Motorola HT Series

9-154 UHF Band 1 Circuit Board/Schematic Diagrams and Parts List (PCB 8415234H01, 8415234H02, 8415234H05, 8415234H08)
VR449 4813977A54 DIODE,ZEN,MM3Z10V,SM,S
OD-323,1
VR450 4815040H01 ZENER DIODE-12V
VR460 4815038H01 ZENER DIODE-6.8V
VR501 4813977M14 DIODE,ZEN,MBZ5235,SM,S
OT-23,6.
VR506 4815038H01 ZENER DIODE-6.8V
Y300 4802245J84 XTAL 44.395MHZ, 3RD OT,
SMD
Y301 9186145B02 CER.DISCR.
CDBCA455CX36-TC
Circuit
Ref
Motorola
Part No.
Description
