C24 Hardware Interface Manual
Version 0.3
2.11 Antenna Interface
The module’s antenna connector is the RF interface to the network.
The antenna interface is terminated by an MMCX connector type, which is 50 impedance matched at
the relevant frequencies.
The antenna or antenna application must be installed properly to achieve best performance.
TABLE 25 – Antenna Interface Specifications
Parameter Conditions Specifications
1900 MHz
-106dBm
Sensitivity
800 MHz
-106dBm
Max Average Power Max Peak Power
1900 MHz
25dBm 30dBm
RF output
power
800 MHz
25dBm 30dBm
Gain 0 dBi (unity) gain or greater
Impedance 50
VSWR Less than 2.5:1
Motorola General Business Use
Page 36 of 36
