Motorola HT Series

2-2 Radio Power Distribution:
R = Regulator Jumper
Table 2-1. VDD Regulator Scheme by Band
Band
Vdd
Regulator
Scheme
Low Band Dual
VHF Dual
UHF Dual
800 MHz Dual
900 MHz Dual
Table 2-2. Radio Jumpers
Jumpers
Dual Vdd
Regulator
Scheme
Single Vdd
Regulator
Scheme
R401 Y Y
R402 N N
R403 N Y
R404 N N
R405 Y N
