UHF Band 2 Circuit Board/Schematic Diagrams and Parts List (PCB 8415235H01, 8415235H05) 9-257
UHF (450-527 MHz) Radio Parts List (PCB
8415235H01)
Circuit
Ref
Motorola
Part No.
Description
B501 0986237A02 CONNECTOR (CONTACT
BATTERY)
B503 3980502Z01 CONTACT, BACKUP B+
B504 3980501Z01 CONTACT, BACKUP B-
C101 2113944C45 CAP CER CHP 100.0PF 50V
5%
C102 2113944C72 CAP,FXD,6.2PF,.25PF+/-,50V-
DC,060
C103 2113944C77 CAP,FXD,11PF,+5%,-5%,50V-
DC,0603,C
C104 2113944C72 CAP,FXD,6.2PF,.25PF+/-,50V-
DC,060
C105 2113944A40 CAP CER CHP 100.0PF 50V
5%
C106 2113944C22 CAP CER CHP 4.7PF 50V +/-
0.25PF
C107 2113944C18 CAP CER CHP 3.3PF 50V +/-
0.25PF
C108 2113944A40 CAP CER CHP 100.0PF 50V
5%
C109 2113944C45 CAP CER CHP 100.0PF 50V
5%
C110 2113944A40 CAP CER CHP 100.0PF 50V
5%
C111 2115938H01 CAP CHIP CL1 11.0 +/-0.05
PF
C112 2115937H03 HIGH Q CHIP CAPACITOR,
33PF
C113 2115937H02 HIGH Q CHIP CAPACITOR,
15PF
C114 2113944A40 CAP CER CHP 100.0PF 50V
5%
C115 2113944A79 CAP,FXD,16PF,+5%,-5%,50V-
DC,0402,C
C116 2113944A77 CAP,FXD,11PF,+5%,-5%,50V-
DC,0402,C
C117 NOT PLACED
C118 2113944A40 CAP CER CHP 100.0PF 50V
5%
C119 2113944A40 CAP CER CHP 100.0PF 50V
5%
C120 2113944A22 CAP CER CHP 7.5PF 50V +/-
0.5PF
C121 2113944A40 CAP CER CHP 100.0PF 50V
5%
C122 2113944A40 CAP CER CHP 100.0PF 50V
5%
C123 2313960F04 CAP TANT 33 UF 10% 16V
6032-28
C125 2113944A40 CAP CER CHP 100.0PF 50V
5%
C126 2113946K02 CAP CER CHP 0.10UF 16V
C127 2113945A09 CAP CER CHP 1000PF 50V
10%
C128 2113945B04 CAP,FXD,.022UF,+10%,-10%,
25V-DC,04
C129 2113944A22 CAP CER CHP 7.5PF 50V +/-
0.5PF
C130 2113944A40 CAP CER CHP 100.0PF 50V
5%
C131 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C132 2113944A40 CAP CER CHP 100.0PF 50V
5%
C133 2113945A09 CAP CER CHP 1000PF 50V
10%
C134 2113945A12 CAP CER CHP 3300PF 50V
10%
C135 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C138 2113944A40 CAP CER CHP 100.0PF 50V
5%
C140 0613952H91 CER CHIP RES 5600 OHM
5% 0603
C141 2113944C28 CAP CER CHP 8.2PF 50V +/-
0.5PF
C150 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C151 2113944A40 CAP CER CHP 100.0PF 50V
5%
C152 2113945B04 CAP,FXD,.022UF,+10%,-10%,
25V-DC,04
C160 2113944A34 CAP CER CHP 56.0PF 50V
5%
C161 2113946K02 CAP CER CHP 0.10UF 16V
C165 2113944A34 CAP CER CHP 56.0PF 50V
5%
C166 2113944A40 CAP CER CHP 100.0PF 50V
5%
C169 2113944A08 CAP CER CHP 2.0PF 50V +/-
0.25PF
C170 2113944A40 CAP CER CHP 100.0PF 50V
5%
C171 2113944A40 CAP CER CHP 100.0PF 50V
5%
C172 2113945D04 CAP CER CHP 100,000PF
25V 10%
C173 2113945B04 CAP,FXD,.022UF,+10%,-10%,
25V-DC,04
Circuit
Ref
Motorola
Part No.
Description
C174 2113944A40 CAP CER CHP 100.0PF 50V
5%
C180 NOT PLACED
C181 NOT PLACED
C188 2113944A83 CAP,FXD,36PF,+5%,-5%,50V-
DC,0402,C
C201 2113944A40 CAP CER CHP 100.0PF 50V
5%
C202 2113945A09 CAP CER CHP 1000PF 50V
10%
C203 2313960B30 CAP TANT 4.7 UF 10% 10V
3216-18
C204 2113946N03 CAP CER CHP 2.2UF 16V
C206 2113944C04 CAP CER CHP 330.0PF 50V
5%
C207 2113944A32 CAP CER CHP 39.0PF 50V
5%
C208 NOT PLACED
C210 2113944A40 CAP CER CHP 100.0PF 50V
5%
C211 2113944A40 CAP CER CHP 100.0PF 50V
5%
C212 2113944A40 CAP CER CHP 100.0PF 50V
5%
C213 2113944A40 CAP CER CHP 100.0PF 50V
5%
C214 2113944A40 CAP CER CHP 100.0PF 50V
5%
C217 2113946N03 CAP CER CHP 2.2UF 16V
C218 2113946K02 CAP CER CHP 0.10UF 16V
C219 2113946L03 CAP CER CHP 0.22UF 16V
C220 2113944A40 CAP CER CHP 100.0PF 50V
5%
C223 2113946K02 CAP CER CHP 0.10UF 16V
C224 2113946K02 CAP CER CHP 0.10UF 16V
C228 2313960D05 CAP TANT 4.7 UF 10% 16V
3528-21
C229 2113945A09 CAP CER CHP 1000PF 50V
10%
C230 2113944A40 CAP CER CHP 100.0PF 50V
5%
C231 2113946K02 CAP CER CHP 0.10UF 16V
C232 2113945D02 CAP CER CHP 47,000PF 25V
10%
C233 2313960A26 CAP TANT 0.1 UF 10% 35V
3216-18
C234 2313960A55 CAP TANT 0.47 UF 10% 25V
3216-18
C235 2113946N03 CAP CER CHP 2.2UF 16V
C238 2113945L17 CAP,FXD,470PF,+5%,-5%,
50V-DC,0603,
Circuit
Ref
Motorola
Part No.
Description
C241 2113944A40 CAP CER CHP 100.0PF 50V
5%
C242 2113944A16 CAP CER CHP 4.3PF 50V +/-
0.25PF
C243 2113944A16 CAP CER CHP 4.3PF 50V +/-
0.25PF
C244 2113944C17 CAP CER CHP 3.0PF 50V +/-
0.25PF
C245 2113944A11 CAP CER CHP 2.7PF 50V +/-
0.25PF
C246 2113944A40 CAP CER CHP 100.0PF 50V
5%
C247 2113944A40 CAP CER CHP 100.0PF 50V
5%
C248 2113946K02 CAP CER CHP 0.10UF 16V
C250 2113944A16 CAP CER CHP 4.3PF 50V +/-
0.25PF
C251 2113944A40 CAP CER CHP 100.0PF 50V
5%
C252 2113944A18 CAP CER CHP 5.1PF 50V +/-
0.5PF
C253 2113944C12 CAP CER CHP 1.8PF 50V +/-
0.25PF
C254 2113944A25 CAP CER CHP 10.0PF 50V +/
- 0.5PF
C255 2113944A40 CAP CER CHP 100.0PF 50V
5%
C256 2113944A18 CAP CER CHP 5.1PF 50V +/-
0.5PF
C257 2113944A40 CAP CER CHP 100.0PF 50V
5%
C258 2113945B02 CAP CER CHP 10,000PF 25V
10%
C259 2113945B02 CAP CER CHP 10,000PF 25V
10%
C260 2113944A40 CAP CER CHP 100.0PF 50V
5%
C263 2113944A62 CAP,FXD,.75PF,.25PF+/-,50V-
DC,040
C264 2113944A40 CAP CER CHP 100.0PF 50V
5%
C265 NOT PLACED
C271 NOT PLACED
C272 2115153H01 CAP, CERAMIC, COG
C273 2113946K02 CAP CER CHP 0.10UF 16V
C276 2113946N03 CAP CER CHP 2.2UF 16V
C277 2113944A40 CAP CER CHP 100.0PF 50V
5%
C278 2313960D07 CAP TANT 10 UF 10% 16V
3528-21
C279 2113946N03 CAP CER CHP 2.2UF 16V
Circuit
Ref
Motorola
Part No.
Description
