3-2 SERVICE AIDS
5886564Z01 RF Adaptor Adapts radio’s antenna port to BNC cabling of test
equipment.
0180305K08 Shop Battery Eliminator Interconnects radio to power supply.
EPN4040 Wall-Mounted Power Supply Used to supply power to the RIB (UK).
EPN4041 Wall-Mounted Power Supply Used to supply power to the RIB (Euro).
3080369B71 or
3080369B72
Computer Interface Cable Use B72 for the IBM PC AT or newer (9-pin serial
port). Use B71 for older models (25-pin serial port).
Connects the computer’s serial communications
adapter to the RIB (RLN4008).
6686533Z01 Knob Remover/Chassis Opener Used to remove the front cover assembly.
HKN9216 IBM Computer Interface Cable Connection from computer to RIB.
8180384N65 Housing Eliminator Allows testing of the radio outside of the housing.
RSX4043A TORX Screwdriver Used to remove and tighten chassis screws.
6680387A70 T6 TORX bit Removable TORX screwdriver bit.
WADN4055A Portable Soldering Station Digitally controlled soldering iron.
6604008K01 0.4mm Replacement Tip For WADN4055A Soldering iron.
6604008K01 0.8mm Replacement Tip For WADN4055A Soldering iron.
R1453A Digital readout solder station Digitally controlled soldering iron
RLN4062A Hot air workstation, 120 V Tool for hot air soldering/desoldering of surface
mounted integrated circuits
0180386A78 Illuminated magnifying glass with
lens attachment
Illumination and magnification of components
0180302E51 Master lens system
0180386A82 Anti-static Grounding Kit Used for all radio assembly/disassembly procedures.
6684253C72 Straight Prober
6680384A98 Brush
1010041A86 Solder (RMA type) 63/37, 0.5mm diameter, 1lb. spool.
0180303E45 SMD tool kit (included with
R1319A)
R1319A ChipMaster (110 V) Surface mount removal and assembly of surface
mounted integrated circuits and/or rework station
shields. Includes 5 nozzles.
R1321A ChipMaster (220 V)
Table 3-2 Service Aids
