Motorola CP040

3-36 UHF2 PCB No. 8416205H02-C/-D Parts List
* Motorola Depot Servicing only
R418 0613952R25 RES 100K OHM
R419 0613952Q89 RES 4700 OHM
R420 0613952P30 RES 200K OHM
R421 0613952P01 RES, 100K OHM
R422 0613952R25 RES 100K OHM
R423 0613952R25 RES 100K OHM
R424 0613952P30 RES 200K OHM
R425 0613952P01 RES, 100K OHM
R430 0613952R25 RES 100K OHM
R431 NOTPLACED -
R432 0613952R66 RES 0.0 OHM
R433 0613952R25 RES 100K OHM
R434 NOTPLACED -
R440 0613952Q89 RES 4700 OHM
R441 0613952Q89 RES 4700 OHM
R442 0613952H57 RES, 220 OHM
R443 0613952H51 RES, 120 OHM
R445 0613952Q89 RES 4700 OHM
R446 0613952R01 RES 10K OHM
R451 0613952R17 RES 47K OHM
R460 0613952R10 RES 24K OHM
R462 0613952R10 RES 24K OHM
R463 0613952R10 RES 24K OHM
R464 0613952R12 RES 30K OHM
R469 0613952Q25 RES 10.0 OHM
R470 0613952Q81 RES 2200 OHM
R471 0613952Q81 RES 2200 OHM
R472 0613952Q69 RES 680 OHM
R473 0613952Q69 RES 680 OHM
R474 0613952H61 RES, 330 OHM
R475 0613952R31 RES 180K OHM
R476 0613952R25 RES 100K OHM
R477 0613952Q81 RES 2200 OHM
R478 0613952Q81 RES 2200 OHM
R479 0613952R25 RES 100K OHM
R480 0613952G67 RES, 0.0 OHM
R481 NOTPLACED -
R482 NOTPLACED -
R483 NOTPLACED -
R484 NOTPLACED -
R485 NOTPLACED -
R486 NOTPLACED -
R487 0613952R66 RES 0.0 OHM
R488 0613952R37 RES 330K OHM
Circuit
Ref
Motorola
Part No.
Description
R489 NOTPLACED -
R490 NOTPLACED -
R491 0613952R66 RES 0.0 OHM
R492 0613952R10 RES 24K OHM
R493 0613952R37 RES 330K OHM
R494 0613952Z80 RES 330K OHM
R495 0613952Q91 RES 5600 OHM
R496 NOTPLACED -
R497 NOTPLACED -
R498 NOTPLACED -
R499 NOTPLACED -
R501 0613952Q49 RES 100 OHM
R502 0613952Q49 RES 100 OHM
R503 0613952Q49 RES 100 OHM
R504 0613952Q49 RES 100 OHM
R505 0613952Q49 RES 100 OHM
R506 0613952Q49 RES 100 OHM
R507 0613952Q49 RES 100 OHM
R508 0613952R25 RES 100K OHM
R509 0613952R25 RES 100K OHM
R510 0613952R37 RES 330K OHM
R511 0613952R25 RES 100K OHM
R512 0613952R29 RES 150K OHM
R513 0613952R25 RES 100K OHM
R514 0613952R25 RES 100K OHM
R515 0613952R66 RES 0.0 OHM
R516 NOTPLACED -
R517 NOTPLACED -
R518 0613952R33 RES 220K OHM
R519 0613952R25 RES 100K OHM
R520 0613952R25 RES 100K OHM
R521 NOTPLACED -
R522 0613952R25 RES 100K OHM
R523 0613952R01 RES 10K OHM
S440 4080710Z25 SWITCH, rotary16CH Select
4080710Z34 SWITCH, rotary 4CH Select
S441 4070354A01 LIGHT TOUCH SWITCH
S442 4070354A01 LIGHT TOUCH SWITCH
S443 4070354A01 LIGHT TOUCH SWITCH
S444 1880619Z04 VOL POTENTIOMETER
SH1 2686421Z02 SHIELD, FE
SH40 2686419Z02 SHIELD, MIXER
SH50 2686423Z02 SHIELD, 19 X 19 X 3.03 MM
SH52 2686424Z02 SHIELD, IF
Circuit
Ref
Motorola
Part No.
Description
SH100 2686418Z02 SHIELD, HARMONIC FILTER
SH200 2686424Z02 SHIELD, IF
SH201 2686423Z02 SHIELD, 19 X 19 X 3.03 MM
SH250 2686425Z02 SHIELD
SH251 2686425Z02 SHIELD
SH253 2686422Z02 SHIELD, BUFFER
SH400 2686420Z03 SHIELD,CONTROL
SH401 2686420Z03 SHIELD,CONTROL
T41 2515121H01 BALUN, TRANSFORMER
T42 2515121H01 BALUN, TRANSFORMER
U51 5115281H01 FM IF IC SA616
U52 5115070H01 IC INVTR, TC7W04FU
U110 0186438Z05 UHF1 PA MODULE
U150 5114005A01 IC SING SPLY
U151 2415954H01 INDUCTOR BEAD CHIP
U201* 5185177Y01 IC AT25016 48 PIN
U251 5105750U56 VCO BUFFER IC
U310 5115746H01 VOLTAGE REGULATOR, 5V
U320 5115679H01 IC VOLTAGE REGLTR
U330 5115745H01 VOLTAGE REGULATOR, 3V
U401* 5185143E03 IC, MICROP, 3.7MHZ
U402* 5115033H01 IC,EEPROM 16K
U403 NOTPLACED -
U404* 5115032H01 IC,FLSH 128K
U425 5115697H01 LOW PWR OP AMP
U451 5115062H01 IC, CUST, TQFP48
U480 NOTPLACED -
U490 5116029H01 1 W AUDIO AMPLIFIER
U510 5114005A01 IC SING SPLY
U511 4815066H01 XSTR, UMG5NFTR
VR110 4813977A59 DIODE, 3.9V 0.2W
VR301 4813977M29 DIODE 20V ZENER
VR302 4813977M29 DIODE 20V ZENER
VR471 4813977M14 DIODE, 6.8V 0.225W
VR472 4813977M05 DIODE, 3.3V 0.225W
VR473 4813977M29 DIODE 20V ZENER
VR474 4813977M29 DIODE 20V ZENER
VR475 4813977M24 DIODE,ZEN,MBZ5245
Y51 4802245J84 XTAL 44.395MHz, 3RD OT
Y70 9186145B02 CER.DISCR.
CDBCA455CX36-TC
Y201* 4880114R08 CRYSTAL, QUARTZ 16.8
MHZ
Y202 NOTPLACED -
Circuit
Ref
Motorola
Part No.
Description
8416205H02 UHF BAND 1/2 MAIN BOARD
5480678Z01 LABEL BARCODE
Circuit
Ref
Motorola
Part No.
Description
