Motorola HT Series

9-144 UHF Band 1 Circuit Board/Schematic Diagrams and Parts List (PCB 8415234H01, 8415234H02, 8415234H05, 8415234H08)
C264 2113944A40 CAP CER CHP 100.0PF 50V
5%
C265 NOT PLACED -
C271 NOT PLACED -
C272 NOT PLACED -
C273 2113946K02 CAP CER CHP 0.10UF 16V
C276 2113946N03 CAP CER CHP 2.2UF 16V
C277 2113944A40 CAP CER CHP 100.0PF 50V
5%
C278 2313960D07 CAP,FXD,10,+10,-10,16,SM,-
55MIN,125MAX,174,EPXY,PB
-FREE
C279 2113946N03 CAP CER CHP 2.2UF 16V
C281 2113944A40 CAP CER CHP 100.0PF 50V
5%
C285 2113944A40 CAP CER CHP 100.0PF 50V
5%
C286 2113946K02 CAP CER CHP 0.10UF 16V
C289 2113944A40 CAP CER CHP 100.0PF 50V
5%
C291 2313960M51 CAP,FXD,10UF,+10%,-10%,
6.3V-DC,SM,-55DEG
CMIN,125DEG CMAX,96MA
C292 2113946K02 CAP CER CHP 0.10UF 16V
C293 2113945G98 CAP,FXD,.47UF,+10%,-10%,
50V-DC,0805,X7R,-55DEG
CMIN,125DEG CMAX
C294 2113944A40 CAP CER CHP 100.0PF 50V
5%
C295 2113944A40 CAP CER CHP 100.0PF 50V
5%
C296 2113946K02 CAP CER CHP 0.10UF 16V
C297 2113945B02 CAP CER CHP 10,000PF 25V
10%
C298 2113946K02 CAP CER CHP 0.10UF 16V
C301 2113944A14 CAP CER CHP 3.6PF 50V +/-
0.25PF
C302 2113944A25 CAP CER CHP 10.0PF 50V +/
- 0.5PF
C303 2113944C20 CAP CER CHP 3.9PF 50V +/-
0.25PF
C304 2113944A25 CAP CER CHP 10.0PF 50V +/
- 0.5PF
C305 2113944A80 CAP,FXD,20PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX,PB
C306 NOT PLACED -
C307 2113944A40 CAP CER CHP 100.0PF 50V
5%
C308 2113944A40 CAP CER CHP 100.0PF 50V
5%
Circuit
Ref.
Motorola
Part No.
Description
C309 2113944A40 CAP CER CHP 100.0PF 50V
5%
C310 2113944A40 CAP CER CHP 100.0PF 50V
5%
C311 NOT PLACED -
C312 2113944A24 CAP CER CHP 9.1PF 50V +/-
0.5PF
C313 2113944A25 CAP CER CHP 10.0PF 50V +/
- 0.5PF
C314 2113946K02 CAP CER CHP 0.10UF 16V
C315 2113944A40 CAP CER CHP 100.0PF 50V
5%
C316 2113944C20 CAP CER CHP 3.9PF 50V +/-
0.25PF
C317 2113944A24 CAP CER CHP 9.1PF 50V +/-
0.5PF
C318 2113944A22 CAP CER CHP 7.5PF 50V +/-
0.5PF
C319 2113944A11 CAP CER CHP 2.7PF 50V +/-
0.25PF
C320 2113944A79 CAP,FXD,16PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX,PB
C321 2113944A40 CAP CER CHP 100.0PF 50V
5%
C322 2113944A38 CAP CER CHP 82.0PF 50V
5%
C324 2113944A29 CAP CER CHP 22.0PF 50V
5%
C325 2115153H26 CAP, CERAMIC, COG
C326 2113946K02 CAP CER CHP 0.10UF 16V
C327 2113946K02 CAP CER CHP 0.10UF 16V
C328 2113946K02 CAP CER CHP 0.10UF 16V
C329 2113946K02 CAP CER CHP 0.10UF 16V
C334 2113945A13 CAP CER CHP 4700PF 50V
10%
C337 NOT PLACED -
C338 NOT PLACED -
C343 2113946K02 CAP CER CHP 0.10UF 16V
C344 2113945D04 CAP CER CHP 100,000PF
25V 10%
C345 2113946K02 CAP CER CHP 0.10UF 16V
C346 2113946K02 CAP CER CHP 0.10UF 16V
C347 2113946K02 CAP CER CHP 0.10UF 16V
C348 2113946K02 CAP CER CHP 0.10UF 16V
C349 2113945D04 CAP CER CHP 100,000PF
25V 10%
C350 2113946K02 CAP CER CHP 0.10UF 16V
C351 2113944A41 CAP CER CHP 120.0PF 50V
5%
Circuit
Ref.
Motorola
Part No.
Description
C352 2113946K02 CAP CER CHP 0.10UF 16V
C355 2113946K02 CAP CER CHP 0.10UF 16V
C357 2113946K02 CAP CER CHP 0.10UF 16V
C358 NOT PLACED -
C359 NOT PLACED -
C360 2113944A13 CAP CER CHP 3.3PF 50V +/-
0.25PF
C361 2113946K02 CAP CER CHP 0.10UF 16V
C362 2113946K02 CAP CER CHP 0.10UF 16V
C364 2113944A81 CAP,FXD,24PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX,PB
C366 NOT PLACED -
C367 2113944A82 CAP,FXD,30PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX,PB
C370 2113944A17 CAP CER CHP 4.7PF 50V +/-
0.25PF
C371 NOT PLACED -
C372 2113944A40 CAP CER CHP 100.0PF 50V
5%
C373 NOT PLACED -
C374 2113944A40 CAP CER CHP 100.0PF 50V
5%
C375 2113944A40 CAP CER CHP 100.0PF 50V
5%
C378 NOT PLACED -
C380 2113945B02 CAP CER CHP 10,000PF 25V
10%
C381 NOT PLACED -
C382 2313960B57 CAP,TANTALUM,10UF,+10%,
-10%,4V-DC,S
C383 NOT PLACED -
C385 2113944A82 CAP,FXD,30PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX,PB
C386 2113944A40 CAP CER CHP 100.0PF 50V
5%
C390 NOT PLACED -
C404 NOT PLACED -
C406 NOT PLACED -
C432 NOT PLACED -
C502 2313960A55 CAP TANT 0.47 UF 10% 25V
3216-18
C503 2113743N41 CAP CHIP 43.0 PF 5% COG
C505 2113944A40 CAP CER CHP 100.0PF 50V
5%
C511 2113944A40 CAP CER CHP 100.0PF 50V
5%
Circuit
Ref.
Motorola
Part No.
Description
C512 2113944A40 CAP CER CHP 100.0PF 50V
5%
C513 2113944A40 CAP CER CHP 100.0PF 50V
5%
C514 2113944A40 CAP CER CHP 100.0PF 50V
5%
C520 2113945B02 CAP CER CHP 10,000PF 25V
10%
C521 2113945B02 CAP CER CHP 10,000PF 25V
10%
C522 2113945B02 CAP CER CHP 10,000PF 25V
10%
C523 2113945B02 CAP CER CHP 10,000PF 25V
10%
C525 2113944A40 CAP CER CHP 100.0PF 50V
5%
C526 2113944A40 CAP CER CHP 100.0PF 50V
5%
C527 2113944A40 CAP CER CHP 100.0PF 50V
5%
C528 2113944A40 CAP CER CHP 100.0PF 50V
5%
C529 2113944A40 CAP CER CHP 100.0PF 50V
5%
C530 2113944A40 CAP CER CHP 100.0PF 50V
5%
C531 2113944A40 CAP CER CHP 100.0PF 50V
5%
C532 2113944A40 CAP CER CHP 100.0PF 50V
5%
C533 2113944A40 CAP CER CHP 100.0PF 50V
5%
C534 2113944A40 CAP CER CHP 100.0PF 50V
5%
C535 2113944A40 CAP CER CHP 100.0PF 50V
5%
C536 2113944A40 CAP CER CHP 100.0PF 50V
5%
C537 2113944A40 CAP CER CHP 100.0PF 50V
5%
C538 2113944A40 CAP CER CHP 100.0PF 50V
5%
C539 NOT PLACED -
C540 NOT PLACED -
C541 NOT PLACED -
C542 NOT PLACED -
C543 NOT PLACED -
C544 2113944A40 CAP CER CHP 100.0PF 50V
5%
C545 2113944A40 CAP CER CHP 100.0PF 50V
5%
Circuit
Ref.
Motorola
Part No.
Description
