9-198 UHF Band 2 Circuit Board/Schematic Diagrams and Parts List (PCB 8485641Z06 / 8485677Z03)
C416 2113928N01 0.1uF, 10%
C419 NOT PLACED -
C420 2113743L41 10000pF, 10%
C421 2113928N01 0.1uF, 10%
C422 2113743M24 100000pF, +80%/-20%
C423 2113743N50 100pF
C424 2311049A59 10uF, 10%, 6V
C425 2113743M24 100000pF, +80%/-20%
C426 2113743N50 100pF
C427 2113743N50 100pF
C428 2113743M24 100000pF, +80%/-20%
C429 2113743M24 100000pF, +80%/-20%
C430 2113928N01
0662057M01
0.1uF, 10%
0 (SUB on Models LS
+
Only)
C431 2113743N50 100pF
C432 NOT PLACED -
C433 2113743L41 10000pF, 10%
C434 2113928N01 0.1uF, 10%
C435 2113743M24 100000pF, +80%/-20%
C436 2113743N34 22pF
C437 2113743N34 22pF
C440 2113743G26 4.7uF, +80%/-20%
C441 2113743N50 100pF
C442 2113743E20 0.10uF, 10%
C443 2113928N01 0.1uF, 10%
C444 2113743N50 100pF
C445 2113743N50 100pF
C447 2113743M08 22000pF, +80%/-20%
C448 2113928N01 0.1uF, 10%
C449 2113743N50 100pF
C450 NOT PLACED -
C451 2113743M08 22000pF, +80%/-20%
C452 2113743B29 1uF, 10%
C453 2113743N50 100pF
C456 2113743N50 100pF
C458 2113743N50 100pF
C459 2113743N50 100pF
C463 2113743N50 100pF
C466 2113743N50 100pF
C467 2113928N01 0.1uF, 10%
C471 2113743N50 100pF
C472 2113743L09 470pF, 10%
C473 2113743L09 470pF, 10%
C475 2113743H14 10uF, +80%/-20%
C476 2113928D08 10uF, +/-80%/-20%
C479 2113928N01 0.1uF, 10%
C480 2113928D08 10uF, +/-80%/-20%
C481 2113928N01 0.1uF, 10%
C482 2113928N01
0662057M01
0.1uF, 10%
0 (SUB on Models LS
+
Only)
C490 2113743N50 100pF
C491 2113743N50 100pF
C492 2113743N50 100pF
C493 2113743N50 100pF
C494 2113743N50 100pF
C495 2113743N50 100pF
Circuit
Ref
Motorola Part
No.
Description
C496 2113743N50 100pF
C497 2113743N50 100pF
C502 2311049A05 0.47uF, 10%, 25V
C503 2113743N50 100pF
C505 2113743N50 100pF
C511 2113743N50 100pF
C512 2113743N50 100pF
C513 2113743N50 100pF
C514 2113743N50 100pF
C520 2113743L41 10000pF, 10%
C521 2113743L41 10000pF, 10%
C522 2113743L41 10000pF, 10%
C523 2113743L41 10000pF, 10%
C524 2113743N50 100pF
C525 2113743N50 100pF
C526 2113743N50 100pF
C527 2113743N50 100pF
C528 2113743N50 100pF
C529 NOT PLACED -
CR101 4880973Z02 Pin diode
CR102 4802245J41 Pin diode
CR103 4802245J41 Pin diode
CR105 5185963A15 Temperature sensor
CR160 NOT PLACED -
CR201 4802233J09 Triple diode (SOT 25)
CR203 4862824C03 Varactor
CR241 4805649Q13 Varactor
CR242 4862824C01 Varactor
CR243 4862824C01 Varac to r
CR251 4862824C01 Varactor
CR301 4862824C01 Varac to r
CR302 4862824C01 Varactor
CR303 4880154K03 Dual common anode-cathode
diode
CR304 4862824C01 Varactor
CR305 4862824C01 Varac to r
CR306 4802245J42 Ring Quad diode (SOT-143)
CR308 4802245J41 Pin diode
CR310 4862824C01 Varactor
CR411 4802245J62 Diode Schottky
CR412 4802245J62 Diode Schottky
CR413 4802245J62 Diode Schottky
CR440 4813833C02 Dual common cathode diode
CR501 4880107R01 Rectifier
CR503 4805729G49 LED Red/Yellow
E101 2484657R01 Ferrite bead
E400 2480640Z01 Ferrite bead
E401 2480640Z01 Ferrite bead
E402 2480640Z01 Ferrite bead
E403 2480640Z01 Ferrite bead
E404 2480640Z01 Ferrite bead
E405 2480640Z01 Ferrite bead
E406 2480640Z01 Ferrite bead
E407 2480640Z01 Ferrite bead
E408 2480640Z01 Ferrite bead
E409 2480640Z01 Ferrite bead
Circuit
Ref
Motorola Part
No.
Description
F501 6580542Z01 3A fuse
FL201 4805875Z04 16.8 MHz Xtal oscillator (not field
serviceable)
FL301 4802245J43 Xtal Filter 45.1 MHz
FL401 4870368G02 Xtal Oscillator 38.4 kHz
H101 2680499Z01 Heat spreader
J101 0985613Z01 RF Jack
J102 0280519Z02 Antenna nut
J403 0905505Y02 20-pin connector
L101 2460591B28 13.37nH
L102 2460591B28 13.37nH
L104 2460591B48 15.22nH
L105 2462587N22 390nH
L106 2460591A19 8.71nH
L107 2479990G01 33.47nH
L108 2479990A01 4.22nH
L112 2462587N42 12nH, 5%
L113 2413926H09 5.6nH, 0.3
L114 2462587N42 12nH, 5%
L115 2462587N22 390nH
L116 2479990C02 16.28nH
L117 2409154M17 22nH
L160 2413926H14 15nH, 5%
L201 2462587Q20 2200nH, 20%
L202 2462587Q20 2200nH, 20%
L203 2462587Q20 2200nH, 20%
L232 2462587P25 12000nH, 5%
L241 2462587V41 390nH
L242 2462587V26 22nH, 5%
L243 2460593C03 Multi-layered Teflon resonator, Rx
L251 2462587V41 390nH
L253 2460593C03 Multi-layered Teflon resonator, Tx
L261 2462587V29 39nH, 5%
L271 2462587V27 27nH, 5%
L273 2462587V25 18nH, 5%
L281 2462587V41 390nH
L282 2462587V41 390nH
L301 2479990B01 11.03nH
L302 2479990B01 11.03nH
L303 2462587V26 22nH, 5%
L304 2462587V37 180nH, 5%
L305 2462587V23 12nH, 5%
L306 2479990B01 11.03nH
L307 2479990B01 11.03nH
L309 2479990C02 16.28nH
L310 2462587V36 150nH, 5%
L311 2462587N65 750nH, 5%
L314 2462587N72 2200nH, 5%
L321 NOT PLACED -
L325 2480646Z20 2.2uH
L330 2462587N64 680nH, 5%
L331 2480646Z20 2.2uH
L332 2462587N53 100nH, 5%
L340 2462587V41 390nH
L400 2462587Q42 390nH
L401 2462587Q42 390nH
Circuit
Ref
Motorola Part
No.
Description
L410 2462587Q42 390nH
L411 2462587Q42 390nH
L505 2462587Q42 390nH
P100 3905643V01 Ground contact finger
PB501 4080523Z01 Tactile switch, pushbutton
PB502 4080523Z01 Tactile switch, pushbutton
PB503 4080523Z01 Tactile switch, pushbutton
PB504 4080523Z01 Tactile switch, pushbutton
PB505 4080523Z01 Tactile switch, pushbutton
Q110 4813828A09 RF Power Amplifier
Q111 4802245J50 Dual NPN/PNP transistor
Q210 4802245J50 Dual NPN/PNP transistor
Q241 4805218N63 RF NPN transistor
Q260 4802245J50 Dual NPN/PNP transistor
Q261 4802245J50 Dual NPN/PNP transistor
Q301 4802245J44 NPN Transistor
Q302 4802245J44 NPN Transistor
Q310 NOT PLACED -
Q315 4880214G02 NPN Transistor
Q316 NOT PLACED -
Q320 4805218N63 RF NPN transistor
Q400 4809579E18 Mosfet P - channel
Q403 4813824A17 Bipolar Transistor, PNP
Q405 4802245J54 Dual NPN Transistor
Q410 4802245J54 Dual NPN Transistor
Q416 4809579E18 Mosfet P - channel
Q417 4802245J50 Dual NPN/PNP transistor
Q502 5180159R01 Dual NPN Transistor
Q505 4880214G02 NPN Transistor
R101 0662057A34 240
R102 0680539Z01 0.1
R104 0662057N15 47K
R106 0662057M26 10
R107 NOT PLACED -
R108 0662057M92 5600
R109 0662057N30 200K
R110 0662057M61 300
R111 0662057M33 20
R112 0662057M61 300
R120 0662057N14 43K
R130 0662057M98 10K
R131 0662057N05 18K
R132 0662057N33 270K
R133 NOT PLACED -
R136 0662057N47 1M
R161 0662057M57 200
R170 0662057A34 240
R171 0662057N14 43K
R172 0662057A32 200
R173 0662057N29 180K
R174 0662057N15 47K
R175 0662057B59 3
R176 0662057B59 3
R191 0662057C01 0
R201 0662057N21 82K
R202 0662057N23 100K
Circuit
Ref
Motorola Part
No.
Description
