202 (R2) 2602674J02 VCO Back
S203 2602658J01 Pendulum
S204 2602675J01 Synthesizer, Back
S205 2602660J01 Harmonic Filter, UHF
S206 2602686J01 Coil
S207 2605547X01 Varactor
TRANSFORMER:
T1 2505515V08 4:1
T2 2505515V11 16:1
INTEGRATED CIRCUIT
MODULE: See Note 1.
U1 5105329V20 RF Amplifier
U2 5105329V26 Mixer
U101 5105835U52 TX ALC
U102 5105835U51 D/A CONVERTER
U104 5102001J68 Coupler
U105 (R1) 5105385Y10 LDMOS RF PA UHF-1
U105 (R2) 5105385Y11 LDMOS RF PA UHF-2
U106 5105469E65 5V Regulator
U201 5102227J37 VCO Buffer
U202 5105469E65 5V Regulator
U203 5105385Y42 16.8 MHz Reference Oscillator
U204 5105457W81 Fractional-N Synthesizer
U401 5105835U90 ABACUS
DIODE: See Note 1.
VR1 4813830A33 20V
VR3 4813830A33 20V
VR402 4805129M58 Varactor
LAYER 1 (L1)
LAYER 2 (L2)
LAYER 3 (L3)
LAYER 4 (L4)
INNER LAYERS
LAYER 5 (L5)
LAYER 6 (L6)
MAEPF-18827-A
SIDE 1
SIDE 2
6-LAYER CIRCUIT BOARD DETAIL VIEWING
COPPER STEPS IN PROPER LAYER SEQUENCE
