Motorola CP040

3-34 VHF1 PCB 8486769Z04-C/Z05-D Parts List
* Motorola Depot Servicing only
R433 0613952R25 RES, 100K
R434 Not_Placed -
R440 0613952Q89 RES, 4700
R441 0613952Q89 RES, 4700
R442 0613952H57 RES, 220
R443 0613952H51 CHIP RES 120
R445 0613952Q89 RES, 4700
R446 0613952R01 RES, 10K
R451 0613952R17 RES, 47K
R460 0613952R10 RES, 24K
R462 0613952R10 RES, 24K
R463 0613952R10 RES, 24K
R464 0613952R12 RES, 30K
R469 0613952Q25 RES, 10
R470 0613952Q81 RES, 2200
R471 0613952Q81 RES, 2200
R472 0613952Q69 RES, 680
R473 0613952Q69 RES, 680
R474 0613952H61 RES, 330
R475 0613952R31 RES, 180K
R476 0613952R25 RES, 100K
R477 0613952Q81 RES, 2200
R478 0613952Q81 RES, 2200
R479 0613952R25 RES, 100K
R480 0613952G67 RES, 0
R481 Not_Placed -
R482 Not_Placed -
R483 Not_Placed -
R484 Not_Placed -
R485 Not_Placed -
R486 Not_Placed -
R487 0613952R66 RES, 0
R488 0613952R37 RES, 330K
R489 Not_Placed -
R490 Not_Placed -
R491 0613952R66 RES, 0
R492 0613952R10 RES, 24K
R493 0613952R37 RES, 330K
R494 0613952Z80 RES, 330K
R495 0613952Q91 RES, 5600
R496 Not_Placed -
R497 Not_Placed -
R498 Not_Placed -
R499 Not_Placed -
Circuit
Ref
Motorola
Part No.
Description
R501 0613952Q49 RES, 100
R502 0613952Q49 RES, 100
R503 0613952Q49 RES, 100
R504 0613952Q49 RES, 100
R505 0613952Q49 RES, 100
R506 0613952Q49 RES, 100
R507 0613952Q49 RES, 100
R508 0613952R25 RES, 100K
R509 0613952R25 RES, 100K
R510 0613952R37 RES, 330K
R511 0613952R25 RES, 100K
R512 0613952R29 RES, 150K
R513 Not_Placed -
R514 0613952R25 RES, 100K
R515 Not_Placed -
R516 Not_Placed -
R517 0613952R66 RES, 0
R518 0613952R33 RES, 220K
R519 0613952R25 RES, 100K
R520 0613952R25 RES, 100K
R521 Not_Placed -
R522 0613952R25 RES, 100K
R523 0613952R01 RES, 10K
R524 0613952R01 RES, 10K
S440 4080710Z25 Switch, rotary, 16 chan. select
4080710Z34 Switch, rotary, 4 chan. select
S441 4070354A01 Switch
S442 4070354A01 Switch
S443 4070354A01 Switch
S444 1880619Z04 Potentiometer
SH1 2686421Z02 Shield
SH40 2686419Z02 Shield
SH50 2686423Z02 Shield
SH52 2686424Z02 Shield
SH100 2686418Z02 Shield
SH200 2686424Z02 Shield
SH201 2686423Z02 Shield
SH250 2686425Z02 Shield
SH251 2686425Z02 Shield
SH253 2686422Z02 Shield
SH400 2686420Z03 Shield
SH401 2686420Z03 Shield
T41 2515121H01 Balun Transformer
T42 2515121H01 Balun Transformer
Circuit
Ref
Motorola
Part No.
Description
U51 5115281H01 SA616
U52 5115070H01 TC7W04FU
U110 0178034A01 PA Module
U150 5114005A01 LM2904DR
U151 2415954H01 INDCTR Bead
U201* 5185177Y01 AT25016
U251 5105750U56 VCO Buffer IC
U310 5115746H01 Voltage Regulator
U320 5115679H01 Voltage Regulator
U330 5115745H01 Voltage Regulator
U401* 5185143E03 68HC11FLO
U402* 5115033H01 EEPROM IC
U403 Not_Placed -
U404* 5115032H01 Flash 128K
U425 5115697H01 OP AMP
U451 5115062H01 IC ASFIC_CMP_R1
U480 Not_Placed -
U490 9115811H03 Audio Amplifier
U510 5114005A01 LM2904DR
U511 4815066H01 Transistor
VR110 4813977A59 Diode Zener
VR301 4813977M29 Diode 20V
VR302 4813977M29 Diode 20V
VR471 4813977M14 Diode 6.8V
VR472 4813977M05 Diode 3.3V
VR473 4813977M29 Diode 20V
VR474 4813977M29 Diode 20V
VR475 4813977M24 Diode Zener
Y51 4802245J84 XTAL 44.395MHz
Y70 9186145B02 CDBCA455CX36-TC
Y201* 4880114R06 Crystal 16.8MHZ
Y202 Not_Placed -
Circuit
Ref
Motorola
Part No.
Description
