Motorola CP040

Chapter 3
SERVICE AIDS
1.0 Test Equipment
Table 3-1 lists test equipment recommended to service the radio and other two-way radios.
2.0 Service Aids
Table 3.2 lists the service aids recommended for working on the radio. While all of these items are
available from Motorola, most are standard workshop equipment items, and any equivalent item
capable of the same performance may be substituted for the item listed.
Table 3-1 Recommended Test Equipment
Motorola Part
No.
Description Application
R2600 Service Monitor Frequency/deviation meter and signal
generator for wide-range troubleshooting and alignment. Audio
voltage measurements, Transmitter power output measurements
and Receiver sensitivity measurements.
R1074 Digital Multimeter Two meters recommended for AC/DC voltage and
current measurements.
R1094 or
R1369
Oscilloscope Waveform Measurements
WADN4243 DC Power Supply Bench Supply for Vdc
Table 3-2 Service Aids
Motorola Part
No.
Description Application
RLN4460 Portable Test Set Enables connection to the audio/accessory jack.
Allows switching for radio testing.
RLN4510 Battery Interface Regulates DC current and voltage between radio and
power supply.
RVN4191 Customer Programming
Software (CPS) and Global
Tuner - Software on CD Rom
Program customer option and channel data.
PMKN4004 Programming Test Cable Connects radio to RIB (RLN4008).
PMKN4003 Radio to Radio Cloning Cable
Allows a radio to be duplicated from a master radio by
transferring programmed data from the master radio to
the other.
RLN4008 Radio Interface Box Enables communications between the radio and the
computer’s serial communications adapter.
