Chapter 4
POWER UP SELF-TEST
1.0 Error Codes
Turning on the radio using the ON/OFF volume control starts a self-test routine which checks the
RAM, ROM checksum, EEPROM hardware and EEPROM checksum. If these checks are
successfully completed, the radio will generate the Self-Test Pass Tone. Radio emits only “bonk” (300
Hz) tone if it fails the self-test.
* for Display models only.
*Error Code Explanation Corrective Action
“RAM TST ERROR” RAM Test Failure Retest radio by turning it off and turning it on again. If
message reoccurs, replace RAM (U405).
“ROM CS ERROR” ROM Checksum is
wrong.
Reprogram FLASH Memory, then retest. If message
reoccurs, replace ROM (U406).
“EEPRM HW ERROR” Codeplug structure
mismatch, non
existence of
codeplug.
Reprogram codeplug with correct version and retest
radio. If message reoccurs, replace EEPROM
(U407).
“EEPRM CS ERROR” Codeplug
checksum is wrong.
Reprogram codeplug.
No Display Display module is
not connected
properly.
Display module is
damaged.
Check connection between main board and display
module.
Replace with new display module.
