Motorola HT Series

UHF Band 1 Circuit Board/Schematic Diagrams and Parts List (PCB 8415234H01, 8415234H02, 8415234H05, 8415234H08) 9-161
U420 5115280H01 AUDIO AMPLIFIER
TDA8547TS
U602 5115014H01 CMOS,MAX SUPPLY VOL
15.5V
VR432 4813979P10 DIODE ARRAY,TRANSIENT
PROTECTI
VR433 4813979P10 DIODE ARRAY,TRANSIENT
PROTECTI
VR434 4815038H01 ZENER DIODE-6.8V
VR439 4813977M21 DIODE,ZEN,MBZ5242,SM,S
OT-23,12
VR440 4815038H01 ZENER DIODE-6.8V
VR441 4815038H01 ZENER DIODE-6.8V
VR442 4815038H01 ZENER DIODE-6.8V
VR443 4815038H01 ZENER DIODE-6.8V
VR444 4815038H01 ZENER DIODE-6.8V
VR445 4813977A54 DIODE,ZEN,MM3Z10V,SM,S
OD-323,1
VR446 4813977A54 DIODE,ZEN,MM3Z10V,SM,S
OD-323,1
VR447 4813977A54 DIODE,ZEN,MM3Z10V,SM,S
OD-323,1
VR448 4813977A54 DIODE,ZEN,MM3Z10V,SM,S
OD-323,1
VR449 4813977A54 DIODE,ZEN,MM3Z10V,SM,S
OD-323,1
VR450 4815040H01 ZENER DIODE-12V
VR460 4815038H01 ZENER DIODE-6.8V
VR501 4813977M14 DIODE,ZEN,MBZ5235,SM,S
OT-23,6.
VR506 4815038H01 ZENER DIODE-6.8V
Y300 4802245J84 XTAL 44.395MHZ, 3RD OT,
SMD
Y301 9186145B02 CER.DISCR.
CDBCA455CX36-TC
Circuit
Ref
Motorola
Part No.
Description
