Motorola CP040

Troubleshooting Table for Board and IC Signals 2-15
U480
Dual Opamp
1 Unit 1 output 2.48
2 Unit 1 (-) input 2.48
3 Unit 1 (+) input 2.46
4 Ground GND
5 Unit 2 (+) input 0.28
6 Unit 2 (-) input 0.29
7 Unit 2 output 0
8 Vcc 4.96
U490
Audio Power Amp
1 Enable/shutdown 0.12 (Unsquelched)
2 Bias reference 3.26 (Unsquelched)
3 (+) input 3.26 (Unsquelched)
4 (-) input 3.27 (Unsquelched)
5 (-) output 3.25 (Unsquelched)
6 Vcc 7.48 (Unsquelched)
7 Ground GND
8 (+) output 3.29 (Unsquelched)
U510
Dual Opamp
1 Unit 1 output 1.75
2 Unit 1 (-) input 1.56
3 Unit 1 (+) input 1.55
4 Ground GND
5 Unit 2 (+) input 1.55
6 Unit 2 (-) input 1.56
7 Unit 2 output 1.38
8 Vcc 4.96
1. All voltages are measured with a high-impedance digital voltmeter and expressed in volts DC relative to ground (0V).
2. Voltages are measured with a DC input voltage of 7.50 + .02 volts DC applied to the battery connector (J301).
3. All voltages are measured in the squelched receive mode, unless otherwise indicated.
IC Designator Pin Pin Function DC Voltage Comments (Condition)
