General| power supply | 7.5 V |
|---|---|
| power VHF | 1-5 W |
| power UHF 1 | 1-4 W |
| power UHF 2 | 1-4 W |
| average battery life with standard Li-lon battery (low power) | >9 hours |
| average battery life with standard Li-lon battery (high power) | >7 hours |
| average battery life with high capacity Li-lon battery (low power) | >13 hours |
| average battery life with high capacity Li-lon battery (high power) | >10 hours |
| operating temperature | -20°C to +55°C |
| frequencies VHF | 136-174 MHz |
| frequencies UHF 1 | 403-470 MHz |
| frequencies UHF 2 | 450-527 MHz |
| channel spacing | 12.5/20/25 kHz |
| frequency stability | ±2.5 ppm |
| modulation limiting @ 12.5 kHz | ±2.5 |
| modulation limiting @ 20 kHz | ±4.0 |
| modulation limiting @ 25 kHz | ±5.0 |
| FM hum & noise | -40 dB typical |
| conducted/radiated emission <1 GHz | -36 dBm |
| conducted/radiated emission >1 GHz | -30 dBm |
| audio response (300-3000Hz) | +1 to -3 dB |
| audio distortion | <5% typical |
| frequencies VHF | 136-174 MHz |
| frequencies UHF 1 | 403-470 MHz |
| frequencies UHF 2 | 450-527 MHz |
| channel spacing | 12.5/20/25 kHz |
| sensitivity (12 dB SINAD) EIA | 0.35 µV typical |
| intermodulation EIA | -65 dB |
| adjacent channel selectivity @ 12.5 kHz | 60 dB |
| adjacent channel selectivity @ 20/25 kHz | 70 dB |
| spurious rejection | 70 dB |
| rated audio | 0.5W |
| audio response (300-3000 Hz) | +1 to -3 dB |
Weight and Dimensions| dimensions with standard Li-lon battery | 101.5 x 55.5 x 30.5 mm |
|---|---|
| dimensions with high capacity Li-lon battery | 101.5 x 55.5 x 35.5 mm |
| weight with standard Li-lon battery | 250 gm |
| weight with high capacity Li-lon battery | 270 gm |
