Motorola CP040

3-32 VHF1 PCB 8486769Z04-C/Z05-D Parts List
C301 2113945A04 CAP, 390pF
C302 2113945A04 CAP, 390pF
C303 2313960F04 CAP, 33uF
C304 2113945B02 CAP, 10000pF
C305 2113944A40 CAP, 100pF
C306 2113945L49 CAP, 1000pF
C310 2113945B02 CAP, 10000pF
C311 2113743E05 CAP, 0.18uF
C312 2313960D07 CAP, 10uF
C313 2113945B02 CAP, 10000pF
C314 2113945A60 CAP, 1200pF
C315 2113945A60 CAP, 1200pF
C316 2113945A60 CAP, 1200pF
C320 2113743E05 CAP, 0.18uF
C321 2313960D07 CAP, 10uF
C322 2113945B02 CAP, 10000pF
C323 2113944A42 CAP, 150pF
C331 2113945B02 CAP, 10000pF
C333 2113945B02 CAP, 10000pF
C334 2313960D07 CAP, 10uF
C400 Not_Placed -
C401 2113946K02 CAP, 100000pF
C402 2113945A09 CAP, 1000pF
C403 2113944A40 CAP, 100pF
C404 2113945A09 CAP, 1000pF
C405 2113944A40 CAP, 100pF
C406 2113944A40 CAP, 100pF
C407 2113945A09 CAP, 1000pF
C408 2113945A09 CAP, 1000pF
C409 2113945A09 CAP, 1000pF
C410 2313960D07 CAP, 10uF
C411 2113946K02 CAP, 100000pF
C412 2113945A09 CAP, 1000pF
C413 2113946K02 CAP, 100000pF
C414 2113946K02 CAP, 100000pF
C415 2113945A09 CAP, 1000pF
C416 2113945A09 CAP, 1000pF
C417 2113945A09 CAP, 1000pF
C418 2113946K02 CAP, 100000pF
C419 2113945A09 CAP, 1000pF
C420 2113945B02 CAP, 10000pF
C421 2113945B02 CAP, 10000pF
C422 2113945B02 CAP, 10000pF
C425 2113946E02 CAP, 1uF
Circuit
Ref
Motorola
Part No.
Description
C426 2313960B01 CAP, 1uF
C430 2113946K02 CAP, 100000pF
C431 2113945A09 CAP, 1000pF
C432 2113946K02 CAP, 100000pF
C433 2113945A09 CAP, 1000pF
C440 2113945B02 CAP, 10000pF
C441 2113945B02 CAP, 10000pF
C442 2113945B02 CAP, 10000pF
C443 2113945B02 CAP, 10000pF
C444 2113945B02 CAP, 10000pF
C445 2113945B02 CAP, 10000pF
C446 2113945B02 CAP, 10000pF
C447 2113946K02 CAP, 100000pF
C451 2113946K02 CAP, 100000pF
C452 2113945C31 CAP, 0.10uF
C453 2313960B30 CAP, 4.7pF
C454 2113945C31 CAP, 0.10uF
C455 2113945B04 CAP, 22000pF
C456 2113945C31 CAP, 0.10uF
C457 2113945C31 CAP, 0.10uF
C458 2113945C31 CAP, 0.10uF
C459 2113945C31 CAP, 0.10uF
C460 2113945C31 CAP, 0.10uF
C461 2113946F03 CAP, 4.7uF
C462 2113945C31 CAP, 0.10uF
C463 2113945C31 CAP, 0.10uF
C464 2113945C31 CAP, 0.10uF
C465 2113945A09 CAP, 1000pF
C466 Not_Placed -
C467 2113945A60 CAP, 1200pF
C470 2113945C31 CAP, 0.10uF
C471 2113946N03 CAP, 2.2uF
C472 2113945C31 CAP, 0.10uF
C473 2113944A42 CAP, 150pF
C474 2113944A42 CAP, 150pF
C475 2113945B04 CAP, 22000pF
C476 2113945B04 CAP, 22000pF
C477 2113946K02 CAP, 100000pF
C478 2113944A42 CAP, 150pF
C479 2113944A42 CAP, 150pF
C480 2113945C31 CAP, 0.10uF
C481 Not_Placed -
C482 Not_Placed -
C483 2113946C02 CAP, 0.22uF
Circuit
Ref
Motorola
Part No.
Description
C484 Not_Placed -
C488 2113945A05 CAP, 470pF
C489 2113945A05 CAP, 470pF
C490 2113945A05 CAP, 470pF
C492 2113928J08 CAP, 10uF
C493 2113945A09 CAP, 1000pF
C494 2113946N03 CAP, 2.2uF
C495 2113946N02 CAP, 1uF
C496 2113946N02 CAP, 1uF
C497 2113945C31 CAP, 0.10uF
C498 2113946N02 CAP, 1uF
C499 2113944A32 CAP, 39pF
C500 2113945A09 CAP, 1000pF
C501 2113946N02 CAP, 1uF
C503 2113945A09 CAP, 1000pF
C504 2113945A09 CAP, 1000pF
C505 2113945A09 CAP, 1000pF
C506 2113945A09 CAP, 1000pF
C507 2113945A09 CAP, 1000pF
C511 2113944C02 CAP, 220pF
C512 2113944A21 CAP, 6.8pF
C513 2113944C02 CAP, 220pF
C514 2113944A79 CAP, 16pF
C518 2113945C31 CAP, 0.10uF
C519 2113946N02 CAP, 1uF
CR1 4813974A19 Diode Schottky
CR41 4815923H01 Diode Schottky
CR51 4813974A19 Diode Schottky
D51 4815047H01 Switching Diode
D52 4815047H01 Switching Diode
D120 4880973Z02 Pin Diode
D121 4880973Z02 Pin Diode
D201 4815072H01 Diode Varactor
D220 4815011H01 Diode Triple
D221 4815011H01 Diode Triple
D251 4813974A01 ISV 228
D261 4813974A01 ISV 228
D262 4885055Y01 Diode Varactor
D301 4815713H01 Diode Schottky
D414 4816064H01 RH29M19 LH
D424 4809924D29 Diode High Voltage
D425 4816064H01 RH29M19 LH
D440 4805729G49 Diode Red/Yel
D470 4809924D29 Diode High Voltage
Circuit
Ref
Motorola
Part No.
Description
D471 4809924D29 Diode High Voltage
D491 Not_Placed -
E451 2480640Z01 Ferrite Bead
E452 2480640Z01 Ferrite Bead
E453 2480640Z01 Ferrite Bead
E500 2480640Z01 Ferrite Bead
F301 6515076H01 Fuse Chip SMT
FL51 9186801Z01 OSC,XTAL 44.85MHZ
FL52 9180468V04 4 Element FLTR
FL53 9180469V05 6 Element FLTR
FL54 9115811H01 6 Element FLTR
J140 0986428Z02 RF Jack
J301 0986565Z02 Battery CONN
J460 Not_Placed -
J470 0985818A02 CONN 2 Pin
J471 0980683Z03 Audio Jack
J491 2815162H01 CONN_P
L1 2414015C09 INDCTR, 68nH
L2 2414015C09 INDCTR, 68nH
L3 2414015C09 INDCTR, 68nH
L4 2414015C09 INDCTR, 68nH
L21 Not_Placed -
L22 2414017N24 INDCTR, 100nH
L31 2414015C09 INDCTR, 68nH
L32 2414015C09 INDCTR, 68nH
L33 2414015C09 INDCTR, 68nH
L40 2414015C09 INDCTR, 68nH
L41 2414015C09 INDCTR, 68nH
L51 2414017N26 INDCTR, 150nH
L52 2462587V43 INDCTR, 560nH
L53 2113944A41 CAP, 120 pF
L54 2414015A25 INDCTR, 1200nH
L81 2414015A19 INDCTR, 1000nH
L100 2414017K32 INDCTR, 560nH
L101 2414017K32 INDCTR, 560nH
L102 2415429H36 INDCTR, 100nH
L103 2415429H25 INDCTR, 30nH
L110 2414017K32 INDCTR, 560nH
L120 2414017K32 INDCTR, 560nH
L121 2415015H01 INDCTR, 47nH
L130 2479990N01 INDCTR, 43.67nH
L131 2479990N01 INDCTR, 43.67nH
L132 2479990N01 INDCTR, 43.67nH
L140 2479990M01 INDCTR, 30.54nH
Circuit
Ref
Motorola
Part No.
Description
