Motorola CP040

UHF3 PCB 8416847H01-A/H02-B Parts List 3-35
L52 2414032F43 IND, 560 NH
L53 2113944A41 CAP, 120 pF
L54 2414015A25 IND, 1200 NH
L55 2414017N16 IND, 22 NH
L81 2414015A19 IND, 1000 NH
L100 2414017K27 IND, 220 NH
L101 2414017K27 IND, 220 NH
L102 2415429H11 IND, 7.5 NH
L103 2415429H08 IND, 5.1 NH
L110 2414017K27 IND, 220 NH
L120 2414017K27 IND, 220 NH
L121 2414032F24 IND, 15 NH
L130 2460591C36 IND, 20.45 NH
L131 2460591C40 IND, 17.02 NH
L132 2460591C40 IND, 17.02 NH
L140 2460591L14 IND, 15.92 NH
L141 2479990M01 IND, 31 NH NH
L211 2414017K30 IND, 390 NH
L251 2414017N28 IND, 220 NH
L252 2414017N17 IND, 27 NH
L254 2415385H02 IND, 12.5 NH
L255 2414017N28 IND, 220 NH
L262 2414017N17 IND, 27 NH
L264 2415385H01 IND, 8.0 NH
L265 2414017N28 IND, 220 NH
L270 2414017N28 IND, 220 NH
L271 NOTPLACED -
L272 2414017N28 IND, 220 NH
L276 2414017N17 IND, 27 NH
L281 2414017N15 IND, 18 NH
L282 2414017N15 IND, 18 NH
L283 NOTPLACED -
L291 2414017N10 IND, 6.8 NH
L292 2414017N14 IND, 15 NH
L471 2414017K30 IND, 390 NH
M140 0286427Z02 NUT, ANTENNA
Q21 4802247J01 BJT, RF AMP, BFS505
Q22 4815267H01 TRANS DUAL PNP
Q51 4802197J95 RF TRANSISTOR
Q70 4813973M07 TSTR MMBT3904
Q100 4885593U03 TSTR NPN BFG540W
Q150 4813973M07 TSTR MMBT3904
Q170 4809939C34 TSTR DUAL PNP
Q171 4813973A42 TSTR NPN DIG
Circuit
Ref
Motorola
Part No.
Description
Q280 4802245J95 BJT, NPN TRANSISTOR
Q311 4815069H02 TSTR MOSFET P-CHAN
Q312 4815069H02 TSTR MOSFET P-CHAN
Q313 4815066H01 DIGITAL TRANSISTOR
Q402 4813973A42 TSTR NPN DIG
Q403 4813973A13 XSTR PNP40V
Q410 4815066H01 DIGITAL TRANSISTOR
Q425 4815069H02 TSTR MOSFET P-CHAN
Q426 4815069H02 TSTR MOSFET P-CHAN
Q427 4815069H02 TSTR MOSFET P-CHAN
Q440 4815154H01 DUAL TRANS NPNS
Q470 4815267H01 TRANS DUAL PNP
Q471 4815066H01 DIGITAL TRANSISTOR
Q472 4815267H01 TRANS DUAL PNP
Q481 NOTPLACED -
Q482 NOTPLACED -
Q490 4815066H01 DIGITAL TRANSISTOR
Q493 4815069H02 TSTR MOSFET P-CHAN
Q494 4815066H01 DIGITAL TRANSISTOR
Q520 4815154H01 DUAL TRANS NPNS
R20 0613952Q91 RES, 5600
R21 0613952Q48 RES, 91
R22 0613952Q91 RES, 5600
R23 0613952R11 RES, 27K
R24 0613952Q75 RES, 1200
R25 0613952Q91 RES, 5600
R40 0613952Q73 RES, 1000
R51 0613952Q42 RES, 51
R52 0613952R03 RES, 12K
R53 0613952R13 RES, 33K
R54 0613952Q90 RES,5100
R55 0613952Q61 RES, 330
R57 0613952Q89 RES, 4700
R60 0613952Q82 RES, 2400
R61 0613952R25 RES, 100K
R62 0613952Q85 RES, 3300
R63 0613952R15 RES, 39K
R64 0613952R08 RES, 20K
R65 0613952R15 RES, 39K
R66 0613952R08 RES, 20K
R67 0613952R08 RES, 20K
R72 0613952Q63 RES, 390
R73 0613952Q79 RES, 1800
R74 0613952Q75 RES, 1200
Circuit
Ref
Motorola
Part No.
Description
R75 0613952R03 RES, 12K
R76 0613952Z55 RES, 12K
R77 0613952Z53 RES, 8.2K
R78 0613952Q69 RES, 680
R80 0613952Q90 RES,5100
R81 0613952Q73 RES, 1000
R82 NOTPLACED -
R90 0613952Q42 RES, 51
R91 0613952Q78 RES, 1600
R100 0613952Q71 RES,820
R101 0613952Q19 RES, 5.6
R102 0613952Q71 RES,820
R103 0613952Q84 RES, 3000
R104 0613952H31 RES, 18
R105 0613952Q83 RES, 2700
R106 0613952Q89 RES, 4700
R107 NOTPLACED -
R110 0613952Q69 RES, 680
R111 0613952Q80 RES, 2000
R120 0613958H53 RES, 150
R121 0613958H53 RES, 150
R150 0680539Z01 RESISTOR, METAL STRIP
R151 0613952H39 RES, 39
R152 0613952P01 RES, 100K
R153 0613952P01 RES, 100K
R154 0613952P01 RES, 100K
R155 0613952P01 RES, 100K
R156 0613952Q61 RES, 330
R157 0613952Q81 RES, 2200
R158 0613952Q77 RES, 1500
R162 0613952R01 RES, 10K
R202 0613952R29 RES, 150K
R205 0613952Q49 RES, 100
R206 NOTPLACED -
R212 0613958J74 RES, 0 50
R220 0613952Q33 RES, 22
R221 0613952Q33 RES, 22
R223 0613952Q49 RES, 100
R227 0613952R15 RES, 39K
R230 0613952R08 RES, 20K
R243 0613952Q71 RES,820
R244 0613952Q42 RES, 51
R245 0613952Q77 RES, 1500
R246 0613952R25 RES, 100K
Circuit
Ref
Motorola
Part No.
Description
R247 0613952R07 RES, 18K
R253 0613952Q41 RES, 47
R254 0613952Q49 RES, 100
R255 0613952Z46 RES, 3.9K
R261 0613952R09 RES, 22K
R262 0613952Q94 RES, 7500
R263 0613952Q37 RES, 33
R264 0613952Q49 RES, 100
R271 0613952Q92 RES, 6200
R272 0613952Q92 RES, 6200
R273 0613952Q61 RES, 330
R274 0613952Q37 RES, 33
R275 0613952Q49 RES, 100
R276 NOTPLACED -
R277 0613952G67 RES, 0
R280 0613952Q89 RES, 4700
R281 0613952Q95 RES, 8200
R282 0613952Q72 RES, 910
R283 0613952Q52 RES, 130
R284 0613952Q69 RES, 680
R285 0613952R66 RES, 0
R310 0613952R25 RES, 100K
R311 0613952R25 RES, 100K
R312 0613952R08 RES, 20K
R313 0613952R01 RES, 10K
R320 0613952Z80 RES, 330K
R321 0613952P30 RES, 200K
R322 0613952R25 RES, 100K
R400 NOTPLACED -
R401 0613952R36 RES, 300K
R402 0613952R01 RES, 10K
R403 0613952R01 RES, 10K
R404 0613952R18 RES, 51K
R405 0613952R36 RES, 300K
R406 0613952R33 RES, 220K
R407 0613952R25 RES, 100K
R408 0613952R25 RES, 100K
R409 0613952Q73 RES, 1000
R410 0613952R01 RES, 10K
R411 0613952Q71 RES,820
R412 0613952R25 RES, 100K
R413 0613952R25 RES, 100K
R414 0613952R13 RES, 33K
R415 0613952R13 RES, 33K
Circuit
Ref
Motorola
Part No.
Description
