VHF1 PCB 8486769Z04-C/Z05-D Parts List 3-31
5.0 VHF1 PCB 8486769Z04-C/Z05-D
Parts List
Circuit
Ref
Motorola
Part No.
Description
C1 2115153H43 CAP, 22pF
C2 2115153H48 CAP, 36pF
C3 2115153H49 CAP, 47pF
C4 2115153H39 CAP, 18pF
C5 2115153H15 CAP, 3.3
C6 2115153H41 CAP, 22pF
C7 2115153H45 CAP, 33pF
C8 2115153H44 CAP, 30pF
C9 Not_Placed -
C20 2113945A09 CAP, 1000pF
C22 2113945A09 CAP, 1000pF
C23 2113945A09 CAP, 1000pF
C24 Not_Placed -
C25 2113945A09 CAP, 1000pF
C26 2113945A09 CAP, 1000pF
C29 2115153H27 CAP, 10pF
C30 2115153H44 CAP, 30pF
C31 2115153H46 CAP, 36pF
C32 2115153H53 CAP, 68pF
C33 2115153H43 CAP, 27pF
C34 2115153H53 CAP, 68pF
C35 2115153H45 CAP, 33pF
C36 2115153H44 CAP, 30pF
C40 2115153H40 CAP, 20pF
C41 2115153H37 CAP, 15pF
C42 2115153H46 CAP, 36pF
C43 2115153H37 CAP, 15pF
C44 2115153H40 CAP, 20pF
C51 2113944A38 CAP, 82pF
C52 2115153H41 CAP, 22pF
C53 2115153H26 CAP, 9.1pF
C55 2113946K02 CAP, 100000pF
C56 2113945C31 CAP, 0.10uF
C57 2113946K02 CAP, 100000pF
C58 2113944A15 CAP, 25pF
C59 2113944A11 CAP, 2.7pF
C60 2113946K02 CAP, 100000pF
C61 2113944A36 CAP, 68pF
C62 2113946K02 CAP, 100000pF
C63 2113946K02 CAP, 100000pF
C64 2113946K02 CAP, 100000pF
C65 2113946K02 CAP, 100000pF
C66 2113946K02 CAP, 100000pF
C67 2113946K02 CAP, 100000pF
C68 2113946K02 CAP, 100000pF
C69 2113946K02 CAP, 100000pF
C70 2113944A87 CAP, 130pF
C71 2113945C31 CAP, 0.10uF
C72 2113946K02 CAP, 100000pF
C73 2113945A13 CAP, 4700pF
C74 2113944A33 CAP, 47pF
C80 2115153H41 CAP, 22pF
C81 2115153H45 CAP, 33pF
C82 2115153H46 CAP, 36pF
C90 2113946K02 CAP, 100000pF
C91 2313960D07 CAP, 10uF
C92 2113945C31 CAP, 0.10uF
C93 Not_Placed -
C99 2113946K02 CAP, 100000pF
C100 2113945A10 CAP, 1500pF
C101 2113945A10 CAP, 1500pF
C102 2113946K02 CAP, 100000pF
C103 2113945A10 CAP, 1500pF
C104 Not_Placed -
C105 Not_Placed -
C106 2113945A10 CAP, 1500pF
C107 2113944A25 CAP, 10pF
C108 2113946K02 CAP, 100000pF
C109 2113946K02 CAP, 100000pF
C110 2113946K02 CAP, 100000pF
C111 Not_Placed -
C112 2113945A10 CAP, 1500pF
C113 2113945A10 CAP, 1500pF
C114 2113945A10 CAP, 1500pF
C115 2313960B01 CAP, 1uF
C116 2113946K02 CAP, 100000pF
C117 2113945L25 CAP, 1000pF
C120 2113945A10 CAP, 1500pF
C121 2113945A10 CAP, 1500pF
C122 2113944C32 CAP, 15pF
C123 2113944C80 CAP, 20pF
C124 2113945A10 CAP, 1500pF
C130 2113944C32 CAP, 15pF
C131 2113944C30 CAP, 10pF
C132 2113944C32 CAP, 15pF
Circuit
Ref
Motorola
Part No.
Description
C133 2113944C15 CAP, 2.4pF
C134 2113944C78 CAP, 13pF
C135 2113944C30 CAP, 10pF
C136 2113944C72 CAP, 6.2pF
C137 2113944C89 CAP, 20pF0
C140 2113944C79 CAP, 16pF
C141 2113944C34 CAP, 22pF
C150 2113945A10 CAP, 1500pF
C151 2113945A10 CAP, 1500pF
C152 2113945A10 CAP, 1500pF
C153 2113946L04 CAP, 0.47uF
C154 2113945A10 CAP, 1500pF
C155 2113945C31 CAP, 0.10uF
C156 2113945B02 CAP, 10000pF
C157 2113946K02 CAP, 100000pF
C158 2113945A10 CAP, 1500pF
C159 2113945A10 CAP, 1500pF
C170 2113946K02 CAP, 100000pF
C171 2113944A11 CAP, 2.7pF
C172 2113945A10 CAP, 1500pF
C201 2113944C02 CAP, 220pF
C202 2115153H52 CAP, 68pF
C203 2115153H13 CAP, 2.7pF
C204 2113945A05 CAP, 470pF
C205 Not_Placed -
C206 Not_Placed -
C207 2113945A05 CAP, 470pF
C208 2113945A05 CAP, 470pF
C209 2113945A05 CAP, 470pF
C210 2113945A05 CAP, 470pF
C211 2113945C31 CAP, 0.10uF
C212 2113946N03 CAP, 2.2uF
C213 2113945B02 CAP, 10000pF
C214 2113945A09 CAP, 1000pF
C215 2113946N03 CAP, 2.2uF
C216 2113945C31 CAP, 0.10uF
C217 2113945A09 CAP, 1000pF
C218 2113946N03 CAP, 2.2uF
C219 2113945C31 CAP, 0.10uF
C220 2113944A29 CAP, 22pF
C221 2113945B02 CAP, 10000pF
C222 2113945B02 CAP, 10000pF
C223 2113945B02 CAP, 10000pF
C224 2113945B02 CAP, 10000pF
Circuit
Ref
Motorola
Part No.
Description
C225 2313960D07 CAP, 10uF
C226 2313960D07 CAP, 10uF
C227 2113945A09 CAP, 1000pF
C228 2113945C31 CAP, 0.10uF
C230 2113946N03 CAP, 2.2uF
C231 2113945A09 CAP, 1000pF
C232 2113945C31 CAP, 0.10uF
C233 2313960B30 CAP, 4.7pF
C241 2113945A60 CAP, 1200pF
C243 2113945G91 CAP, 100000pF
C244 2113945L27 CAP, 1200pF
C245 2313960C26 KEMET CAP
C251 2113945L49 CAP, 1000pF
C253 2115153H38 CAP, 16pF
C254 2115153H30 CAP, 6pF
C255 2115153H39 CAP, 18pF
C256 2115153H27 CAP, 10pF
C257 2115153H46 CAP, 36pF
C258 2113945A60 CAP, 1200pF
C263 2115153H43 CAP, 27pF
C264 2115153H27 CAP, 10pF
C265 2115153H37 CAP, 15pF
C266 2115153H27 CAP, 10pF
C267 2115153H46 CAP, 36pF
C268 2115153H13 CAP, 2.7pF
C269 2113945A10 CAP, 1500pF
C270 2113945A60 CAP, 1200pF
C271 2113945B02 CAP, 10000pF
C272 2113945C31 CAP, 0.10uF
C273 2113945B02 CAP, 10000pF
C274 2113945C31 CAP, 0.10uF
C275 2113945A60 CAP, 1200pF
C276 2113944A18 CAP, 5.1pF
C277 2113945A60 CAP, 1200pF
C281 2113945A60 CAP, 1200pF
C282 2113944A24 CAP, 9.1pF
C283 2113945A60 CAP, 1200pF
C284 2113945A60 CAP, 1200pF
C285 2113945C31 CAP, 0.10uF
C286 2113944A77 CAP, 11pF
C290 2113944A85 CAP, 51pF
C291 2115153H48 CAP, 43pF
C292 2113945A60 CAP, 1200pF
C293 2113945A05 CAP, 470pF
Circuit
Ref
Motorola
Part No.
Description
