C24 Hardware Interface Manual
Version 0.3
2.2 Power Supply
The Module power supply must be a single external DC voltage source of 3.0V to 4.4V.
TABLE 2 – Power supply signals
Pin (s) Signal Name Description
1-4 GND Main ground connection for the module.
DC supply input for the module.
5-8 VCC
V
IN
= 3.0 V to 4.4 V
I
MAX
≤ 600 mA at TX/RX
2.2.1 Power Consumption
The following table specifies typical current consumption ratings of the module in various operating
modes. The current ratings refer to the overall current consumption through the VCC supply.
TABLE 3 – Current ratings (VCC = 3.6 V)
Parameter Description Conditions Min Typ Max Unit
I
OFF
RTC mode 30 uA
I
IDLE
Idle mode Registered 20 mA
- SCI2
- TBR = 30 minutes
Legend
I
SLEEP
Low power mode 2.5 mA
• SCI2: Paging slots every 5.12 seconds
• TBR: Timer Base Registration
I
MAX
Max TX/RX current 600 mA
Motorola General Business Use
Page 8 of 36
