C24 Hardware Interface Manual
Version 0.3
TABLE 17 – Rx port Gains
Handset Vs. 0dBm0 Headset Vs. 0dBm0
AT
Command
Value
0dBm0
gain level
(dB)
0dBm0
output level
(mV
RMS
)
0dBm0 0dBm0
gain level output level
(dB) (mV
RMS
)
0 -35.8 12 -28.6 29
1 -32.9 17.5 -25.7 40
2 -29.8 25 -22.8 55.9
3 -27 34.5 -19.8 79.4
4 -23.8 50 -16.8 111.5
5 -20.8 70 -13.8 158
6 -17.8 100 -10.7 226
7 -14.8 140 -7.7 316.8
TABLE 18 – Microphone and Headset-Microphone port Gains
0dBm0 Input Maximum Input
AT Command
Value
Level Level
(mV
RMS
) (mV
RMS
)
0 87 350
… … …
3 63 250
… … …
16 15 55
… … …
31 4 11
Motorola General Business Use
Page 29 of 36
Applicant: Motorola, INC
FCC ID: IHDP56JE1
