Motorola Commercial CM Series - Page 63

UHF 1-25W PCB 8486684Z01 (Rev.O) / Schematics 4-23
L103 2462587T30 IND CHIP 1000NH 5% LOW PRO
L104 2462587N50 CHIP IND 56 NH 5%
L105 2462587N44 CHIP IND 18 NH 5%
L107 2460591B04 COIL AIR WOUND INDUC 11.03
L108 2462587T22 IND. CHIP 390NH 5% LOW PRO
L111 2460592A01 COIL AW 2 TURN 17 NH
L113 2460592A01 COIL AW 2 TURN 17 NH
L114 2485873L01 ENCAPSULATED AIR WOUND
COIL
L115 2485873L01 ENCAPSULATED AIR WOUND
COIL
L117 7686135U02 FLTR,EMI
L118 7686135U02 FLTR,EMI
L119 7686135U02 FLTR,EMI
L120 7686135U02 FLTR,EMI
L121 7686135U02 FLTR,EMI
L122 2460591A01 COIL AIR WOUND INDUC 4.22
L126 2462587T22 IND. CHIP 390NH 5% LOW PRO
L200 2462587Q42 IND CHIP 390NH 10%
L201 2462587V44 IND CHIP 680 NH 10%
L202 2462587V44 IND CHIP 680 NH 10%
L203 2462587V36 CHIP IND 150NH 5% 0805
L204 2462587V36 CHIP IND 150NH 5% 0805
L205 2462587Q47 IND CHIP 1000 NH 10%
L206 2484562T11 COIL SURF MNT AIR WOUND
L207 2413923C12 IND CHIP 7.8 NH 2%
L208 2413926N24 IND CER CHIP 100.0 NH 5%
L209 2413926N24 IND CER CHIP 100.0 NH 5%
L210 2413926H20 IND CHIP 47.0 NH 5%
L211 2413926N24 IND CER CHIP 100.0 NH 5%
L212 2413926N18 IND CER CHIP 33.0 NH 5%
L213 2413926N24 IND CER CHIP 100.0 NH 5%
L214 2413926H20 IND CHIP 47.0 NH 5%
Circuit
Ref.
Motorola
Part No.
Description
L215 2413926H20 IND CHIP 47.0 NH 5%
L216 2462587N44 CHIP IND 18 NH 5%
L217 2462587Q42 IND CHIP 390NH 10%
L300 2460591C35 COIL AIR WOUND INDUC 18.08
L301 2462587N55 CHIP IND 150 NH 5%
L302 2462587N55 CHIP IND 150 NH 5%
L303 2462587X69 IND CHIP LO-PRO 1200 NH 5%
L304 2462587N55 CHIP IND 150 NH 5%
L305 2483411T74 INDUCTOR CHIP SHIELDED
L306 2413926K31 IND CER CHIP 470.0 NH 5%
L307 2460591C35 COIL AIR WOUND INDUC 18.08
L308 2460591C35 COIL AIR WOUND INDUC 18.08
L309 2460591C35 COIL AIR WOUND INDUC 18.08
L310 2460591C35 COIL AIR WOUND INDUC 18.08
L311 2460591C35 COIL AIR WOUND INDUC 18.08
L312 2460591C35 COIL AIR WOUND INDUC 18.08
L313 2460591C35 COIL AIR WOUND INDUC 18.08
L314 2460591C35 COIL AIR WOUND INDUC 18.08
L315 2462587N68 CHIP IND 1000 NH 5%
L500 7686135U02 FLTR,EMI
L501 7686135U02 FLTR,EMI
L502 7686135U02 FLTR,EMI
M100 2680499Z01 HEAT SPREADER
M105 7588823L03 PAD GROUND LCD
M106 7588823L03 PAD GROUND LCD
M107 7588823L03 PAD GROUND LCD
M108 7588823L04 PAD GROUND LCD
M109 7588823L04 PAD GROUND LCD
M110 7588823L04 PAD GROUND LCD
M111 NOT PLACED GCAM DUMMY PART NUMBER
M112 NOT PLACED GCAM DUMMY PART NUMBER
M113 3985994A01 CONTACT, PCB SPEAKER
Circuit
Ref.
Motorola
Part No.
Description
M114 3985994A01 CONTACT, PCB SPEAKER
M9 0289511U01 NUTS
P1 2804503J01 CONNECTOR,ACCY 16 PIN
P2 NOT PLACED GCAM DUMMY PART NUMBER
Q100 4886163B01 LDMOS SMT 35W 520MH 12V
Q101 4813824A10 TSTR NPN 40V .2A GEN PURP
Q102 4813824A10 TSTR NPN 40V .2A GEN PURP
Q103 4813824A06 XSTR NPN 30V DARLINGTON
Q105 4886212B01 LDMOS PWR TSTR MRF1518
Q106 4805128M27 SOT TRANS
Q200 4802245J95 BJT, NPN TRANSISTOR
Q201 4809939C04 TSTR DUAL PNP/NPN UMC3
Q300 4809940E02 TSTR DIG NPN DTC114YE
Q301 4813824A17 XSTR PNP40V .2A GENPB=100-
300
Q302 4813824A10 TSTR NPN 40V .2A GEN PURP
Q303 4802245J95 BJT, NPN TRANSISTOR
Q304 4809939C04 TSTR DUAL PNP/NPN UMC3
Q305 4802197J95 RF TRANSISTOR PBR941
Q306 4813824A17 XSTR PNP40V .2A GENPB=100-
300
Q400 4809940E02 TSTR DIG NPN DTC114YE
Q401 4880141L03 QSTR PNP SOT23 LO PROFILE
TAPE
Q403 4809940E02 TSTR DIG NPN DTC114YE
Q404 4809940E02 TSTR DIG NPN DTC114YE
Q405 4809940E02 TSTR DIG NPN DTC114YE
Q407 4809940E02 TSTR DIG NPN DTC114YE
Q408 4880048M01 TSTR NPN DIG 47K/47K
Q409 4880048M01 TSTR NPN DIG 47K/47K
Q410 4880048M01 TSTR NPN DIG 47K/47K
Q411 4880048M01 TSTR NPN DIG 47K/47K
Q412 4880048M01 TSTR NPN DIG 47K/47K
Circuit
Ref.
Motorola
Part No.
Description
Q413 4809940E02 TSTR DIG NPN DTC114YE
Q414 4809940E02 TSTR DIG NPN DTC114YE
Q415 NOT PLACED GCAM DUMMY PART NUMBER
Q416 4809940E02 TSTR DIG NPN DTC114YE
Q417 4813824A10 TSTR NPN 40V .2A GEN PURP
Q500 4813824A10 TSTR NPN 40V .2A GEN PURP
Q501 4809940E02 TSTR DIG NPN DTC114YE
Q502 4809940E02 TSTR DIG NPN DTC114YE
Q503 4813824A10 TSTR NPN 40V .2A GEN PURP
Q504 4880048M01 TSTR NPN DIG 47K/47K
Q505 4813824A10 TSTR NPN 40V .2A GEN PURP
Q506 4813824A10 TSTR NPN 40V .2A GEN PURP
R103 0683962T51 RES CHIP 120 5-1
R104 0662057A41 CHIP RES 470 OHMS 5%
R106 0680194M18 RES 51 OHMS 5% 1W
R107 0680194M18 RES 51 OHMS 5% 1W
R108 0680194M18 RES 51 OHMS 5% 1W
R109 0662057A14 RES CHIP 36 OHM 5 1/8W
R117 0662057P02 RES. CHIP 15K 1% 30X60
R118 0662057C51 CHIP RES 100 OHMS 5%
R119 0662057C51 CHIP RES 100 OHMS 5%
R122 0662057C19 CHIP RES 4.7 OHMS 5%
R126 0662057C03 CHIP RES 1.0 OHMS 5%
R127 0662057C03 CHIP RES 1.0 OHMS 5%
R128 0662057C03 CHIP RES 1.0 OHMS 5%
R130 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R131 0662057A97 CHIP RES 100K OHMS 5%
R134 0662057A59 CHIP RES 2700 OHMS 5%
R135 0662057A88 CHIP RES 43K OHMS 5%
R136 0662057A86 CHIP RES 36K OHMS 5%
R137 0662057A87 CHIP RES 39K OHMS 5%
Circuit
Ref.
Motorola
Part No.
Description
