Motorola ASTRO XTS 3000 User Manual

13-52
NCN6128B Controller Board
Electrical Parts List
Notes:
1. For optimum performance, order replacement diodes, transistors, and circuit
modules by Motorola part number only.
2. When ordering crystals, specify carrier frequency, crystal frequency, crystal
type number, and Motorola part number.
3. Part value notations:
p=10
-12
n=10
-9
µ=10
-6
m=10
-3
k=10
3
M=10
6
4. ITEM refers to the component reference designator. SIDE refers to the location
of the component on the board; S1=Side 1, S2=Side 2.
5. The NCN6128 Controller Kit uses an 8-layer printed circuit board.
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
CAPACITOR, Fixed: unless
otherwise stated
C100 thru 106 2113931F17 470 pF
C108 2113930F39 33 pF
C109 thru 111 2113931F17 470 pF
C112 2113930F39 33 pF
C113, 114 2113931F17 470 pF
C116 2113930F39 33 pF
C117 2113931F17 470 pF
C118 2113930F39 33 pF
C120, 121 2113930F39 33 pF
C122 2113931F17 470 pF
C123, 124 2113930F39 33 pF
C125 thru 138 2113931F17 470 pF
C140 2113931F17 470 pF
C142 thru 152 2113931F17 470 pF
C160 2113932K15 .1 µF
C161 2113930F27 10 pF
C162 2113930F13 Not Placed
C163 2113930F27 10 pF
C164, 165 2113932K15 .1 µF
C167 2113931F17 470 pF
C168 thru 172 2113932K15 .1 µF
C174, 175 2311049A97 33 µF
C176 2113932K15 .1 µF
C177 2113931F13 330 pF
C178 2113932K15 .1 µF
C179 2113931F49 .01 µF
C180 2311049C07 100 µF
C181, 182 2113931F17 470 pF
C183 thru 186 2311049J12 4.7 µF
C187 2113931F41 4700 pF
C188 2311049J12 4.7 µF
C189 2113931F41 4700 pF
C190, 191 2113931F13 33 pF
C192 2113743A19 .1 µF
C193 thru 197 2113743A23 .22 µF
C198 2113931F49 .01 µF
C199, 200 2113743A23 .22 µF
C201 2311049J12 4.7 µF
C202 2113931F41 4700 pF
C203, 204 2113932K15 .1 µF
C205, 206 2113743F12 .33 µF
C207 thru 209 2311049A07 1 µF
C210 2113743A13 .047 µF
C211 2113743A23 .22 µF
C212, 213 2113932K15 .1 µF
C214 2311049A05 .47 µF
C215 thru 217 2113932K15 .1 µF
C219, 220 2113932K15 .1 µF
C223 2113931F17 470 pF
C224 2113930F39 33 pF
C225, 226 2113931F17 470 pF
C227, 288 2113930F39 33 pF
DIODE: See Note 1.
D100 4884939C35 Hot Carrier, 4V
D101 4884939C35 Hot Carrier, 4V
D104 4813833B09 Schottky, 30V
JACK:
J101 0913915A15 Controls Flex Assembly
Connector
J601 0913915A11 Encryption Board Connector
COIL, RF:
unless otherwise stated
L100 thru 115 2462587Q40 270 nH
L117, 118 2462587Q40 270 nH
L119 2405528W04 100 uH
L120 2460578C43 33 uH
L500 2462587Q40 270 nH
L501 2405688Z01 Ferrite Bead
TRANSISTOR: See Note 1.
Q102 4805128M12 NPN
Q104, 105 4805128M12 NPN
Q106 4805718V01 MOSFET Switch
Q107 4880048M01 NPN
Q108 4805921T09 Dual NPN
Q109 4805128M12 NPN
Q110 4805128M40 PNP
Q111, 112 4805921T09 Dual NPN
Q113 4805128M40 Not Placed
RESISTOR:
R100 0662057A65 4.7K
R101 0662057A89 47K
R102 0662057A36 300
R103 0662057A35 270
R105 0662057A62 3.6K
R106 0662057A97 100K
R108 0662057A97 100K
R109 0662057A73 10K
R110 thru 112 0662057A39 390
R114 0662057A49 1K
R115 0662057A39 390
R116 thru 118 0662057A97 100K
R119 thru 123 0662057A49 1K
R124 0662057A85 33K
R125, 126 0662057A97 100K
R127 thru 133 0662057A49 1K
R135 thru 143 0662057A85 33K
R144 thru 152 0662057A49 1K
R153 thru 155 0662057A97 100K
R156 0662057A73 10K
R157 0662057B47 0
R158 0662057B22 1M
R159, 160 0662057A65 4.7K
R161 0662057A73 10K
R163 0683962T45 68
R164 0662057A73 10K
R165 0662057A57 2.2K
R167 0662057A97 100K
R168 0662057A65 4.7K
R169 0662057A97 100K
R170 0662057G08 82.5K
R171 0662057A97 100K
R172 0662057R92 47.5K
R173 0662057B47 0
R174, 175 0662057A73 10K
R176, 177 0662057A97 100K
R178 0662057A85 33K
R179 0662057A65 4.7K
R180 0662057A97 100K
R181 0662057B47 0
R182, 183 0662057A97 100K
R184, 185 0662057A73 10K
R186 0662057B14 470K
R187 thru 189 0662057A97 100K
R190 0662057A73 10K
R191 0662057A49 1K
R192 0662057A73 10K
R193 0662057A39 390
R194 0662057A62 3.6K
R195 0662057A65 4.7K
R196 0662057A89 47K
R197 0662057A39 390
R198 0662057A62 3.6K
R199 0662057G14 110K
R200 0662057A65 4.7K
R201 0662057A89 47K
R202 0662057G08 82.5K
R203 thru 205 0662057A73 10K
R206 0662057A77 15K
R207 0662057A85 33K
R208 0662057A97 100K
R209 0662057A65 4.7K
R211 thru 213 0662057A73 10K
R502 0662057A97 100K
R503 0662057A65 4.7K
R504 0662057A97 100K
R507, 208 0662057A97 100K
R509 0662057C03 1
R510 0662057B47 0
R513, 514 0662057A39 390
R515 0662057A97 100K
R516 0662057A49 1K
R517 0662057A23 82
R518 0662057A39 390
R519, 520 0662057A97 100K
R521 0662057A25 100
R529 0662057A97 100K
R531 0662057B47 Not Placed
R533 0662057B47 Not Placed
R535, 536 0662057A97 100K
R537 0662057C03 1
R538 0662057B47 Not Placed
R539 0662057A73 10K
R540 0662057A73 Not Placed
R541 0662057B47 0
R542 0662057A65 Not Placed
INTEGRATED CIRCUIT
MODULE: See Note 1.
U701 5113802A33 HC11F1 MCU (QFP)
U702 5105457W33 SLIC 5 (OMPAC)
U704 5105750U28 CMOS Switch (MUX)
U705 5105662U54 32K X 8 SRAM
U706 5105625U33 32K X 8 EEPROM
U708 5105279V65 AND GATE
U709 5105625U38 5V Digital Switching
Regulator
U710 5105625U41 5V Analog Regulator
U712, 713 5105750U28 CMOS Switch (MUX)
U714 5105364W01 DUAL OP-AMP
U717 5105750U28 CMOS Switch (MUX)
U718 5105457W68 AUDIO PA (QFP)
U725 5105279V65 AND GATE
U726 5105492X73 4.2V Voltage Detector
U727 5105109Z25 1M X 8 FLASH ROM
U728, 729 5105750U28 CMOS Switch (MUX)
DIODE: See Note 1.
VR100 thru 102 4813830A24 Zener, 11V
VR104 4805117Y01 Dual Zener, 6.2V
VR105 4813830A15 Zener, 5.6V
VR107 thru 109 4813830A24 Zener, 11V
VR110 4805117Y01 Dual Zener, 6.2V
VR111 4813830A31 Zener, 18V
VR112 4813830A24 Zener, 11V
VR113 4813830A31 Zener, 18V
VR117 4813830A24 Zener, 11V
VR119 4813830A22 Zener, 9.1V
VR121 4813830A24 Zener, 11V
VR122, 123 4813830A15 Zener, 5.6V
VR124 4805117Y01 Dual Zener, 6.2V
VR300 4805117Y01 Dual Zener, 6.2V
CRYSTAL: See Note 2
Y100 4805574W01 7.3728 MHz CRYSTAL
MISCELLANEOUS:
8405259Z03 PC Board
LAYER 1 (L1)
LAYER 2 (L2)
LAYER 3 (L3)
LAYER 4 (L4)
INNER LAYERS
LAYER 5 (L5)
LAYER 6 (L6)
MAEPF-18828-A
SIDE 1
SIDE 2
8-LAYER CIRCUIT BOARD DETAIL VIEWING
COPPER STEPS IN PROPER LAYER SEQUENCE
LAYER 7 (L7)
LAYER 8 (L8)
