Motorola CP040

UHF3 PCB 8416847H01-A/H02-B Parts List 3-33
5.0 UHF3 PCB 8416847H01-A/H02-B
Parts List
Circuit
Ref
Motorola
Part No.
Description
C1 2115153H32 CAP, 8 pF
C2 2115153H26 CAP, 9.1 pF
C3 2115153H18 CAP, 4.3 pF
C4 2115153H27 CAP, 10 pF
C5 2115153H31 CAP, 7 pF
C6 2115153H24 CAP, 7.5 pF
C7 2115153H26 CAP, 9.1 pF
C8 2115153H18 CAP, 4.3 pF
C9 2115153H22 CAP, 6.2 pF
C10 2115153H13 CAP, 2.7 pF
C11 2113945A04 CAP, 390 pF
C12 NOTPLACED -
C13 2115153H07 CAP, 1.5 pF
C14 2115153H07 CAP, 1.5 pF
C20 2113945A04 CAP, 390 pF
C21 2115153H53 CAP, 68 pF
C23 2113945A04 CAP, 390 pF
C25 2113945A04 CAP, 390 pF
C26 2113945A04 CAP, 390 pF
C27 2115153H25 CAP, 8.2 pF
C28 2115153H27 CAP, 10 pF
C29 2115153H22 CAP, 6.2 pF
C30 2115153H38 CAP, 16 pF
C31 2115153H21 CAP, 5.6 pF
C32 2115153H22 CAP, 6.2 pF
C33 2115153H42 CAP, 24 pF
C34 2115153H22 CAP, 6.2 pF
C35 2115153H22 CAP, 6.2 pF
C36 2115153H39 CAP, 18 pF
C37 2115153H25 CAP, 8.2 pF
C38 2115153H20 CAP, 5.1 pF
C39 2115153H13 CAP, 2.7 pF
C41 2115153H27 CAP, 10 pF
C42 2115153H25 CAP, 8.2 pF
C43 2115153H40 CAP, 20 pF
C44 2115153H26 CAP, 9.1 pF
C45 2115153H37 CAP, 15 pF
C46 NOTPLACED -
C47 NOTPLACED -
C48 0613952R66 RES, 0
C49 NOTPLACED -
C51 2113944A38 CAP, 82 pF
C52 2115153H41 CAP, 22 pF
C53 2115153H26 CAP, 9.1 pF
C55 2113946K02 CAP, 100000 pF
C56 2113945C31 CAP, 10 uF
C57 2113946K02 CAP, 100000 pF
C58 2113944A15 CAP, 3.9 pF
C59 2113944A11 CAP, 2.7 pF
C60 2113946K02 CAP, 100000 pF
C61 2113944A36 CAP, 68 pF
C62 2113946K02 CAP, 100000 pF
C63 2113946K02 CAP, 100000 pF
C64 2113946K02 CAP, 100000 pF
C65 2113946K02 CAP, 100000 pF
C66 2113946K02 CAP, 100000 pF
C67 2113946K02 CAP, 100000 pF
C68 2113946K02 CAP, 100000 pF
C69 2113946K02 CAP, 100000 pF
C70 2113944A87 CAP, 130 pF
C71 2113945C31 CAP, 10 uF
C72 2113946K02 CAP, 100000 pF
C73 2113945A13 CAP, 4700 pF
C74 2113944A33 CAP, 47 pF
C80 2115153H41 CAP, 22 pF
C81 2115153H45 CAP, 33 pF
C82 2115153H46 CAP, 36 pF
C90 2113946K02 CAP, 100000 pF
C91 2313960D07 CAP, 10uF
C92 2113945C31 CAP, 10 uF
C93 NOTPLACED -
C99 2113946K02 CAP, 100000 pF
C100 2113945A04 CAP, 390 pF
C101 2113946K02 CAP, 100000 pF
C102 2113946K02 CAP, 100000 pF
C103 2113945A04 CAP, 390 pF
C104 2113944A21 CAP, 6.8 pF
C105 NOTPLACED -
C106 2113945A04 CAP, 390 pF
C107 NOTPLACED -
C108 2113945A04 CAP, 390 pF
C109 2113946K02 CAP, 100000 pF
C111 2113945A04 CAP, 390 pF
C112 2113946K02 CAP, 100000 pF
C113 2113945A04 CAP, 390 pF
Circuit
Ref
Motorola
Part No.
Description
C114 2113945A04 CAP, 390 pF
C115 2313960B01 CAP, 1 uF
C116 2113946K02 CAP, 100000 pF
C117 2113944C05 CAP, 390 pF
C120 NOTPLACED -
C121 2113945A04 CAP, 390 pF
C122 NOTPLACED -
C123 2113944C20 CAP, 3.9 pF
C124 2113944C05 CAP, 390 pF
C130 2113944C16 CAP, 2.7 pF
C131 NOTPLACED -
C132 2113944C73 CAP, 6.8 pF
C133 NOTPLACED -
C134 2113944C73 CAP, 6.8 pF
C135 NOTPLACED -
C136 2113944C21 CAP, 4.3 pF
C137 2113944C02 CAP, 220 pF
C141 2113944C63 CAP, 1 pF
C150 2113945A04 CAP, 390 pF
C151 2113945A04 CAP, 390 pF
C152 2113945A04 CAP, 390 pF
C153 2113946L04 CAP, 0.47 uF
C154 2113945A04 CAP, 390 pF
C156 2113945B02 CAP, 10000 pF
C157 2113946K02 CAP, 100000 pF
C158 2113945A04 CAP, 390 pF
C159 2113945A04 CAP, 390 pF
C160 2113945C31 CAP, 10 uF
C170 2113945A04 CAP, 390 pF
C171 2113945A04 CAP, 390 pF
C172 2113945A04 CAP, 390 pF
C201 2113944C02 CAP, 220 pF
C202 2115153H52 CAP, 62 pF
C203 2115153H13 CAP, 2.7 pF
C204 2113945A05 CAP, 470 pF
C205 NOTPLACED -
C206 NOTPLACED -
C207 2113945A05 CAP, 470 pF
C208 2113945A05 CAP, 470 pF
C209 2113945A05 CAP, 470 pF
C210 2113945A05 CAP, 470 pF
C211 2113945C31 CAP, 10 uF
C212 2113946N03 CAP, 2.2 uF
C213 2113945B02 CAP, 10000 pF
Circuit
Ref
Motorola
Part No.
Description
C214 2113945A09 CAP, 1000 pF
C215 2113946N03 CAP, 2.2 uF
C216 2113945C31 CAP, 10 uF
C217 2113945A09 CAP, 1000 pF
C218 2113946N03 CAP, 2.2 uF
C219 2113945C31 CAP, 10 uF
C220 2113944A29 CAP, 22 pF
C221 2113945B02 CAP, 10000 pF
C222 2113945B02 CAP, 10000 pF
C223 2113945B02 CAP, 10000 pF
C224 2113945B02 CAP, 10000 pF
C225 2313960D07 CAP, 10uF
C226 2313960D07 CAP, 10uF
C227 2113945A09 CAP, 1000 pF
C228 2113945C31 CAP, 10 uF
C230 2113946N03 CAP, 2.2 uF
C231 2113945A09 CAP, 1000 pF
C232 2113945C31 CAP, 10 uF
C233 2313960B30 CAP, 4.7 uF
C240 2115153H06 CAP, 1.3 pF
C241 2113944A40 CAP, 100 pF
C243 0886641Z01 CAP, .1uF
C244 0888600M25 CAP,
C245 2313960C26 CAP, 1 uF
C251 0888600M03 CAP,
C252 NOTPLACED -
C253 2115153H22 CAP, 6.2 pF
C254 2115153H15 CAP, 3.3 pF
C255 2115153H26 CAP, 9.1 pF
C256 2115153H17 CAP, 3.9 pF
C257 2115153H35 CAP, 12 pF
C263 2115153H22 CAP, 6.2 pF
C264 2115153H14 CAP, 3 pF
C265 2115153H21 CAP, 5.6 pF
C266 2115153H14 CAP, 3 pF
C267 2115153H26 CAP, 9.1 pF
C268 2115153H01 CAP, 0.5 pF
C270 2113945A04 CAP, 390 pF
C271 2113945A04 CAP, 390 pF
C272 2113945C31 CAP, 10 uF
C273 2113945B02 CAP, 10000 pF
C274 2113945C31 CAP, 10 uF
C275 2113945A04 CAP, 390 pF
C276 2115153H16 CAP, 3.6 pF
Circuit
Ref
Motorola
Part No.
Description
