Motorola CP040 - Page 217

VHF 146-174 MHz Schematic Diagrams, Overlays, and Parts Lists (8486342Z09-A) 3-49
7.0 VHF (146-174 MHz) Radio Parts
List PCB No. 8486342Z09-A
Circuit
Ref
Motorola
Part No.
Description
C1 2109445U41 22 pF
C2 2109445U46 36 pF
C3 2109445U49 47 pF
C4 2109445U37 15 pF
C5 2109445U14 3.0 pF
C6 2109445U37 15 pF
C7 2109445U45 33 pF
C8 2109445U44 30 pF
C9 not used
C20 2113743L17 1000 pF
C22 2113743L17 1000 pF
C23 2113743L17 1000 pF
C24 not used
C25 2113743L17 1000 pF
C26 2113743L17 1000 pF
C29 2109445U48 43 pF
C30 2109445U42 24 pF
C31 2109445U44 30 pF
C32 2109445U51 56 pF
C33 2109445U42 24 pF
C34 2109445U51 56 pF
C35 2109445U43 27 pF
C36 2109445U42 24 pF
C40 2109445U40 20 pF
C41 2109445U37 15 pF
C42 2109445U46 36 pF
C43 2109445U37 15 pF
C44 2109445U40 20 pF
C51 2113743N48 82 pF
C52 2113743N32 18 pF
C53 2109445U26 9.1 pF
C55 2113743M24 0.1 uF
C56 2113743E20 0.1 uF
C57 2113743M24 0.1 uF
C58 2113743N16 3.9 pF
C59 2113743N12 2.7 pF
C60 2113743M24 0.1 uF
C62 2113743M24 0.1 uF
C63 2113743M24 0.1 uF
C64 2113743M24 0.1 uF
C65 2113743M24 0.1 uF
C66 2113743M24 0.1 uF
C67 2113743M24 0.1 uF
C68 2113743M24 0.1 uF
C69 2113743M24 0.1 uF
C70 2113743N53 130 pF
C71 2113743E20 0.1 uF
C72 2113743M24 0.1 uF
C73 2113743L33 4700 pF
C80 2109445U44 30 pF
C81 2109445U44 30 pF
C82 not used
C90 2113743M24 0.1 uF
C91 2311049A57 10 uF
C92 2113743E20 0.1 uF
C93 2113743N15 3.6 pF
C99 2113743M24 0.1 uF
C100 2113743L21 1500 pF
C101 2113743L21 1500 pF
C102 2113743M24 0.1 uF
C103 2113743L21 1500 pF
C104 not used
C105 not used
C106 2113743L21 1500 pF
C107 2113743N26 10 pF
C108 2113743M24 0.1 uF
C109 2113743M24 0.1 uF
C110 2113743M24 0.1 uF
C111 not used
C112 2113743L21 1500 pF
C113 2113743L21 1500 pF
C114 2113743L21 1500 pF
C115 2311049A07 1 uF
C116 2113743M24 0.1 uF
C117 2113741F25 1000 pF
C118 not used
C120 2113743L21 1500 pF
C121 2113743L21 1500 pF
C122 2113740F31 15 pF
C123 2113740F31 15 pF
C124 2113743L21 1500 pF
C130 2113740F29 12 pF
C131 2113740F15 3.3 pF
C132 2113740F37 27 pF
C133 2113740F15 3.3 pF
C134 2113740F37 27 pF
C135 2113740F17 3.9 pF
C136 2113740F30 13 pF
C137 2113740F58 200 pF
C140 2113740F30 13 pF
C141 2113740F33 18 pF
C150 2113743L21 1500 pF
C151 2113743L21 1500 pF
C152 2113743L21 1500 pF
C153 2113743K18 0.47 uF
C154 2113743L21 1500 pF
C155 2113743E20 0.1 uF
C156 2113743L41 .01 uF
C157 2113743M24 0.1 uF
Circuit
Ref
Motorola
Part No.
Description
C158 2113743L21 1500 pF
C159 2113743L21 1500 pF
C170 2113743L21 1500 pF
C171 2113743N12 2.7 pF
C201 2113740F59 220 pF
C202 2109445U52 62 pF
C203 2109445U13 2.7 pF
C204 2113743L09 470 pF
C205 not used
C206 not used
C207 2113743L09 470 pF
C208 2113743L09 470 pF
C209 2113743L09 470 pF
C210 2113743L09 470 pF
C211 2113743E20 0.1 uF
C212 2113743F18 2.2 uF
C213 2113743L41 .01 uF
C214 2113743L17 1000 pF
C215 2113743F18 2.2 uF
C216 2113743E20 0.1 uF
C217 2113743L17 1000 pF
C218 2113743F18 2.2 uF
C219 2113743E20 0.1 uF
C220 2113743N34 22 pF
C221 2113743L41 .01 uF
C222 2113743L41 .01 uF
C223 2113743L41 .01 uF
C224 2113743L41 .01 uF
C225 2311049A57 10 uF
C226 2311049A57 10 uF
C227 2113743L17 1000 pF
C228 2113743E20 0.1 uF
C230 2113743F18 2.2 uF
C231 2113743L17 1000 pF
C232 2113743E20 0.1 uF
C233 2311049A56 4.7 uF
C241 2113743L19 1200 pF
C243 2113741M69 0.1 uF
C244 2113741F27 1200 pF
C245 2311049A08 1 uF
C251 2113741F49 .01 uF
C253 2109445U38 16 pF
C254 2109445U15 3.3 pF
C255 2109445U39 18 pF
C256 2109445U27 10 pF
C257 2109445U46 36 pF
C258 2113743L19 1200 pF
C263 2109445U43 27 pF
C264 2109445U19 4.7 pF
C265 2109445U37 15 pF
C266 2109445U27 10 pF
Circuit
Ref
Motorola
Part No.
Description
C267 2109445U46 36 pF
C268 2109445U13 2.7 pF
C269 2113743L21 1500 pF
C270 2113743L19 1200 pF
C271 2113743L41 .01 uF
C272 2113743E20 0.1 uF
C273 2113743L41 .01 uF
C274 2113743E20 0.1 uF
C275 2113743L19 1200 pF
C276 2113743N19 5.1 pF
C277 2113743L19 1200 pF
C281 2113743L19 1200 pF
C282 2113743N25 9.1 pF
C283 2113743L19 1200 pF
C284 2113743L19 1200 pF
C285 2113743E20 0.1 uF
C286 2113743N27 11 pF
C290 2113743N43 51 pF
C291 2113743N39 36 pF
C292 2113743L19 1200 pF
C301 2113743L07 390 pF
C302 2113743L07 390 pF
C303 2311049A57 10 uF
C304 2113743L41 .01 uF
C305 2113743N50 100 pF
C306 2113741F49 .01 uF
C310 2113743L41 .01 uF
C311 2113743E05 .018 uF
C312 2311049A57 10 uF
C313 2113743L41 .01 uF
C314 2113743L19 1200 pF
C315 2113743L19 1200 pF
C316 2113743L19 1200 pF
C320 2113743E05 .018 uF
C321 2311049A57 10 uF
C322 2113743L41 .01 uF
C323 2113743N54 150 pF
C331 2113743L41 .01 uF
C333 2113743L41 .01 uF
C334 2311049A57 10 uF
C410 2311049A57 10 uF
C411 2113743M24 0.1 uF
C412 2113743L17 1000 pF
C413 2113743M24 0.1 uF
C414 2113743M24 0.1 uF
C415 2113743L17 1000 pF
C416 2113743L17 1000 pF
C417 2113743L17 1000 pF
C418 2113743M24 0.1 uF
C419 2113743L17 1000 pF
C420 2113743L41 .01 uF
Circuit
Ref
Motorola
Part No.
Description
