9-30 UHF Band 1 Circuit Board/Schematic Diagrams and Parts List (PCB 8480450Z03)
C428 2113743M24 0.1uF, +80%/-20%
C429 2113743M24 0.1uF, +80%/-20%
C430 2113928N01
0662057M01
0.1uF, 10%
0 (SUB on LS
+
Models Only)
C431 2113743N50 100pF
C432 Not Placed -
C433 2113743L41 .01uF, 10%
C434 2113743M24 0.1uF, +80%/-20%
C435 2113743M24 0.1uF, +80%/-20%
C436 2113743N34 22pF
C437 2113743N34 22pF
C440 2113743G26 4.7uF, +80%/-20%
C441 2113743N50 100pF
C442 2113743E20 0.1uF, 10%
C443 2113928N01 0.1uF, 10%
C444 2113743N50 100pF
C445 2113743N50 100pF
C447 2113928N01 0.1uF, 10%
C448 2113928N01 0.1uF, 10%
C449 2113743N50 100pF
C450 2113743M24 0.1uF, +80%/-20%
C451 2113743M08 .022uF, +80%/-20%
C452 2113743G26 4.7uF, +80%/-20%
C453 2113743N50 100pF
C456 2113743N50 100pF
C458 2113743N50 100pF
C459 2113743N50 100pF
C463 2113743N50 100pF
C466 2113743N50 100pF
C467 2113928N01 0.1uF, 10%
C471 2113743N50 100pF
C472 2113743N50 100pF
C473 2113743N50 100pF
C475 2113743H14 10uF, +80%/-20%
C476 2113928D08 10uF, +80%/-20%
C479 2113928N01 0.1uF, 10%
C480 2113928D08 10uF, +80%/-20%
C481 2113928N01 0.1uF, 10%
C482 2113928N01
0662057M01
0.1uF, 10%
0 (SUB on LS
+
Models Only)
C490 2113743N50 100pF
C491 2113743N50 100pF
C492 2113743N50 100pF
C493 2113743N50 100pF
C494 2113743N50 100pF
C495 2113743N50 100pF
C496 2113743N50 100pF
C497 2113743N50 100pF
C502 2311049A05 0.47uF, 10%; 25V
C503 2113743N50 100pF
C505 2113743N50 100pF
C511 2113743N50 100pF
C512 2113743N50 100pF
C513 2113743N50 100pF
C514 2113743N50 100pF
C520 2113743L41 .01uF, 10%
Circuit
Ref
Motorola Part
No.
Description
C521 2113743L41 .01uF, 10%
C522 2113743L41 .01uF, 10%
C523 2113743L41 .01uF, 10%
CR101 4880973Z02 Pin Diode
CR102 4802245J41 Pin Diode
CR105 5185963A15 Temperature Sense
CR201 4802233J09 Triple Diode
CR203 4862824C03 Varactor
CR241 4805649Q13 Dual Varactor
CR242 4862824C01 Varactor
CR243 4862824C01 Varac to r
CR251 4802245J22 Varactor
CR301 4862824C01 Varac to r
CR302 4862824C01 Varactor
CR303 4880154K03 Dual Common Anode-Cathode
CR304 4862824C01 Varactor
CR305 4862824C01 Varac to r
CR306 4802245J42 Ring Quad Diode
CR308 4802245J41 Pin Diode
CR310 4862824C01 Varactor
CR411 4802245J47 Schottky Diode
CR412 4802245J47 Schottky Diode
CR413 4802245J47 Schottky Diode
CR440 4813833C02 Dual Diode Common Cathode
CR501 4880107R01 Rectifier
CR503 4805729G49 LED Red/Yellow
E101 2484657R01 Ferrite Bead
E400 2480640Z01 Ferrite Bead
E401 2480640Z01 Ferrite Bead
E402 2480640Z01 Ferrite Bead
E403 2480640Z01 Ferrite Bead
E404 2480640Z01 Ferrite Bead
E405 2480640Z01 Ferrite Bead
E406 2480640Z01 Ferrite Bead
E407 2480640Z01 Ferrite Bead
E408 2480640Z01 Ferrite Bead
E409 2480640Z01 Ferrite Bead
F501 6580542Z01 Fuse 3A
FL201 4802245J49 16.8 MHz Xtal Clip (not field
serviceable)
FL301 4802245J43 Xtal Filter 45.1 MHz
FL401 4870368G02 Osc Xtal 38.4 kHz
H101 2680499Z01 Heat Spreader
J101 0180117S05 RF Jack Assembly
J102 0280519Z02 Antenna Nut
J400 0905505Y04 40-pins Connector
J403 0905505Y02 20-pins Connector
L101 2460591B80 19.61nH, 10%
L102 2460591B80 19.61nH, 10%
L104 2460591B80 19.61nH, 10%
L105 2462587N22 390nH, 10%
L106 2460591A11 7.66nH, 10%
L107 2460591G24 33.47nH, 10%
L108 2460591A01 4.22nH, 10%
L109 2460591B04 11.03nH, 10%
L112 2462587N22 390nH, 10%
Circuit
Ref
Motorola Part
No.
Description
L113 2413926H09 5.6nH, 5%
L114 2462587N22 390nH, 10%
L115 2462587N22 390nH, 10%
L116 2460591A50 9.75nH, 10%
L160 2413926H14 15.0nH, 5%
L201 2462587Q20 2.2uH, 20%
L202 2462587Q20 2.2uH, 20%
L203 2462587Q20 2.2uH, 20%
L232 2462587P25 12uH, 5%
L241 2462587V41 390nH, 10%
L242 2462587V38 220nH, 5%
L243 2460593C01 Teflon Resonator
L251 2462587V28 33nH, 5%
L253 2460593C02 Teflon Resonator
L261 2462587V29 39nH, 5%
L271 2462587V32 68nH, 5%
L273 2462587V28 33nH, 5%
L281 2462587V41 390nH, 10%
L282 2462587V41 390nH, 10%
L301 2460591C04 13.9nH, 10%
L302 2460591C04 13.9nH, 10%
L303 2462587V38 220nH, 5%
L304 2462587V37 180nH, 5%
L305 2462587V27 27nH, 5%
L306 2460591C04 13.9nH, 10%
L307 2460591C04 13.9nH, 10%
L309 2460591C16 16.28nH, 10%
L310 2462587V36 150nH,5%
L311 2462587N65 750nH,5%
L314 2462587N72 2.2uH, 5%
L321 Not Placed -
L325 2480646Z20 2.2uH
L330 2462587N64 680nH, 5%
L331 2480646Z20 2.2uH
L332 2462587N53 100nH, 5%
L340 2462587V41 390nH, 10%
L400 2462587Q42 390nH, 10%
L401 2462587Q42 390nH, 10%
L410 2462587Q42 390nH, 10%
L411 2462587Q42 390nH, 10%
L505 2462587Q42 390nH, 10%
P100 3905643V01 Gnd Contact Finger
PB501 4080523Z01 Tactile, Pushbutton
PB502 4080523Z01 Tactile, Pushbutton
PB503 4080523Z01 Tactile, Pushbutton
PB504 4080523Z01 Tactile, Pushbutton
PB505 4080523Z01 Tactile, Pushbutton
Q110 4802245J55 RF Power FET
Q111 4802245J50 Dual NPN/PNP
Q210 4802245J50 Dual NPN/PNP
Q241 4805218N63 NPN
Q260 4802245J50 Dual NPN/PNP
Q261 4802245J50 Dual NPN/PNP
Q301 4802245J44 NPN
Q302 4802245J44 NPN
Q310 Not Placed -
Circuit
Ref
Motorola Part
No.
Description
Q315 4880214G02 NPN
Q316 Not Placed -
Q320 4805218N63 NPN
Q400 4809579E18 MOSFET P-Chan
Q403 4880214G02 NPN
Q405 4802245J54 Dual NPN
Q410 4802245J54 Dual NPN
Q416 4809579E18 MOSFET P-Chan
Q417 4802245J50 Dual NPN/PNP
Q502 5180159R01 Dual NPN
Q505 4880214G02 NPN
R101 0662057A34 240
R102 0680539Z01 0.1, 1%
R103 0662057M41 43
R104 0662057M81 2K
R106 0662057M26 10
R107 Not Placed -
R108 Not Placed -
R109 0662057N30 200K
R110 0662057M61 300
R111 0662057M33 20
R112 0662057M61 300
R120 0662057M01 0
R130 0662057M98 10K
R131 0662057M98 10K
R132 0662057N39 470K
R133 Not Placed -
R161 0662057M57 200
R170 0662057A34 240
R171 0662057M92 5.6K
R172 0662057A32 200
R173 0662057N47 1MEG
R201 0662057N21 82K
R202 0662057N23 100K
R204 0662057N15 47K
R231 0662057M52 120
R232 0662057M69 620
R233 0662057M68 560
R241 0662057M32 18
R242 0662057M57 200
R243 0662057M98 10K
R244 0662057N01 12K
R245 0662057M59 240
R248 0662057M37 30
R251 0662057M32 18
R252 0662057M62 330
R253 0662057M95 7.5K
R254 0662057M95 7.5K
R255 0662057M89 4.3K
R256 0662057M37 30
R260 0662057M74 1K
R281 0662057M01 0
R300 0662057M82 2.2K
R301 0662057N23 100K
R302 0662057N23 100K
R303 0662057M74 1K
Circuit
Ref
Motorola Part
No.
Description
To Next Page
