Diagnostics
High-Definition DVR DCX3510-M tInstallation Manual 69
365-095-17066-x.1
Figure 35: RF Upstream Modem Front Panel Display
Power level
Alternating with
Frequency
Frequency in
Decimal point
Power level in dB (blank if
modem not configured)
