3-52 VHF 146-174 MHz Schematic Diagrams, Overlays, and Parts Lists (8486342Z09-A)
* Motorola Depot Servicing only
U490 5108858K99 audio power amplifier,
TDA8541
U510 5113818A01 dual opamp, LM2904
VR110 not used
VR301 4813830A33 zener diode, 20V,
MMBZ5250B
VR302 4813830A33 zener diode, 20V,
MMBZ5250B
VR471 4813830A18 zener diode, 6.8V,
MMBZ5235B
VR472 4813830A09 zener diode, 3.3V,
MMBZ5226B
VR473 4813830A33 zener diode, 20V,
MMBZ5250B
VR474 4813830A33 zener diode, 20V,
MMBZ5250B
VR475 4880140L20 zener diode, 15V,
MMBZ5245B
Y51 4880606B09 crystal, 44.395 MHz
Y70 9186145B02 ceramic discriminator, 455
kHz
Y201* 4880114R06 crystal, 16.8 MHz
Y202 not used
Circuit
Ref
Motorola
Part No.
Description
