Motorola Commercial CM Series - Page 65

UHF 1-25W PCB 8486684Z01 (Rev.O) / Schematics 4-25
R405 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R406 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R407 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R414 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R415 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
(CM340/CM360)
R421 0662057A33 CHIP RES 220 OHMS 5%
R422 0662057A73 CHIP RES 10K OHMS 5%
(CM140/CM160)
R423 NOT PLACED GCAM DUMMY PART NUMBER
R424 NOT PLACED GCAM DUMMY PART NUMBER
R425 0662057A97 CHIP RES 100K OHMS 5%
R426 0662057A97 CHIP RES 100K OHMS 5%
(CM140/CM160)
R427 NOT PLACED GCAM DUMMY PART NUMBER
R428 0662057A97 CHIP RES 100K OHMS 5%
R429 0662057A97 CHIP RES 100K OHMS 5%
R430 0662057A87 CHIP RES 39K OHMS 5%
R431 NOT PLACED GCAM DUMMY PART NUMBER
R432 0662057A85 CHIP RES 33K OHM 5%
R433 0662057A85 CHIP RES 33K OHM 5%
R434 0662057A85 CHIP RES 33K OHM 5%
R435 0662057A85 CHIP RES 33K OHM 5%
R436 0662057A85 CHIP RES 33K OHM 5%
R438 0662057A73 CHIP RES 10K OHMS 5%
R439 0662057A73 CHIP RES 10K OHMS 5%
R440 0662057A73 CHIP RES 10K OHMS 5%
R441 0662057A73 CHIP RES 10K OHMS 5%
R442 0662057A73 CHIP RES 10K OHMS 5%
R443 0662057A61 CHIP RES 3300 OHMS 5%
Circuit
Ref.
Motorola
Part No.
Description
R444 0662057A73 CHIP RES 10K OHMS 5%
R445 0662057A73 CHIP RES 10K OHMS 5%
R450 0662057A73 CHIP RES 10K OHMS 5%
R451 0662057A73 CHIP RES 10K OHMS 5%
R453 0662057A61 CHIP RES 3300 OHMS 5%
R454 0662057A61 CHIP RES 3300 OHMS 5%
R455 0662057A61 CHIP RES 3300 OHMS 5%
R456 0662057A61 CHIP RES 3300 OHMS 5%
R457 0662057A61 CHIP RES 3300 OHMS 5%
R458 0662057A61 CHIP RES 3300 OHMS 5%
R459 NOT PLACED GCAM DUMMY PART NUMBER
R460 0662057A53 CHIP RES 1500 OHMS 5%
R461 0662057A33 CHIP RES 220 OHMS 5%
R462 0662057A18 CHIP RES 51 OHMS 5%
R463 0662057A73 CHIP RES 10K OHMS 5%
R466 NOT PLACED GCAM DUMMY PART NUMBER
R467 NOT PLACED GCAM DUMMY PART NUMBER
R468 NOT PLACED GCAM DUMMY PART NUMBER
R469 NOT PLACED GCAM DUMMY PART NUMBER
R470 0662057A73 CHIP RES 10K OHMS 5%
(CM340/CM360)
R471 0662057A01 CHIP RES 10 OHMS 5%
R472 NOT PLACED GCAM DUMMY PART NUMBER
R473 NOT PLACED GCAM DUMMY PART NUMBER
R5000 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R5001 0662057T68 RES CHIP 1.0K 1% 30*60
R5002 0662057C01 CHIP RES 0 OHMS .050 OHMS
(CM160/CM360)
R5008 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R5009 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
Circuit
Ref.
Motorola
Part No.
Description
R5010 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R5011 NOT PLACED GCAM DUMMY PART NUMBER
R5013 NOT PLACED GCAM DUMMY PART NUMBER
R5014 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R5016 NOT PLACED GCAM DUMMY PART NUMBER
R5017 0609887C05 RES CHIP 1.5 OHM 1/2W 2010
R5018 0609887C05 RES CHIP 1.5 OHM 1/2W 2010
R5019 0662057B05 CHIP RES 200K OHMS 5%
R5020 0662057B02 CHIP RES 150K OHMS 5%
R5021 0662057A97 CHIP RES 100K OHMS 5%
R5022 0662057A97 CHIP RES 100K OHMS 5%
R5023 0662057A97 CHIP RES 100K OHMS 5%
R5024 0662057A97 CHIP RES 100K OHMS 5%
(CM160/CM360)
R5025 0662057A97 CHIP RES 100K OHMS 5%
R5026 0662057A85 CHIP RES 33K OHM 5%
R5027 0662057B08 CHIP RES 270K OHMS 5%
R5028 0662057A97 CHIP RES 100K OHMS 5%
R5029 0662057A97 CHIP RES 100K OHMS 5%
R5030 0662057A85 CHIP RES 33K OHM 5%
R5031 0662057A92 CHIP RES 62K OHMS 5%
R5032 0662057A89 CHIP RES 47K OHMS 5%
R5033 0662057A89 CHIP RES 47K OHMS 5%
R5034 0662057A86 CHIP RES 36K OHMS 5%
R5035 0662057A89 CHIP RES 47K OHMS 5%
R5036 0662057A89 CHIP RES 47K OHMS 5%
R5037 0662057A73 CHIP RES 10K OHMS 5%
R5038 0662057A85 CHIP RES 33K OHM 5%
R5039 0662057A97 CHIP RES 100K OHMS 5%
R5040 0662057A84 CHIP RES 30K OHMS 5%
R5041 0662057A82 CHIP RES 24K OHMS 5%
Circuit
Ref.
Motorola
Part No.
Description
R5042 0662057A82 CHIP RES 24K OHMS 5%
R5043 0662057A82 CHIP RES 24K OHMS 5%
R5044 0662057A82 CHIP RES 24K OHMS 5%
R5045 0662057A85 CHIP RES 33K OHM 5%
R5046 0662057A82 CHIP RES 24K OHMS 5%
R5047 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
(CM140/CM340)
R5048 0662057A82 CHIP RES 24K OHMS 5%
R5049 0662057A77 CHIP RES 15K OHMS 5%
R5050 0662057A76 CHIP RES 13K OHMS 5%
R5051 0662057A75 CHIP RES 12K OHMS 5%
R5052 0662057A73 CHIP RES 10K OHMS 5%
R5053 0662057A73 CHIP RES 10K OHMS 5%
R5054 0662057A73 CHIP RES 10K OHMS 5%
R5055 0662057A73 CHIP RES 10K OHMS 5%
R5056 0662057A73 CHIP RES 10K OHMS 5%
R5057 0662057A73 CHIP RES 10K OHMS 5%
R5058 NOT PLACED GCAM DUMMY PART NUMBER
R5059 NOT PLACED GCAM DUMMY PART NUMBER
R5060 0662057A73 CHIP RES 10K OHMS 5%
R5061 0662057A73 CHIP RES 10K OHMS 5%
R5062 0662057A73 CHIP RES 10K OHMS 5%
R5063 NOT PLACED GCAM DUMMY PART NUMBER
R5064 NOT PLACED GCAM DUMMY PART NUMBER
R5065 0662057A68 CHIP RES 6200 OHMS 5%
R5066 0662057A49 CHIP RES 1000 OHMS 5%
R5067 NOT PLACED GCAM DUMMY PART NUMBER
R5068 NOT PLACED GCAM DUMMY PART NUMBER
R5069 0662057A73 CHIP RES 10K OHMS 5%
R5070 0662057A57 CHIP RES 2200 OHMS 5%
R5071 0662057A57 CHIP RES 2200 OHMS 5%
R5072 0662057A65 CHIP RES 4700 OHMS 5%
Circuit
Ref.
Motorola
Part No.
Description
