Motorola HT Series

UHF Band 1 Circuit Board/Schematic Diagrams and Parts List (PCB 8415234H01, 8415234H02, 8415234H05, 8415234H08) 9-139
C463 2113944A40 CAP CER CHP 100.0PF 50V
5%
C466 2113944A40 CAP CER CHP 100.0PF 50V
5%
C467 2113946B04 CAP CER CHP 0.10UF 10V
10%
C471 2113944A40 CAP CER CHP 100.0PF 50V
5%
C472 2113945A05 CAP CER CHP 470PF 50V
10%
C473 2113945A05 CAP CER CHP 470PF 50V
10%
C475 2113956E91 CAP,FXD,10UF,+10%,-10%,
16V-DC,
C476 2113946R01 CAP CER CHP 10.0UF 10V
C479 2113946B04 CAP CER CHP 0.10UF 10V
10%
C480 2113946R01 CAP CER CHP 10.0UF 10V
C481 2113946B04 CAP CER CHP 0.10UF 10V
10%
C482 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
C490 2113944A40 CAP CER CHP 100.0PF 50V
5%
C491 2113944A40 CAP CER CHP 100.0PF 50V
5%
C492 2113944A40 CAP CER CHP 100.0PF 50V
5%
C493 2113944A40 CAP CER CHP 100.0PF 50V
5%
C494 2113944A40 CAP CER CHP 100.0PF 50V
5%
C495 2113944A40 CAP CER CHP 100.0PF 50V
5%
C496 2113944A40 CAP CER CHP 100.0PF 50V
5%
C497 2113944A40 CAP CER CHP 100.0PF 50V
5%
C498 NOT PLACED -
C499 2113946B04 CAP CER CHP 0.10UF 10V
10%
C502 2313960A55 CAP,FXD,.47UF,+10%,-10%
,25V-DC
C503 2113944A84 CAP,FXD,43PF,+5%,-5%,50V-
DC,04
C505 2113944A40 CAP CER CHP 100.0PF 50V
5%
C511 2113944A40 CAP CER CHP 100.0PF 50V
5%
C512 2113944A40 CAP CER CHP 100.0PF 50V
5%
Circuit
Ref
Motorola
Part No.
Description
C513 2113944A40 CAP CER CHP 100.0PF 50V
5%
C514 2113944A40 CAP CER CHP 100.0PF 50V
5%
C520 2113945B02 CAP CER CHP 10,000PF 25V
10%
C521 2113945B02 CAP CER CHP 10,000PF 25V
10%
C522 2113945B02 CAP CER CHP 10,000PF 25V
10%
C523 2113945B02 CAP CER CHP 10,000PF 25V
10%
C524 2113944A40 CAP CER CHP 100.0PF 50V
5%
C525 2113944A40 CAP CER CHP 100.0PF 50V
5%
C526 2113944A40 CAP CER CHP 100.0PF 50V
5%
C527 2113944A40 CAP CER CHP 100.0PF 50V
5%
C528 2113944A40 CAP CER CHP 100.0PF 50V
5%
C529 2113944A40 CAP CER CHP 100.0PF 50V
5%
C597 NOT PLACED -
C610 2113944A40 CAP CER CHP 100.0PF 50V
5%
C611 2113944A40 CAP CER CHP 100.0PF 50V
5%
C612 2113944A40 CAP CER CHP 100.0PF 50V
5%
C613 2113944A40 CAP CER CHP 100.0PF 50V
5%
C615 2113944A40 CAP CER CHP 100.0PF 50V
5%
C616 2113944A40 CAP CER CHP 100.0PF 50V
5%
C618 2113944A40 CAP CER CHP 100.0PF 50V
5%
C619 2113944A40 CAP CER CHP 100.0PF 50V
5%
C620 2113944A40 CAP CER CHP 100.0PF 50V
5%
C621 2113944A40 CAP CER CHP 100.0PF 50V
5%
C622 2113944A40 CAP CER CHP 100.0PF 50V
5%
CR101 4880973Z02 PIN DIODE
CR102 4815257H01 SURFACE MOUNT PIN
DIODES
Circuit
Ref
Motorola
Part No.
Description
CR103 4815257H01 SURFACE MOUNT PIN
DIODES
CR105 5115022H01 IC TEMPERATURE SENSOR
CR160 NOT PLACED -
CR201 4815011H01 DIODE TRIPLE
CR203 4815072H01 DIODE VARACTOR
CR241 4885094Y01 DIODE VARACTOR ISV228
W18
CR242 4815279H01 BBY5503WE6327 FROM
INFINEON
CR243 4815279H01 BBY5503WE6327 FROM
INFINEON
CR251 4815322H01 VHF VARIABLE
CAPACITANCE DIODE
CR301 4815279H01 BBY5503WE6327 FROM
INFINEON
CR302 4815279H01 BBY5503WE6327 FROM
INFINEON
CR303 4815048H01 SOT MMBD353 DIODE DUAL
SCHT
CR304 4815279H01 BBY5503WE6327 FROM
INFINEON
CR305 4815279H01 BBY5503WE6327 FROM
INFINEON
CR306 4815923H02 SCHOTTKY DIODE-NEW
LEADFREE
CR311 4813974A19 DIODE ARRAY,MXR,SM,SOT-
323,7V,
CR312 4815047H01 BAND SWITCHIND
DIODE,ROHM DAN
CR313 4815047H01 BAND SWITCHIND
DIODE,ROHM DAN
CR411 4815067H01 DIODE SCHOTTKY, RB731U
CR412 4815067H01 DIODE SCHOTTKY, RB731U
CR413 4815067H01 DIODE SCHOTTKY, RB731U
CR440 4813978C02 PB FREE, NOT COMPLETELY
ENRICH
CR501 4815155H01 RECTIFIER
CR503 4805729G49 DIODE RED/YEL
D601 4880479U01 LED
D602 4880479U01 LED
D603 4880479U01 LED
D604 4880479U01 LED
D605 4880479U01 LED
D606 4880479U01 LED
E101 2415954H01 INDUCTOR BEAD CHIP
E400 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E401 2480640Z01 SURFACE MOUNT FERRITE
BEAD
Circuit
Ref
Motorola
Part No.
Description
E402 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E403 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E404 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E405 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E406 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E407 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E408 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E409 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E634 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E637 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E638 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E639 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E640 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E641 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E642 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E643 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E644 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E645 2480640Z01 SURFACE MOUNT FERRITE
BEAD
F501 6515076H01 FUSE CHIP SMT TR/1608FF
3A
FL201 4805875Z04 CRYSTAL 16.8 MHZ
FL301 9180022M11 XTAL FILTER 44.85MHZ
FL302 9180468V05 SMD455KHZ 4 ELEMENT CER
FLTR
FL303 9115811H03 SMD455KHZ 6 ELEMENT
FL304 9115811H01 SMD455KHZ 6 ELEMENT
FL401 4870368G02 REFLOWABLE CLOCK OSC
XTAL
H101 2680499Z02 HEAT SPREADER
J101 0985613Z01 JACK, RF
J102 0280519Z06 NUT, ANTENNA
J400 0915064H03 CONNECTOR, ZIF (40 PINS)
Circuit
Ref
Motorola
Part No.
Description
