UHF Band 1 Circuit Board/Schematic Diagrams and Parts List (PCB 8415234H01, 8415234H02, 8415234H05, 8415234H08) 9-159
R130 0613952R01 CER CHIP RES 10K OHM
5% 0402
R131 0613952R07 CER CHIP RES 18K OHM
5% 0402
R132 0613952R35 CER CHIP RES 270K OHM
5% 0402
R133 NOT PLACED -
R136 NOT PLACED -
R161 0613952Q56 CER CHIP RES 200 OHM 5
0402
R170 0613952H58 CER CHIP RES 240 OHM 5
0603
R171 0613952R16 CER CHIP RES 43K OHM 5
0402
R172 0613952H49 CER CHIP RES 100 OHM
5% 0603
R173 0613952R31 CER CHIP RES 180K OHM
5% 0402
R174 0613952R17 CER CHIP RES 47K OHM
5% 0402
R175 0613952H12 CER CHIP RES 3.0 OHM 5
0603
R176 0613952H12 CER CHIP RES 3.0 OHM 5
0603
R201 0613952R23 CER CHIP RES 82K OHM
5% 0402
R202 0613952R25 CER CHIP RES 100K OHM
5% 0402
R204 0613952R17 CER CHIP RES 47K OHM
5% 0402
R231 0613952Q51 CER CHIP RES 120 OHM 5
0402
R232 0613952Q68 CER CHIP RES 620 OHM 5
0402
R233 0613952Q67 CER CHIP RES 560 OHM 5
0402
R241 0613952Q31 CER CHIP RES 18.0 OHM 5
0402
R242 0613952Q56 CER CHIP RES 200 OHM 5
0402
R243 0613952R01 CER CHIP RES 10K OHM
5% 0402
R244 0613952R03 CER CHIP RES 12K OHM
5% 0402
R245 0613952Q58 CER CHIP RES 240 OHM 5
0402
R248 0613952Q36 CER CHIP RES 30.0 OHM 5
0402
R251 0613952Q31 CER CHIP RES 18.0 OHM 5
0402
Circuit
Ref
Motorola
Part No.
Description
R252 0613952Q61 CER CHIP RES 330 OHM 5
0402
R253 0613952Q94 CER CHIP RES 7500 OHM 5
0402
R254 0613952Q94 CER CHIP RES 7500 OHM 5
0402
R255 0613952Q88 CER CHIP RES 4300 OHM 5
0402
R256 0613952Q36 CER CHIP RES 30.0 OHM 5
0402
R260 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R281 NOT PLACED -
R301 0613952R25 CER CHIP RES 100K OHM
5% 0402
R302 0613952R25 CER CHIP RES 100K OHM
5% 0402
R303 0613952Q80 CER CHIP RES 2000 OHM 5
0402
R304 0613952R03 CER CHIP RES 12K OHM
5% 0402
R305 0613952Q66 CER CHIP RES 510 OHM 5
0402
R306 0613952R25 CER CHIP RES 100K OHM
5% 0402
R307 0613952R25 CER CHIP RES 100K OHM
5% 0402
R308 0613952Q42 CER CHIP RES 51.0 OHM 5
0402
R309 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R310 NOT PLACED -
R311 0613952R13 CER CHIP RES 33K OHM
5% 0402
R312 0613952Q89 CER CHIP RES 4700 OHM 5
0402
R313 0613952Q61 CER CHIP RES 330 OHM 5
0402
R314 0613952Q78 CER CHIP RES 1600 OHM 5
0402
R315 0613952R03 CER CHIP RES 12K OHM
5% 0402
R320 NOT PLACED -
R321 0613952R15 CER CHIP RES 39K OHM
5% 0402
R322 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R324 0613952R08 CER CHIP RES 20K OHM 5
0402
R328 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
Circuit
Ref
Motorola
Part No.
Description
R329 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R330 0613952R01 CER CHIP RES 10K OHM
5% 0402
R331 0613952Q56 CER CHIP RES 200 OHM 5
0402
R332 0613952R03 CER CHIP RES 12K OHM
5% 0402
R333 NOT PLACED -
R339 0613952Q88 CER CHIP RES 4300 OHM 5
0402
R340 0613952Q94 CER CHIP RES 7500 OHM 5
0402
R342 0613952R25 CER CHIP RES 100K OHM
5% 0402
R344 0613952Q42 CER CHIP RES 51.0 OHM 5
0402
R345 0613952R15 CER CHIP RES 39K OHM
5% 0402
R346 0613952R05 CER CHIP RES 15K OHM
5% 0402
R348 0613952Q86 CER CHIP RES 3600 OHM 5
0402
R349 0613958J74 CER CHIP RES 0.0 OHM
JMP 0805
R350 0613952Q85 CER CHIP RES 3300 OHM 5
0402
R355 0613952R25 CER CHIP RES 100K OHM
5% 0402
R358 0613952Q82 CER CHIP RES 2400 OHM 5
0402
R359 NOT PLACED -
R360 0613952R08 CER CHIP RES 20K OHM 5
0402
R361 0613952R08 CER CHIP RES 20K OHM 5
0402
R363 0613952Q63 CER CHIP RES 390 OHM 5
0402
R364 0613952Q79 CER CHIP RES 1800 OHM 5
0402
R365 0613952Q75 CER CHIP RES 1200 OHM 5
0402
R366 0613952R03 CER CHIP RES 12K OHM
5% 0402
R367 0613952N09 CER CHIP RES 12.1K OHM
1 0402
R368 0613952N01 CER CHIP RES 10.0K OHM
1 0402
R369 0613952Q69 CER CHIP RES 680 OHM 5
0402
Circuit
Ref
Motorola
Part No.
Description
R370 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R371 NOT PLACED -
R372 NOT PLACED -
R373 NOT PLACED -
R374 NOT PLACED -
R375 NOT PLACED -
R376 NOT PLACED -
R377 NOT PLACED -
R378 NOT PLACED -
R400 0613952R17 CER CHIP RES 47K OHM
5% 0402
R401 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R402 NOT PLACED -
R403 NOT PLACED -
R405 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R406 0613952R22 CER CHIP RES 75K OHM 5
0402
R407 0613952R21 CER CHIP RES 68K OHM
5% 0402
R408 NOT PLACED -
R409 0613952R01 CER CHIP RES 10K OHM
5% 0402
R410 0613952R25 CER CHIP RES 100K OHM
5% 0402
R411 0613952R01 CER CHIP RES 10K OHM
5% 0402
R413 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R414 0613952P25 CER CHIP RES 178K OHM 1
0402
R415 0613952N93 CER CHIP RES 90.9K OHM
1 0402
R416 0613952R01 CER CHIP RES 10K OHM
5% 0402
R418 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R419 0613952Q66 CER CHIP RES 510 OHM 5
0402
R420 0613952J73 CER CHIP RES 10.0M OHM
5% 0603
R421 0613952Q80 CER CHIP RES 2000 OHM 5
0402
R423 0613952R41 CER CHIP RES 470K OHM
5% 0402
R424 0613952R14 CER CHIP RES 36K OHM 5
0402
R425 0613952R12 CER CHIP RES 30K OHM 5
0402
Circuit
Ref
Motorola
Part No.
Description
