Motorola CP040

3-34 UHF3 PCB 8416847H01-A/H02-B Parts List
C281 2113945A04 CAP, 390 pF
C282 2115153H18 CAP, 4.3 pF
C283 2113945A04 CAP, 390 pF
C284 2113945A04 CAP, 390 pF
C285 2113945C31 CAP, 10 uF
C286 2115153H17 CAP, 3.9 pF
C290 2115153H23 CAP, 6.8 pF
C291 2115153H36 CAP, 13 pF
C292 2113945A04 CAP, 390 pF
C293 2113945A05 CAP, 470 pF
C301 2113944A33 CAP, 47 pF
C302 2113945A04 CAP, 390 pF
C303 2313960F04 CAP, 33 uF
C304 2113945B02 CAP, 10000 pF
C305 2113944A40 CAP, 100 pF
C306 2113945L49 CAP, 10000 pF
C310 2113945B02 CAP, 10000 pF
C311 2113945C21 CAP, 18 uF
C312 2313960D07 CAP, 10uF
C313 2113945B02 CAP, 10000 pF
C314 2113945A60 CAP, 1200 pF
C315 2113945A60 CAP, 1200 pF
C316 2113945A60 CAP, 1200 pF
C320 2113945C21 CAP, 18 uF
C321 2313960D07 CAP, 10uF
C322 2113945B02 CAP, 10000 pF
C323 2113944A42 CAP, 150 pF
C331 2113945B02 CAP, 10000 pF
C333 2113945B02 CAP, 10000 pF
C334 2313960D07 CAP, 10uF
C400 NOTPLACED -
C401 2113946K02 CAP, 100000 pF
C402 2113945A09 CAP, 1000 pF
C403 2113944A40 CAP, 100 pF
C404 2113945A09 CAP, 1000 pF
C405 2113944A40 CAP, 100 pF
C406 2113944A40 CAP, 100 pF
C407 2113945A09 CAP, 1000 pF
C408 2113945A09 CAP, 1000 pF
C409 2113945A09 CAP, 1000 pF
C410 2313960D07 CAP, 10uF
C411 2113946K02 CAP, 100000 pF
C412 2113945A09 CAP, 1000 pF
C413 2113946K02 CAP, 100000 pF
Circuit
Ref
Motorola
Part No.
Description
C414 2113946K02 CAP, 100000 pF
C415 2113945A09 CAP, 1000 pF
C416 2113945A09 CAP, 1000 pF
C417 2113945A09 CAP, 1000 pF
C418 2113946K02 CAP, 100000 pF
C419 2113945A09 CAP, 1000 pF
C420 2113945B02 CAP, 10000 pF
C421 2113945B02 CAP, 10000 pF
C422 2113945B02 CAP, 10000 pF
C425 2113946E02 CAP, 1 uF
C426 2313960B01 CAP, 1 uF
C430 2113946K02 CAP, 100000 pF
C431 2113945A09 CAP, 1000 pF
C432 2113946K02 CAP, 100000 pF
C433 2113945A09 CAP, 1000 pF
C440 2113945B02 CAP, 10000 pF
C441 2113945B02 CAP, 10000 pF
C442 2113945B02 CAP, 10000 pF
C443 2113945B02 CAP, 10000 pF
C444 2113945B02 CAP, 10000 pF
C445 2113945B02 CAP, 10000 pF
C446 2113945B02 CAP, 10000 pF
C447 2113946K02 CAP, 100000 pF
C451 2113946K02 CAP, 100000 pF
C452 2185895Z01 CAP, 1 uF
C453 2313960B30 CAP, 4.7 uF
C454 2113945C31 CAP, 10 uF
C455 2113945B04 CAP, 22000 pF
C456 2113945C31 CAP, 10 uF
C457 2113945C31 CAP, 10 uF
C458 2113945C31 CAP, 10 uF
C459 2113945C31 CAP, 10 uF
C460 2113945C31 CAP, 10 uF
C461 2113946F03 CAP, 4.7 uF
C462 2113945C31 CAP, 10 uF
C463 2113945C31 CAP, 10 uF
C464 2113945C31 CAP, 10 uF
C465 2113945A09 CAP, 1000 pF
C466 NOTPLACED -
C467 2113945A60 CAP, 1200 pF
C470 2113945C31 CAP, 10 uF
C471 2113946N03 CAP, 2.2 uF
C472 2113945C31 CAP, 10 uF
C473 2113944A42 CAP, 150 pF
Circuit
Ref
Motorola
Part No.
Description
C474 2113944A42 CAP, 150 pF
C475 2113945B04 CAP, 22000 pF
C476 2113945B04 CAP, 22000 pF
C477 2113946K02 CAP, 100000 pF
C478 2113944A42 CAP, 150 pF
C479 2113944A42 CAP, 150 pF
C480 2113945C31 CAP, 10 uF
C481 NOTPLACED -
C482 NOTPLACED -
C483 2113945C31 CAP, 10 uF
C484 NOTPLACED -
C488 2113945A05 CAP, 470 pF
C489 2113945A05 CAP, 470 pF
C490 2113945A05 CAP, 470 pF
C492 2113955E37 CAP, 10 uF
C493 2113945A09 CAP, 1000 pF
C494 2113946N03 CAP, 2.2 uF
C495 2113946N02 CAP, 1 uF
C496 2113946N02 CAP, 1 uF
C497 2113945C31 CAP, 10 uF
C498 2113946N02 CAP, 1 uF
C499 2113944A38 CAP, 82 pF
C500 2113945A09 CAP, 1000 pF
C501 2113946N02 CAP, 1 uF
C503 2113945A09 CAP, 1000 pF
C504 2113945A09 CAP, 1000 pF
C505 2113945A09 CAP, 1000 pF
C506 2113945A09 CAP, 1000 pF
C507 2113945A09 CAP, 1000 pF
C511 2113944C02 CAP, 220 pF
C512 2113944A21 CAP, 6.8 pF
C513 2113944C02 CAP, 220 pF
C514 2113944A79 CAP, 16 pF
C518 2113945C31 CAP, 10 uF
C519 2113946N02 CAP, 1 uF
C521 2115153H13 CAP, 2.7 pF
C522 2113944A61 CAP, 0.5 pF
C523 2186463Z03 CAP, 0.5 uF
C524 2186463Z03 CAP, 0.5 uF
C525 2113945A04 CAP, 390 pF
CR1 4813974A19 DIODE SCHOTTKY
CR41 4815923H01 DIODE SCHOTTKY
CR51 4813974A19 DIODE SCHOTTKY
D51 4815047H01 DIODE SWITCHING
Circuit
Ref
Motorola
Part No.
Description
D52 4815047H01 DIODE SWITCHING
D120 4880973Z02 PIN DIODE
D121 4880973Z02 PIN DIODE
D122 4813978C06 DIODE SWITCHING
D201 4815072H01 DIODE VARACTOR
D220 4815011H01 DIODE TRIPLE
D221 4815011H01 DIODE TRIPLE
D251 4885055Y01 DIODE VARACTOR
D261 4885055Y01 DIODE VARACTOR
D262 4885055Y01 DIODE VARACTOR
D301 4815713H01 DIODE SCHOTTKY
D414 4805129M41 DIODE SCHOTTKY
D424 4809924D29 DIODE HIGH VOLTAGE
D425 4805129M41 DIODE SCHOTTKY
D440 4805729G49 DIODE RED/YEL
D470 4809924D29 DIODE HIGH VOLTAGE
D471 4809924D29 DIODE HIGH VOLTAGE
D491 NOTPLACED -
E451 2480640Z01 FERRITE BEAD
E452 2480640Z01 FERRITE BEAD
E453 2480640Z01 FERRITE BEAD
E500 2480640Z01 FERRITE BEAD
F301 6515076H01 FUSE SMT
FL51 9186801Z01 CRYSTAL OSC 44.85MHZ
FL52 9180468V04 4 ELEMENT FLTR
FL53 9115811H03 6 ELEMENT FLTR
FL54 9115811H01 6 ELEMENT FLTR
J140 0986428Z02 JACK, RF
J301 0986565Z02 BATTERY CONNECTOR
J460 NOTPLACED -
J470 0985818A02 CONN 2 PIN
J471 0980683Z03 AUDIO JACK
J491 2815162H01 CONN 1.25MM
L1 2415428H08 IND, 9.85 NH
L2 2415428H08 IND, 9.85 NH
L3 2415428H08 IND, 9.85 NH
L21 2414017N18 IND, 33 NH
L31 2415428H08 IND, 9.85 NH
L32 2415428H08 IND, 9.85 NH
L33 2415428H08 IND, 9.85 NH
L34 2415428H08 IND, 9.85 NH
L40 2414017K16 IND, 27 NH
L41 2414017K16 IND, 27 NH
L51 2414017N26 IND, 150 NH
Circuit
Ref
Motorola
Part No.
Description
