Motorola Commercial CM Series - Page 64

4-24 UHF 1-25W PCB 8486684Z01 (Rev.O) / Schematics
R138 0662057A86 CHIP RES 36K OHMS 5%
R139 0662057A87 CHIP RES 39K OHMS 5%
R140 0662057A83 CHIP RES 27K OHMS 5%
R141 0662057A81 CHIP RES 22K OHMS 5%
R142 0662057A81 CHIP RES 22K OHMS 5%
R143 0662057A81 CHIP RES 22K OHMS 5%
R145 0662057A81 CHIP RES 22K OHMS 5%
R147 0662057A59 CHIP RES 2700 OHMS 5%
R148 0662057A81 CHIP RES 22K OHMS 5%
R149 0662057A81 CHIP RES 22K OHMS 5%
R150 0662057A73 CHIP RES 10K OHMS 5%
R151 0662057A67 CHIP RES 5600 OHMS 5%
R153 0662057A73 CHIP RES 10K OHMS 5%
R155 0662057A73 CHIP RES 10K OHMS 5%
R156 0662057A73 CHIP RES 10K OHMS 5%
R157 0662057A91 CHIP RES 56K OHMS 5%
R158 0662057A69 RES CHIP 6800 OHM 5 1/8W
R159 NOT PLACED GCAM DUMMY PART NUMBER
R160 0662057A61 CHIP RES 3300 OHMS 5%
R161 0662057A61 CHIP RES 3300 OHMS 5%
R165 0662057A58 CHIP RES 2400 OHMS 5%
R166 0662057A59 CHIP RES 2700 OHMS 5%
R167 0662057A57 CHIP RES 2200 OHMS 5%
R168 0662057A57 CHIP RES 2200 OHMS 5%
R169 0662057A56 CHIP RES 2000 OHMS 5%
R170 0662057A42 CHIP RES 510 OHMS 5%
R171 0662057A43 CHIP RES 560 OHMS 5%
R172 0662057A41 CHIP RES 470 OHMS 5%
R173 0662057A29 CHIP RES 150 OHMS 5%
R174 0662057A29 CHIP RES 150 OHMS 5%
R175 0662057A43 CHIP RES 560 OHMS 5%
R178 0662057A18 CHIP RES 51 OHMS 5%
Circuit
Ref.
Motorola
Part No.
Description
R179 0662057A18 CHIP RES 51 OHMS 5%
R180 0660082A89 RES CHIP 47K OHMS 1% 1/16W
R181 0660082A89 RES CHIP 47K OHMS 1% 1/16W
R182 0662057A73 CHIP RES 10K OHMS 5%
R183 0662057A25 CHIP RES 100 OHMS 5%
R185 0662057A73 CHIP RES 10K OHMS 5%
R186 0662057C20 CHIP RES 5.1 OHMS 5%
R200 0662057A97 CHIP RES 100K OHMS 5%
R201 0662057A73 CHIP RES 10K OHMS 5%
R202 NOT PLACED GCAM DUMMY PART NUMBER
R203 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R204 NOT PLACED GCAM DUMMY PART NUMBER
R205 NOT PLACED GCAM DUMMY PART NUMBER
R206 0662057A99 CHIP RES 120K OHMS 5%
R207 0662057B02 CHIP RES 150K OHMS 5%
R208 0662057A97 CHIP RES 100K OHMS 5%
R209 0662057A97 CHIP RES 100K OHMS 5%
R210 NOT PLACED GCAM DUMMY PART NUMBER
R211 0662057A69 RES CHIP 6800 OHM 5 1/8W
R212 0662057A89 CHIP RES 47K OHMS 5%
R213 0662057A65 CHIP RES 4700 OHMS 5%
R214 0662057A65 CHIP RES 4700 OHMS 5%
R215 0662057A62 CHIP RES 3600 OHMS 5%
R216 0662057A59 CHIP RES 2700 OHMS 5%
R217 0662057A52 CHIP RES 1300OHMS 5%05
R218 0662057A49 CHIP RES 1000 OHMS 5%
R219 NOT PLACED GCAM DUMMY PART NUMBER
R220 0662057A42 CHIP RES 510 OHMS 5%
R221 0662057A33 CHIP RES 220 OHMS 5%
R222 0662057A33 CHIP RES 220 OHMS 5%
R223 0662057A33 CHIP RES 220 OHMS 5%
Circuit
Ref.
Motorola
Part No.
Description
R224 0662057A53 CHIP RES 1500 OHMS 5%
R225 0662057A29 CHIP RES 150 OHMS 5%
R226 0662057A29 CHIP RES 150 OHMS 5%
R227 0662057A23 CHIP RES 82 OHMS 5%
R228 0662057A25 CHIP RES 100 OHMS 5%
R229 0662057A25 CHIP RES 100 OHMS 5%
R230 0662057A22 CHIP RES 75 OHMS 5%
R231 0662057A18 CHIP RES 51 OHMS 5%
R232 0662057A17 RES CHIP 47 OHMS 5%
R233 0662057A17 RES CHIP 47 OHMS 5%
R234 0662057A15 CHIP RES 39 OHMS 5%
R235 0662057A07 CHIP RES 18 OHMS 5%
R300 0662057A73 CHIP RES 10K OHMS 5%
R301 0662057A41 CHIP RES 470 OHMS 5%
R302 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R303 NOT PLACED GCAM DUMMY PART NUMBER
R304 0662057A85 CHIP RES 33K OHM 5%
R305 0662057A80 CHIP RES 20K OHMS 5%
R306 0662057A80 CHIP RES 20K OHMS 5%
R307 0662057A80 CHIP RES 20K OHMS 5%
R308 0662057A80 CHIP RES 20K OHMS 5%
R309 0662057A77 CHIP RES 15K OHMS 5%
R310 0662057A77 CHIP RES 15K OHMS 5%
R311 0662057A49 CHIP RES 1000 OHMS 5%
R312 0662057A76 CHIP RES 13K OHMS 5%
R313 0662057A75 CHIP RES 12K OHMS 5%
R314 0662057A75 CHIP RES 12K OHMS 5%
R315 0662057A75 CHIP RES 12K OHMS 5%
R316 0662057A75 CHIP RES 12K OHMS 5%
R317 0662057A75 CHIP RES 12K OHMS 5%
R318 0662057A75 CHIP RES 12K OHMS 5%
Circuit
Ref.
Motorola
Part No.
Description
R319 0662057A75 CHIP RES 12K OHMS 5%
R320 0662057A73 CHIP RES 10K OHMS 5%
R321 0662057A71 CHIP RES 8200 OHMS 5%
R322 0662057A65 CHIP RES 4700 OHMS 5%
R323 0662057A65 CHIP RES 4700 OHMS 5%
R324 0662057A61 CHIP RES 3300 OHMS 5%
R325 0662057A61 CHIP RES 3300 OHMS 5%
R326 0662057A59 CHIP RES 2700 OHMS 5%
R327 0662057A58 CHIP RES 2400 OHMS 5%
R328 0662057A55 CHIP RES 1800 OHM 5%
R329 0662057A51 CHIP RES 1200 OHMS 5%
R330 0662057A47 CHIP RES 820 OHMS 5%
R331 0662057A25 CHIP RES 100 OHMS 5%
R332 0662057A45 CHIP RES 680 OHMS 5%
R333 0662057A43 CHIP RES 560 OHMS 5%
R334 0662057A40 CHIP RES 430 OHMS 5%
R335 0662057A39 CHIP RES 390 OHMS 5%
R336 0662057A33 CHIP RES 220 OHMS 5%
R337 0662057A25 CHIP RES 100 OHMS 5%
R338 0662057A25 CHIP RES 100 OHMS 5%
R339 0662057A18 CHIP RES 51 OHMS 5%
R340 0662057A18 CHIP RES 51 OHMS 5%
R345 0662057A73 CHIP RES 10K OHMS 5%
R346 0662057A73 CHIP RES 10K OHMS 5%
R347 0662057A05 CHIP RES 15 OHMS 5%
R401 0662057C85 CHIP RES 2700 OHMS 5%
R402 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R403 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R404 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
Circuit
Ref.
Motorola
Part No.
Description
